Collection: Retaining Rings - Internal - Spiral Rings - Medium-Heavy Duty

Retaining Rings (With Images)

Internal

Spiral Rings

Carbon Steel

20 Products in this selection

This is a combined category of Medium-Heavy Duty Spiral Rings Internal Retaining Rings.
Use the filters in the table below, or the category tree above to refine the selection. To order any item, simply click the part number for a full product page, then add to your cart.

Additional resources:
Spiral Rings and Snap Rings PDF

A more concise listing may be found on the Smallparts store at Retaining Rings - Internal - Spiral Rings - Medium-Heavy Duty. Smallparts promote the most popular MBA products.

Housing Bore (B)	Clip Thickness (T)	Groove Dia. (Dg)	Approx. Loose Circlip OD (Dr)	Radial Wall (S)	Groove Width (W)
Housing Bore (B) 22.23 mm _{(0.875 in.)}	Clip Thickness (T) 1.07 mm +/- 0.05 _{(0.042 in.)}	Groove Dia. (Dg) 23.42 mm _{(0.922 in.)}	Approx. Loose Circlip OD (Dr) 23.61 mm + 0.33 / - 0.00	Radial Wall (S) 1.65 mm +/- 0.10	Groove Width (W) 1.21 mm +/- 0.08
Material: Spring Steel Approx. Loose Clip ID: 20.31 +/- 0.04 Groove Depth (d): 0.61 Category: Retaining Rings - Internal - Spiral Rings - Medium-Heavy Duty - Carbon Steel
Part Number: RRT-087 (6 Pcs) Internal Retaining Rings - 22.23x1.07x23.42 mm - Spring Steel 17 units (102 pcs) Available Immediately \| Further orders can be expected around Fri, Jun 20, 2025 Regular price $14.32 AUD Regular price Sale price $14.32 AUD Unit price per Per 6
Housing Bore (B)	Clip Thickness (T)	Groove Dia. (Dg)	Approx. Loose Circlip OD (Dr)	Indicative Image
Housing Bore (B) 22.23 mm _{(0.875 in.)}	Clip Thickness (T) 1.07 mm +/- 0.05 _{(0.042 in.)}	Groove Dia. (Dg) 23.42 mm _{(0.922 in.)}	Approx. Loose Circlip OD (Dr) 23.61 mm + 0.33 / - 0.00
Material: Spring Steel Radial Wall (S): 1.65 mm +/- 0.10 Groove Width (W): 1.21 mm +/- 0.08 Approx. Loose Clip ID: 20.31 +/- 0.04 Groove Depth (d): 0.61 Category: Retaining Rings - Internal - Spiral Rings - Medium-Heavy Duty - Carbon Steel
Part Number: RRT-087 (6 Pcs) Internal Retaining Rings - 22.23x1.07x23.42 mm - Spring Steel 17 units (102 pcs) Available Immediately \| Further orders can be expected around Fri, Jun 20, 2025 Regular price $14.32 AUD Regular price Sale price $14.32 AUD Unit price per Per 6 View the product page first if you are unsure.
RRT-087 (6 Pcs) --- Internal Retaining Rings - 22.23x1.07x23.42 mm - Spring Steel RRT-087 (6 Pcs) --- Internal Retaining Rings - 22.23x1.07x23.42 mm - Spring Steel Regular price $14.32 AUD Regular price Sale price $14.32 AUD Unit price per 17 Available Now
Housing Bore (B) 23.83 mm _{(0.938 in.)}	Clip Thickness (T) 1.07 mm +/- 0.05 _{(0.042 in.)}	Groove Dia. (Dg) 25.12 mm _{(0.989 in.)}	Approx. Loose Circlip OD (Dr) 25.31 mm + 0.33 / - 0.00	Radial Wall (S) 1.91 mm +/- 0.11	Groove Width (W) 1.21 mm +/- 0.08
Material: Spring Steel Approx. Loose Clip ID: 21.49 +/- 0.04 Groove Depth (d): 0.66 Category: Retaining Rings - Internal - Spiral Rings - Medium-Heavy Duty - Carbon Steel
Part Number: RRT-093 (6 Pcs) Internal Retaining Rings - 23.83x1.07x25.12 mm - Spring Steel Out of Stock \| Backorder Now \| Orders can be expected around Sun, Jun 08, 2025 Regular price $14.05 AUD Regular price Sale price $14.05 AUD Unit price per Per 6
Housing Bore (B) 23.83 mm _{(0.938 in.)}	Clip Thickness (T) 1.07 mm +/- 0.05 _{(0.042 in.)}	Groove Dia. (Dg) 25.12 mm _{(0.989 in.)}	Approx. Loose Circlip OD (Dr) 25.31 mm + 0.33 / - 0.00
Material: Spring Steel Radial Wall (S): 1.91 mm +/- 0.11 Groove Width (W): 1.21 mm +/- 0.08 Approx. Loose Clip ID: 21.49 +/- 0.04 Groove Depth (d): 0.66 Category: Retaining Rings - Internal - Spiral Rings - Medium-Heavy Duty - Carbon Steel
Part Number: RRT-093 (6 Pcs) Internal Retaining Rings - 23.83x1.07x25.12 mm - Spring Steel Out of Stock \| Backorder Now \| Orders can be expected around Sun, Jun 08, 2025 Regular price $14.05 AUD Regular price Sale price $14.05 AUD Unit price per Per 6 View the product page first if you are unsure.
RRT-093 (6 Pcs) --- Internal Retaining Rings - 23.83x1.07x25.12 mm - Spring Steel RRT-093 (6 Pcs) --- Internal Retaining Rings - 23.83x1.07x25.12 mm - Spring Steel Regular price $14.05 AUD Regular price Sale price $14.05 AUD Unit price per Out of stock! Backorder Now
Housing Bore (B) 34.93 mm _{(1.375 in.)}	Clip Thickness (T) 1.27 mm +/- 0.05 _{(0.05 in.)}	Groove Dia. (Dg) 36.83 mm _{(1.45 in.)}	Approx. Loose Circlip OD (Dr) 37.10 mm + 0.38 / - 0.00	Radial Wall (S) 2.49 mm +/- 0.10	Groove Width (W) 1.47 mm +/- 0.10
Material: Spring Steel Approx. Loose Clip ID: 32.12 +/- 0.05 Groove Depth (d): 0.97 Category: Retaining Rings - Internal - Spiral Rings - Medium-Heavy Duty - Carbon Steel
Part Number: RRT-137 (4 Pcs) Internal Retaining Rings - 34.93x1.27x36.83 mm - Spring Steel Out of Stock \| Backorder Now \| Orders can be expected around Sun, Jun 08, 2025 Regular price $12.95 AUD Regular price Sale price $12.95 AUD Unit price per Per 4
Housing Bore (B) 34.93 mm _{(1.375 in.)}	Clip Thickness (T) 1.27 mm +/- 0.05 _{(0.05 in.)}	Groove Dia. (Dg) 36.83 mm _{(1.45 in.)}	Approx. Loose Circlip OD (Dr) 37.10 mm + 0.38 / - 0.00
Material: Spring Steel Radial Wall (S): 2.49 mm +/- 0.10 Groove Width (W): 1.47 mm +/- 0.10 Approx. Loose Clip ID: 32.12 +/- 0.05 Groove Depth (d): 0.97 Category: Retaining Rings - Internal - Spiral Rings - Medium-Heavy Duty - Carbon Steel
Part Number: RRT-137 (4 Pcs) Internal Retaining Rings - 34.93x1.27x36.83 mm - Spring Steel Out of Stock \| Backorder Now \| Orders can be expected around Sun, Jun 08, 2025 Regular price $12.95 AUD Regular price Sale price $12.95 AUD Unit price per Per 4 View the product page first if you are unsure.
RRT-137 (4 Pcs) --- Internal Retaining Rings - 34.93x1.27x36.83 mm - Spring Steel RRT-137 (4 Pcs) --- Internal Retaining Rings - 34.93x1.27x36.83 mm - Spring Steel Regular price $12.95 AUD Regular price Sale price $12.95 AUD Unit price per Out of stock! Backorder Now
Housing Bore (B) 38.10 mm _{(1.5 in.)}	Clip Thickness (T) 1.27 mm +/- 0.05 _{(0.05 in.)}	Groove Dia. (Dg) 40.13 mm _{(1.58 in.)}	Approx. Loose Circlip OD (Dr) 40.46 mm + 0.38 / - 0.00	Radial Wall (S) 2.74 mm +/- 0.10	Groove Width (W) 1.47 mm +/- 0.10
Material: Spring Steel Approx. Loose Clip ID: 34.98 +/- 0.05 Groove Depth (d): 1.02 Category: Retaining Rings - Internal - Spiral Rings - Medium-Heavy Duty - Carbon Steel
Part Number: RRT-150 Internal Retaining Rings - 38.1x1.27x40.13 mm - Spring Steel 31 Available Immediately \| Further orders can be expected around Sun, Jun 08, 2025 Regular price $4.32 AUD Regular price Sale price $4.32 AUD Unit price per Each
Housing Bore (B) 38.10 mm _{(1.5 in.)}	Clip Thickness (T) 1.27 mm +/- 0.05 _{(0.05 in.)}	Groove Dia. (Dg) 40.13 mm _{(1.58 in.)}	Approx. Loose Circlip OD (Dr) 40.46 mm + 0.38 / - 0.00
Material: Spring Steel Radial Wall (S): 2.74 mm +/- 0.10 Groove Width (W): 1.47 mm +/- 0.10 Approx. Loose Clip ID: 34.98 +/- 0.05 Groove Depth (d): 1.02 Category: Retaining Rings - Internal - Spiral Rings - Medium-Heavy Duty - Carbon Steel
Part Number: RRT-150 Internal Retaining Rings - 38.1x1.27x40.13 mm - Spring Steel 31 Available Immediately \| Further orders can be expected around Sun, Jun 08, 2025 Regular price $4.32 AUD Regular price Sale price $4.32 AUD Unit price per Each View the product page first if you are unsure.
RRT-150 --- Internal Retaining Rings - 38.1x1.27x40.13 mm - Spring Steel RRT-150 --- Internal Retaining Rings - 38.1x1.27x40.13 mm - Spring Steel Regular price $4.32 AUD Regular price Sale price $4.32 AUD Unit price per 31 Available Now
Housing Bore (B) 42.88 mm _{(1.688 in.)}	Clip Thickness (T) 1.58 mm +/- 0.08 _{(0.062 in.)}	Groove Dia. (Dg) 45.22 mm _{(1.78 in.)}	Approx. Loose Circlip OD (Dr) 45.54 mm + 0.51 / - 0.00	Radial Wall (S) 3.00 mm +/- 0.10	Groove Width (W) 1.78 mm +/- 0.13
Material: Spring Steel Approx. Loose Clip ID: 39.54 +/- 0.05 Groove Depth (d): 1.17 Category: Retaining Rings - Internal - Spiral Rings - Medium-Heavy Duty - Carbon Steel
Part Number: RRT-168 (28 Pcs) Internal Retaining Rings - 42.88x1.58x45.22 mm - Spring Steel Out of Stock \| Backorder Now \| Orders can be expected around Sun, Jun 08, 2025 Regular price $7.86 AUD Regular price Sale price $7.86 AUD Unit price per Per 28
Housing Bore (B) 42.88 mm _{(1.688 in.)}	Clip Thickness (T) 1.58 mm +/- 0.08 _{(0.062 in.)}	Groove Dia. (Dg) 45.22 mm _{(1.78 in.)}	Approx. Loose Circlip OD (Dr) 45.54 mm + 0.51 / - 0.00
Material: Spring Steel Radial Wall (S): 3.00 mm +/- 0.10 Groove Width (W): 1.78 mm +/- 0.13 Approx. Loose Clip ID: 39.54 +/- 0.05 Groove Depth (d): 1.17 Category: Retaining Rings - Internal - Spiral Rings - Medium-Heavy Duty - Carbon Steel
Part Number: RRT-168 (28 Pcs) Internal Retaining Rings - 42.88x1.58x45.22 mm - Spring Steel Out of Stock \| Backorder Now \| Orders can be expected around Sun, Jun 08, 2025 Regular price $7.86 AUD Regular price Sale price $7.86 AUD Unit price per Per 28 View the product page first if you are unsure.
RRT-168 (28 Pcs) --- Internal Retaining Rings - 42.88x1.58x45.22 mm - Spring Steel RRT-168 (28 Pcs) --- Internal Retaining Rings - 42.88x1.58x45.22 mm - Spring Steel Regular price $7.86 AUD Regular price Sale price $7.86 AUD Unit price per Out of stock! Backorder Now
Housing Bore (B) 44.45 mm _{(1.75 in.)}	Clip Thickness (T) 1.58 mm +/- 0.08 _{(0.062 in.)}	Groove Dia. (Dg) 46.87 mm _{(1.845 in.)}	Approx. Loose Circlip OD (Dr) 47.21 mm + 0.51 / - 0.00	Radial Wall (S) 3.00 mm +/- 0.10	Groove Width (W) 1.78 mm +/- 0.13
Material: Spring Steel Approx. Loose Clip ID: 41.21 +/- 0.05 Groove Depth (d): 1.22 Category: Retaining Rings - Internal - Spiral Rings - Medium-Heavy Duty - Carbon Steel
Part Number: RRT-175 (166 Pcs) Internal Retaining Rings - 44.45x1.58x46.87 mm - Spring Steel Out of Stock \| Backorder Now \| Orders can be expected around Fri, Jun 20, 2025 Regular price $1,047.68 AUD Regular price Sale price $1,047.68 AUD Unit price per Per 166
Housing Bore (B) 44.45 mm _{(1.75 in.)}	Clip Thickness (T) 1.58 mm +/- 0.08 _{(0.062 in.)}	Groove Dia. (Dg) 46.87 mm _{(1.845 in.)}	Approx. Loose Circlip OD (Dr) 47.21 mm + 0.51 / - 0.00
Material: Spring Steel Radial Wall (S): 3.00 mm +/- 0.10 Groove Width (W): 1.78 mm +/- 0.13 Approx. Loose Clip ID: 41.21 +/- 0.05 Groove Depth (d): 1.22 Category: Retaining Rings - Internal - Spiral Rings - Medium-Heavy Duty - Carbon Steel
Part Number: RRT-175 (166 Pcs) Internal Retaining Rings - 44.45x1.58x46.87 mm - Spring Steel Out of Stock \| Backorder Now \| Orders can be expected around Fri, Jun 20, 2025 Regular price $1,047.68 AUD Regular price Sale price $1,047.68 AUD Unit price per Per 166 View the product page first if you are unsure.
RRT-175 (166 Pcs) --- Internal Retaining Rings - 44.45x1.58x46.87 mm - Spring Steel RRT-175 (166 Pcs) --- Internal Retaining Rings - 44.45x1.58x46.87 mm - Spring Steel Regular price $1,047.68 AUD Regular price Sale price $1,047.68 AUD Unit price per Out of stock! Backorder Now
Housing Bore (B) 46.02 mm _{(1.812 in.)}	Clip Thickness (T) 1.58 mm +/- 0.08 _{(0.062 in.)}	Groove Dia. (Dg) 48.52 mm _{(1.91 in.)}	Approx. Loose Circlip OD (Dr) 48.87 mm + 0.51 / - 0.00	Radial Wall (S) 3.13 mm +/- 0.11	Groove Width (W) 1.78 mm +/- 0.13
Material: Spring Steel Approx. Loose Clip ID: 42.61 +/- 0.05 Groove Depth (d): 1.24 Category: Retaining Rings - Internal - Spiral Rings - Medium-Heavy Duty - Carbon Steel
Part Number: RRT-181 (29 Pcs) Internal Retaining Rings - 46.02x1.58x48.52 mm - Spring Steel Out of Stock \| Backorder Now \| Orders can be expected around Sun, Jun 08, 2025 Regular price $25.68 AUD Regular price Sale price $25.68 AUD Unit price per Per 29
Housing Bore (B) 46.02 mm _{(1.812 in.)}	Clip Thickness (T) 1.58 mm +/- 0.08 _{(0.062 in.)}	Groove Dia. (Dg) 48.52 mm _{(1.91 in.)}	Approx. Loose Circlip OD (Dr) 48.87 mm + 0.51 / - 0.00
Material: Spring Steel Radial Wall (S): 3.13 mm +/- 0.11 Groove Width (W): 1.78 mm +/- 0.13 Approx. Loose Clip ID: 42.61 +/- 0.05 Groove Depth (d): 1.24 Category: Retaining Rings - Internal - Spiral Rings - Medium-Heavy Duty - Carbon Steel
Part Number: RRT-181 (29 Pcs) Internal Retaining Rings - 46.02x1.58x48.52 mm - Spring Steel Out of Stock \| Backorder Now \| Orders can be expected around Sun, Jun 08, 2025 Regular price $25.68 AUD Regular price Sale price $25.68 AUD Unit price per Per 29 View the product page first if you are unsure.
RRT-181 (29 Pcs) --- Internal Retaining Rings - 46.02x1.58x48.52 mm - Spring Steel RRT-181 (29 Pcs) --- Internal Retaining Rings - 46.02x1.58x48.52 mm - Spring Steel Regular price $25.68 AUD Regular price Sale price $25.68 AUD Unit price per Out of stock! Backorder Now
Housing Bore (B) 47.63 mm _{(1.875 in.)}	Clip Thickness (T) 1.58 mm +/- 0.08 _{(0.062 in.)}	Groove Dia. (Dg) 50.17 mm _{(1.975 in.)}	Approx. Loose Circlip OD (Dr) 50.58 mm + 0.51 / - 0.00	Radial Wall (S) 3.25 mm +/- 0.10	Groove Width (W) 1.78 mm +/- 0.13
Material: Spring Steel Approx. Loose Clip ID: 44.08 +/- 0.05 Groove Depth (d): 1.27 Category: Retaining Rings - Internal - Spiral Rings - Medium-Heavy Duty - Carbon Steel
Part Number: RRT-187 (28 Pcs) Internal Retaining Rings - 47.63x1.58x50.17 mm - Spring Steel Out of Stock \| Backorder Now \| Orders can be expected around Sun, Jun 08, 2025 Regular price $10.86 AUD Regular price Sale price $10.86 AUD Unit price per Per 28
Housing Bore (B) 47.63 mm _{(1.875 in.)}	Clip Thickness (T) 1.58 mm +/- 0.08 _{(0.062 in.)}	Groove Dia. (Dg) 50.17 mm _{(1.975 in.)}	Approx. Loose Circlip OD (Dr) 50.58 mm + 0.51 / - 0.00
Material: Spring Steel Radial Wall (S): 3.25 mm +/- 0.10 Groove Width (W): 1.78 mm +/- 0.13 Approx. Loose Clip ID: 44.08 +/- 0.05 Groove Depth (d): 1.27 Category: Retaining Rings - Internal - Spiral Rings - Medium-Heavy Duty - Carbon Steel
Part Number: RRT-187 (28 Pcs) Internal Retaining Rings - 47.63x1.58x50.17 mm - Spring Steel Out of Stock \| Backorder Now \| Orders can be expected around Sun, Jun 08, 2025 Regular price $10.86 AUD Regular price Sale price $10.86 AUD Unit price per Per 28 View the product page first if you are unsure.
RRT-187 (28 Pcs) --- Internal Retaining Rings - 47.63x1.58x50.17 mm - Spring Steel RRT-187 (28 Pcs) --- Internal Retaining Rings - 47.63x1.58x50.17 mm - Spring Steel Regular price $10.86 AUD Regular price Sale price $10.86 AUD Unit price per Out of stock! Backorder Now
Housing Bore (B) 49.23 mm _{(1.938 in.)}	Clip Thickness (T) 1.58 mm +/- 0.08 _{(0.062 in.)}	Groove Dia. (Dg) 51.82 mm _{(2.04 in.)}	Approx. Loose Circlip OD (Dr) 52.28 mm + 0.51 / - 0.00	Radial Wall (S) 3.25 mm +/- 0.10	Groove Width (W) 1.78 mm +/- 0.13
Material: Spring Steel Approx. Loose Clip ID: 45.78 +/- 0.05 Groove Depth (d): 1.30 Category: Retaining Rings - Internal - Spiral Rings - Medium-Heavy Duty - Carbon Steel
Part Number: RRT-193 (8 Pcs) Internal Retaining Rings - 49.23x1.58x51.82 mm - Spring Steel Out of Stock \| Backorder Now \| Orders can be expected around Sun, Jun 08, 2025 Regular price $8.41 AUD Regular price Sale price $8.41 AUD Unit price per Per 8
Housing Bore (B) 49.23 mm _{(1.938 in.)}	Clip Thickness (T) 1.58 mm +/- 0.08 _{(0.062 in.)}	Groove Dia. (Dg) 51.82 mm _{(2.04 in.)}	Approx. Loose Circlip OD (Dr) 52.28 mm + 0.51 / - 0.00
Material: Spring Steel Radial Wall (S): 3.25 mm +/- 0.10 Groove Width (W): 1.78 mm +/- 0.13 Approx. Loose Clip ID: 45.78 +/- 0.05 Groove Depth (d): 1.30 Category: Retaining Rings - Internal - Spiral Rings - Medium-Heavy Duty - Carbon Steel
Part Number: RRT-193 (8 Pcs) Internal Retaining Rings - 49.23x1.58x51.82 mm - Spring Steel Out of Stock \| Backorder Now \| Orders can be expected around Sun, Jun 08, 2025 Regular price $8.41 AUD Regular price Sale price $8.41 AUD Unit price per Per 8 View the product page first if you are unsure.
RRT-193 (8 Pcs) --- Internal Retaining Rings - 49.23x1.58x51.82 mm - Spring Steel RRT-193 (8 Pcs) --- Internal Retaining Rings - 49.23x1.58x51.82 mm - Spring Steel Regular price $8.41 AUD Regular price Sale price $8.41 AUD Unit price per Out of stock! Backorder Now
Housing Bore (B) 50.80 mm _{(2 in.)}	Clip Thickness (T) 1.58 mm +/- 0.08 _{(0.062 in.)}	Groove Dia. (Dg) 53.60 mm _{(2.11 in.)}	Approx. Loose Circlip OD (Dr) 53.95 mm + 0.51 / - 0.00	Radial Wall (S) 3.51 mm +/- 0.11	Groove Width (W) 1.78 mm +/- 0.13
Material: Spring Steel Approx. Loose Clip ID: 46.93 +/- 0.05 Groove Depth (d): 1.40 Category: Retaining Rings - Internal - Spiral Rings - Medium-Heavy Duty - Carbon Steel
Part Number: RRT-200 Internal Retaining Rings - 50.8x1.58x53.6 mm - Spring Steel Out of Stock \| Backorder Now \| Orders can be expected around Sun, Jun 08, 2025 Regular price $8.41 AUD Regular price Sale price $8.41 AUD Unit price per Each
Housing Bore (B) 50.80 mm _{(2 in.)}	Clip Thickness (T) 1.58 mm +/- 0.08 _{(0.062 in.)}	Groove Dia. (Dg) 53.60 mm _{(2.11 in.)}	Approx. Loose Circlip OD (Dr) 53.95 mm + 0.51 / - 0.00
Material: Spring Steel Radial Wall (S): 3.51 mm +/- 0.11 Groove Width (W): 1.78 mm +/- 0.13 Approx. Loose Clip ID: 46.93 +/- 0.05 Groove Depth (d): 1.40 Category: Retaining Rings - Internal - Spiral Rings - Medium-Heavy Duty - Carbon Steel
Part Number: RRT-200 Internal Retaining Rings - 50.8x1.58x53.6 mm - Spring Steel Out of Stock \| Backorder Now \| Orders can be expected around Sun, Jun 08, 2025 Regular price $8.41 AUD Regular price Sale price $8.41 AUD Unit price per Each View the product page first if you are unsure.
RRT-200 --- Internal Retaining Rings - 50.8x1.58x53.6 mm - Spring Steel RRT-200 --- Internal Retaining Rings - 50.8x1.58x53.6 mm - Spring Steel Regular price $8.41 AUD Regular price Sale price $8.41 AUD Unit price per Out of stock! Backorder Now
Housing Bore (B) 57.15 mm _{(2.25 in.)}	Clip Thickness (T) 1.99 mm +/- 0.08 _{(0.078 in.)}	Groove Dia. (Dg) 60.20 mm _{(2.37 in.)}	Approx. Loose Circlip OD (Dr) 60.69 mm + 0.64 / - 0.00	Radial Wall (S) 3.58 mm +/- 0.10	Groove Width (W) 2.25 mm +/- 0.15
Material: Spring Steel Approx. Loose Clip ID: 53.53 +/- 0.06 Groove Depth (d): 1.52 Category: Retaining Rings - Internal - Spiral Rings - Medium-Heavy Duty - Carbon Steel
Part Number: RRT-225 (2 Pcs) Internal Retaining Rings - 57.15x1.99x60.2 mm - Spring Steel 6 units (12 pcs) Available Immediately \| Further orders can be expected around Fri, Jun 20, 2025 Regular price $17.68 AUD Regular price Sale price $17.68 AUD Unit price per Per 2
Housing Bore (B) 57.15 mm _{(2.25 in.)}	Clip Thickness (T) 1.99 mm +/- 0.08 _{(0.078 in.)}	Groove Dia. (Dg) 60.20 mm _{(2.37 in.)}	Approx. Loose Circlip OD (Dr) 60.69 mm + 0.64 / - 0.00
Material: Spring Steel Radial Wall (S): 3.58 mm +/- 0.10 Groove Width (W): 2.25 mm +/- 0.15 Approx. Loose Clip ID: 53.53 +/- 0.06 Groove Depth (d): 1.52 Category: Retaining Rings - Internal - Spiral Rings - Medium-Heavy Duty - Carbon Steel
Part Number: RRT-225 (2 Pcs) Internal Retaining Rings - 57.15x1.99x60.2 mm - Spring Steel 6 units (12 pcs) Available Immediately \| Further orders can be expected around Fri, Jun 20, 2025 Regular price $17.68 AUD Regular price Sale price $17.68 AUD Unit price per Per 2 View the product page first if you are unsure.
RRT-225 (2 Pcs) --- Internal Retaining Rings - 57.15x1.99x60.2 mm - Spring Steel RRT-225 (2 Pcs) --- Internal Retaining Rings - 57.15x1.99x60.2 mm - Spring Steel Regular price $17.68 AUD Regular price Sale price $17.68 AUD Unit price per 6 Available Now
Housing Bore (B) 60.33 mm _{(2.375 in.)}	Clip Thickness (T) 1.99 mm +/- 0.08 _{(0.078 in.)}	Groove Dia. (Dg) 63.63 mm _{(2.505 in.)}	Approx. Loose Circlip OD (Dr) 64.07 mm + 0.64 / - 0.00	Radial Wall (S) 4.78 mm +/- 0.13	Groove Width (W) 2.25 mm +/- 0.16
Material: Spring Steel Approx. Loose Clip ID: 54.51 +/- 0.06 Groove Depth (d): 1.65 Category: Retaining Rings - Internal - Spiral Rings - Medium-Heavy Duty - Carbon Steel
Part Number: RRT-237 (8 Pcs) Internal Retaining Rings - 60.33x1.99x63.63 mm - Spring Steel Out of Stock \| Backorder Now \| Orders can be expected around Sun, Jun 08, 2025 Regular price $12.86 AUD Regular price Sale price $12.86 AUD Unit price per Per 8
Housing Bore (B) 60.33 mm _{(2.375 in.)}	Clip Thickness (T) 1.99 mm +/- 0.08 _{(0.078 in.)}	Groove Dia. (Dg) 63.63 mm _{(2.505 in.)}	Approx. Loose Circlip OD (Dr) 64.07 mm + 0.64 / - 0.00
Material: Spring Steel Radial Wall (S): 4.78 mm +/- 0.13 Groove Width (W): 2.25 mm +/- 0.16 Approx. Loose Clip ID: 54.51 +/- 0.06 Groove Depth (d): 1.65 Category: Retaining Rings - Internal - Spiral Rings - Medium-Heavy Duty - Carbon Steel
Part Number: RRT-237 (8 Pcs) Internal Retaining Rings - 60.33x1.99x63.63 mm - Spring Steel Out of Stock \| Backorder Now \| Orders can be expected around Sun, Jun 08, 2025 Regular price $12.86 AUD Regular price Sale price $12.86 AUD Unit price per Per 8 View the product page first if you are unsure.
RRT-237 (8 Pcs) --- Internal Retaining Rings - 60.33x1.99x63.63 mm - Spring Steel RRT-237 (8 Pcs) --- Internal Retaining Rings - 60.33x1.99x63.63 mm - Spring Steel Regular price $12.86 AUD Regular price Sale price $12.86 AUD Unit price per Out of stock! Backorder Now
Housing Bore (B) 63.50 mm _{(2.5 in.)}	Clip Thickness (T) 1.99 mm +/- 0.08 _{(0.078 in.)}	Groove Dia. (Dg) 66.93 mm _{(2.635 in.)}	Approx. Loose Circlip OD (Dr) 67.44 mm + 0.64 / - 0.00	Radial Wall (S) 4.78 mm +/- 0.13	Groove Width (W) 2.25 mm +/- 0.15
Material: Spring Steel Approx. Loose Clip ID: 57.88 +/- 0.06 Groove Depth (d): 1.73 Category: Retaining Rings - Internal - Spiral Rings - Medium-Heavy Duty - Carbon Steel
Part Number: RRT-250 (40 Pcs) Internal Retaining Rings - 63.5x1.99x66.93 mm - Spring Steel Out of Stock \| Backorder Now \| Orders can be expected around Sun, Jun 08, 2025 Regular price $9.86 AUD Regular price Sale price $9.86 AUD Unit price per Per 40
Housing Bore (B) 63.50 mm _{(2.5 in.)}	Clip Thickness (T) 1.99 mm +/- 0.08 _{(0.078 in.)}	Groove Dia. (Dg) 66.93 mm _{(2.635 in.)}	Approx. Loose Circlip OD (Dr) 67.44 mm + 0.64 / - 0.00
Material: Spring Steel Radial Wall (S): 4.78 mm +/- 0.13 Groove Width (W): 2.25 mm +/- 0.15 Approx. Loose Clip ID: 57.88 +/- 0.06 Groove Depth (d): 1.73 Category: Retaining Rings - Internal - Spiral Rings - Medium-Heavy Duty - Carbon Steel
Part Number: RRT-250 (40 Pcs) Internal Retaining Rings - 63.5x1.99x66.93 mm - Spring Steel Out of Stock \| Backorder Now \| Orders can be expected around Sun, Jun 08, 2025 Regular price $9.86 AUD Regular price Sale price $9.86 AUD Unit price per Per 40 View the product page first if you are unsure.
RRT-250 (40 Pcs) --- Internal Retaining Rings - 63.5x1.99x66.93 mm - Spring Steel RRT-250 (40 Pcs) --- Internal Retaining Rings - 63.5x1.99x66.93 mm - Spring Steel Regular price $9.86 AUD Regular price Sale price $9.86 AUD Unit price per Out of stock! Backorder Now
Housing Bore (B) 69.85 mm _{(2.75 in.)}	Clip Thickness (T) 2.37 mm +/- 0.08 _{(0.093 in.)}	Groove Dia. (Dg) 73.66 mm _{(2.9 in.)}	Approx. Loose Circlip OD (Dr) 74.18 mm + 0.64 / - 0.00	Radial Wall (S) 4.78 mm +/- 0.13	Groove Width (W) 2.68 mm +/- 0.15
Material: Spring Steel Approx. Loose Clip ID: 64.62 +/- 0.06 Groove Depth (d): 1.91 Category: Retaining Rings - Internal - Spiral Rings - Medium-Heavy Duty - Carbon Steel
Part Number: RRT-275 Internal Retaining Rings - 69.85x2.37x73.66 mm - Spring Steel Out of Stock \| Backorder Now \| Orders can be expected around Sun, Jun 08, 2025 Regular price $3.86 AUD Regular price Sale price $3.86 AUD Unit price per Each
Housing Bore (B) 69.85 mm _{(2.75 in.)}	Clip Thickness (T) 2.37 mm +/- 0.08 _{(0.093 in.)}	Groove Dia. (Dg) 73.66 mm _{(2.9 in.)}	Approx. Loose Circlip OD (Dr) 74.18 mm + 0.64 / - 0.00
Material: Spring Steel Radial Wall (S): 4.78 mm +/- 0.13 Groove Width (W): 2.68 mm +/- 0.15 Approx. Loose Clip ID: 64.62 +/- 0.06 Groove Depth (d): 1.91 Category: Retaining Rings - Internal - Spiral Rings - Medium-Heavy Duty - Carbon Steel
Part Number: RRT-275 Internal Retaining Rings - 69.85x2.37x73.66 mm - Spring Steel Out of Stock \| Backorder Now \| Orders can be expected around Sun, Jun 08, 2025 Regular price $3.86 AUD Regular price Sale price $3.86 AUD Unit price per Each View the product page first if you are unsure.
RRT-275 --- Internal Retaining Rings - 69.85x2.37x73.66 mm - Spring Steel RRT-275 --- Internal Retaining Rings - 69.85x2.37x73.66 mm - Spring Steel Regular price $3.86 AUD Regular price Sale price $3.86 AUD Unit price per Out of stock! Backorder Now
Housing Bore (B) 71.98 mm _{(2.834 in.)}	Clip Thickness (T) 2.37 mm +/- 0.08 _{(0.093 in.)}	Groove Dia. (Dg) 75.87 mm _{(2.987 in.)}	Approx. Loose Circlip OD (Dr) 76.44 mm + 0.64 / - 0.00	Radial Wall (S) 4.78 mm +/- 0.13	Groove Width (W) 2.68 mm +/- 0.15
Material: Spring Steel Approx. Loose Clip ID: 66.88 +/- 0.06 Groove Depth (d): 1.96 Category: Retaining Rings - Internal - Spiral Rings - Medium-Heavy Duty - Carbon Steel
Part Number: RRT-283 Internal Retaining Rings - 71.98x2.37x75.87 mm - Spring Steel Out of Stock \| Backorder Now \| Orders can be expected around Sun, Jun 08, 2025 Regular price $24.05 AUD Regular price Sale price $24.05 AUD Unit price per Each
Housing Bore (B) 71.98 mm _{(2.834 in.)}	Clip Thickness (T) 2.37 mm +/- 0.08 _{(0.093 in.)}	Groove Dia. (Dg) 75.87 mm _{(2.987 in.)}	Approx. Loose Circlip OD (Dr) 76.44 mm + 0.64 / - 0.00
Material: Spring Steel Radial Wall (S): 4.78 mm +/- 0.13 Groove Width (W): 2.68 mm +/- 0.15 Approx. Loose Clip ID: 66.88 +/- 0.06 Groove Depth (d): 1.96 Category: Retaining Rings - Internal - Spiral Rings - Medium-Heavy Duty - Carbon Steel
Part Number: RRT-283 Internal Retaining Rings - 71.98x2.37x75.87 mm - Spring Steel Out of Stock \| Backorder Now \| Orders can be expected around Sun, Jun 08, 2025 Regular price $24.05 AUD Regular price Sale price $24.05 AUD Unit price per Each View the product page first if you are unsure.
RRT-283 --- Internal Retaining Rings - 71.98x2.37x75.87 mm - Spring Steel RRT-283 --- Internal Retaining Rings - 71.98x2.37x75.87 mm - Spring Steel Regular price $24.05 AUD Regular price Sale price $24.05 AUD Unit price per Out of stock! Backorder Now
Housing Bore (B) 76.20 mm _{(3 in.)}	Clip Thickness (T) 2.37 mm +/- 0.08 _{(0.093 in.)}	Groove Dia. (Dg) 80.39 mm _{(3.165 in.)}	Approx. Loose Circlip OD (Dr) 80.92 mm + 0.76 / - 0.00	Radial Wall (S) 4.78 mm +/- 0.13	Groove Width (W) 2.68 mm +/- 0.15
Material: Spring Steel Approx. Loose Clip ID: 71.36 +/- 0.06 Groove Depth (d): 2.11 Category: Retaining Rings - Internal - Spiral Rings - Medium-Heavy Duty - Carbon Steel
Part Number: RRT-300 (8 Pcs) Internal Retaining Rings - 76.2x2.37x80.39 mm - Spring Steel Out of Stock \| Backorder Now \| Orders can be expected around Sun, Jun 08, 2025 Regular price $12.05 AUD Regular price Sale price $12.05 AUD Unit price per Per 8
Housing Bore (B) 76.20 mm _{(3 in.)}	Clip Thickness (T) 2.37 mm +/- 0.08 _{(0.093 in.)}	Groove Dia. (Dg) 80.39 mm _{(3.165 in.)}	Approx. Loose Circlip OD (Dr) 80.92 mm + 0.76 / - 0.00
Material: Spring Steel Radial Wall (S): 4.78 mm +/- 0.13 Groove Width (W): 2.68 mm +/- 0.15 Approx. Loose Clip ID: 71.36 +/- 0.06 Groove Depth (d): 2.11 Category: Retaining Rings - Internal - Spiral Rings - Medium-Heavy Duty - Carbon Steel
Part Number: RRT-300 (8 Pcs) Internal Retaining Rings - 76.2x2.37x80.39 mm - Spring Steel Out of Stock \| Backorder Now \| Orders can be expected around Sun, Jun 08, 2025 Regular price $12.05 AUD Regular price Sale price $12.05 AUD Unit price per Per 8 View the product page first if you are unsure.
RRT-300 (8 Pcs) --- Internal Retaining Rings - 76.2x2.37x80.39 mm - Spring Steel RRT-300 (8 Pcs) --- Internal Retaining Rings - 76.2x2.37x80.39 mm - Spring Steel Regular price $12.05 AUD Regular price Sale price $12.05 AUD Unit price per Out of stock! Backorder Now
Housing Bore (B) 101.60 mm _{(4 in.)}	Clip Thickness (T) 2.82 mm +/- 0.08 _{(0.111 in.)}	Groove Dia. (Dg) 107.19 mm _{(4.22 in.)}	Approx. Loose Circlip OD (Dr) 107.90 mm + 0.76 / - 0.00	Radial Wall (S) 6.35 mm +/- 0.13	Groove Width (W) 3.12 mm +/- 0.15
Material: Spring Steel Approx. Loose Clip ID: 95.2 +/- 0.07 Groove Depth (d): 2.79 Category: Retaining Rings - Internal - Spiral Rings - Medium-Heavy Duty - Carbon Steel
Part Number: RRT-400 (42 Pcs) Internal Retaining Rings - 101.6x2.82x107.19 mm - Spring Steel Out of Stock \| Backorder Now \| Orders can be expected around Sun, Jun 08, 2025 Regular price $15.68 AUD Regular price Sale price $15.68 AUD Unit price per Per 42
Housing Bore (B) 101.60 mm _{(4 in.)}	Clip Thickness (T) 2.82 mm +/- 0.08 _{(0.111 in.)}	Groove Dia. (Dg) 107.19 mm _{(4.22 in.)}	Approx. Loose Circlip OD (Dr) 107.90 mm + 0.76 / - 0.00
Material: Spring Steel Radial Wall (S): 6.35 mm +/- 0.13 Groove Width (W): 3.12 mm +/- 0.15 Approx. Loose Clip ID: 95.2 +/- 0.07 Groove Depth (d): 2.79 Category: Retaining Rings - Internal - Spiral Rings - Medium-Heavy Duty - Carbon Steel
Part Number: RRT-400 (42 Pcs) Internal Retaining Rings - 101.6x2.82x107.19 mm - Spring Steel Out of Stock \| Backorder Now \| Orders can be expected around Sun, Jun 08, 2025 Regular price $15.68 AUD Regular price Sale price $15.68 AUD Unit price per Per 42 View the product page first if you are unsure.
RRT-400 (42 Pcs) --- Internal Retaining Rings - 101.6x2.82x107.19 mm - Spring Steel RRT-400 (42 Pcs) --- Internal Retaining Rings - 101.6x2.82x107.19 mm - Spring Steel Regular price $15.68 AUD Regular price Sale price $15.68 AUD Unit price per Out of stock! Backorder Now
Housing Bore (B) 107.95 mm _{(4.25 in.)}	Clip Thickness (T) 2.82 mm +/- 0.08 _{(0.111 in.)}	Groove Dia. (Dg) 113.54 mm _{(4.47 in.)}	Approx. Loose Circlip OD (Dr) 114.64 mm + 0.89 / - 0.00	Radial Wall (S) 7.93 mm +/- 0.16	Groove Width (W) 3.12 mm +/- 0.15
Material: Spring Steel Approx. Loose Clip ID: 98.78 +/- 0.07 Groove Depth (d): 2.79 Category: Retaining Rings - Internal - Spiral Rings - Medium-Heavy Duty - Carbon Steel
Part Number: RRT-425 Internal Retaining Rings - 107.95x2.82x113.54 mm - Spring Steel Out of Stock \| Backorder Now \| Orders can be expected around Sun, Jun 08, 2025 Regular price $12.77 AUD Regular price Sale price $12.77 AUD Unit price per Each
Housing Bore (B) 107.95 mm _{(4.25 in.)}	Clip Thickness (T) 2.82 mm +/- 0.08 _{(0.111 in.)}	Groove Dia. (Dg) 113.54 mm _{(4.47 in.)}	Approx. Loose Circlip OD (Dr) 114.64 mm + 0.89 / - 0.00
Material: Spring Steel Radial Wall (S): 7.93 mm +/- 0.16 Groove Width (W): 3.12 mm +/- 0.15 Approx. Loose Clip ID: 98.78 +/- 0.07 Groove Depth (d): 2.79 Category: Retaining Rings - Internal - Spiral Rings - Medium-Heavy Duty - Carbon Steel
Part Number: RRT-425 Internal Retaining Rings - 107.95x2.82x113.54 mm - Spring Steel Out of Stock \| Backorder Now \| Orders can be expected around Sun, Jun 08, 2025 Regular price $12.77 AUD Regular price Sale price $12.77 AUD Unit price per Each View the product page first if you are unsure.
RRT-425 --- Internal Retaining Rings - 107.95x2.82x113.54 mm - Spring Steel RRT-425 --- Internal Retaining Rings - 107.95x2.82x113.54 mm - Spring Steel Regular price $12.77 AUD Regular price Sale price $12.77 AUD Unit price per Out of stock! Backorder Now
Housing Bore (B) 146.05 mm _{(5.75 in.)}	Clip Thickness (T) 3.23 mm +/- 0.11 _{(0.127 in.)}	Groove Dia. (Dg) 152.91 mm _{(6.02 in.)}	Approx. Loose Circlip OD (Dr) 155.11 mm + 1.02 / - 0.00	Radial Wall (S) 9.53 mm +/- 0.16	Groove Width (W) 3.61 mm +/- 0.18
Material: Spring Steel Approx. Loose Clip ID: 136.05 +/- 0.08 Groove Depth (d): 3.43 Category: Retaining Rings - Internal - Spiral Rings - Medium-Heavy Duty - Carbon Steel
Part Number: RRT-575 Internal Retaining Rings - 146.05x3.23x152.91 mm - Spring Steel Out of Stock \| Backorder Now \| Orders can be expected around Sun, Jun 08, 2025 Regular price $34.05 AUD Regular price Sale price $34.05 AUD Unit price per Each
Housing Bore (B) 146.05 mm _{(5.75 in.)}	Clip Thickness (T) 3.23 mm +/- 0.11 _{(0.127 in.)}	Groove Dia. (Dg) 152.91 mm _{(6.02 in.)}	Approx. Loose Circlip OD (Dr) 155.11 mm + 1.02 / - 0.00
Material: Spring Steel Radial Wall (S): 9.53 mm +/- 0.16 Groove Width (W): 3.61 mm +/- 0.18 Approx. Loose Clip ID: 136.05 +/- 0.08 Groove Depth (d): 3.43 Category: Retaining Rings - Internal - Spiral Rings - Medium-Heavy Duty - Carbon Steel
Part Number: RRT-575 Internal Retaining Rings - 146.05x3.23x152.91 mm - Spring Steel Out of Stock \| Backorder Now \| Orders can be expected around Sun, Jun 08, 2025 Regular price $34.05 AUD Regular price Sale price $34.05 AUD Unit price per Each View the product page first if you are unsure.
RRT-575 --- Internal Retaining Rings - 146.05x3.23x152.91 mm - Spring Steel RRT-575 --- Internal Retaining Rings - 146.05x3.23x152.91 mm - Spring Steel Regular price $34.05 AUD Regular price Sale price $34.05 AUD Unit price per Out of stock! Backorder Now
Housing Bore (B) 177.80 mm _{(7 in.)}	Clip Thickness (T) 4.19 mm +/- 0.13 _{(0.165 in.)}	Groove Dia. (Dg) 185.80 mm _{(7.315 in.)}	Approx. Loose Circlip OD (Dr) 188.82 mm + 1.40 / - 0.00	Radial Wall (S) 7.93 mm +/- 0.16	Groove Width (W) 4.52 mm +/- 0.20
Material: Spring Steel Approx. Loose Clip ID: 172.96 +/- 0.10 Groove Depth (d): 4.01 Category: Retaining Rings - Internal - Spiral Rings - Medium-Heavy Duty - Carbon Steel
Part Number: RRT-700 (2 Pcs) Internal Retaining Rings - 177.8x4.19x185.8 mm - Spring Steel Out of Stock \| Backorder Now \| Orders can be expected around Sun, Jun 08, 2025 Regular price $24.05 AUD Regular price Sale price $24.05 AUD Unit price per Per 2
Housing Bore (B) 177.80 mm _{(7 in.)}	Clip Thickness (T) 4.19 mm +/- 0.13 _{(0.165 in.)}	Groove Dia. (Dg) 185.80 mm _{(7.315 in.)}	Approx. Loose Circlip OD (Dr) 188.82 mm + 1.40 / - 0.00
Material: Spring Steel Radial Wall (S): 7.93 mm +/- 0.16 Groove Width (W): 4.52 mm +/- 0.20 Approx. Loose Clip ID: 172.96 +/- 0.10 Groove Depth (d): 4.01 Category: Retaining Rings - Internal - Spiral Rings - Medium-Heavy Duty - Carbon Steel
Part Number: RRT-700 (2 Pcs) Internal Retaining Rings - 177.8x4.19x185.8 mm - Spring Steel Out of Stock \| Backorder Now \| Orders can be expected around Sun, Jun 08, 2025 Regular price $24.05 AUD Regular price Sale price $24.05 AUD Unit price per Per 2 View the product page first if you are unsure.
RRT-700 (2 Pcs) --- Internal Retaining Rings - 177.8x4.19x185.8 mm - Spring Steel RRT-700 (2 Pcs) --- Internal Retaining Rings - 177.8x4.19x185.8 mm - Spring Steel Regular price $24.05 AUD Regular price Sale price $24.05 AUD Unit price per Out of stock! Backorder Now
