S623-CSN-ZZS-T9H-AF12 (200 Pcs)

Base Category: Bearings - Single Row Ball

Top Level Category: Bearings - Single Row Ball - Unflanged - Precision - Ceramic Hybrid

Product Details

High speed polyamide cage. Ceramic balls.

ID (d): 3.000mm
_{+ 0.000 / - 0.0075
(3.000mm is 0.118 in.)}

Stainless Steel AISI 440C - High Speed Polyamide Cage

• ID (d): 3.000mm
  _{+ 0.000 / - 0.0075
  (3.000mm is 0.118 in.)}

• OD (D): 10.000mm
  _{+ 0.000 / - 0.0075
  (10.000mm is 0.394 in.)}

• Width (B): 4.000mm
  _{+ 0.000 / - 0.125
  (4.000mm is 0.157 in.)}

• Precision Grade: Abec 1
• Closure Type: ZZS
• Bearing Type: Radial

Brand: MBA
Country of Origin: TW

Product Compliance and Data

• Full Data Sheet
• RoHs Statement
• Reach Statement
• CoC Information

Similar to

• W.H. 01577000
• Abu Garcia 3x10x3 Bush (May be able to use 3x10x4 Bearing)
• Shielded S623 / 4
• Shielded SS623 / 4
• S623CSNT9HZZSAF12
• SS623CSNT9HZZSAF12
• 623BASIC

Used for

• Dental Handpiece Parts
• Fishing Reel Parts
• RC Helicopter Parts
• Gamborini - MKT - MKQ - MKS - Rear Armature Bearing
• Muss - Micromat-Athlet Type H240B Motor - Bearing 3-10-4mm
• W.H. - Straight Handpiece 6000 RPM - Cap End Bearing
• Abu Garcia - 6500C - 6500C3 - Spool Bearing 3-10-4mm Check Size
• Abu Garcia - 7000 - Spool Bearing 3-10-4mm
• Shimano - Bantam 10X - Spool Bearing 3-10-4mm Right Side
• Shimano - Bass One - Spool Bearing 3-10-4mm Outside
• Shimano - Calais CL200 / CL200-5 - Spool Bearing 3-10-4mm Both Sides
• Shimano - Calcutta 50-100-150-200-250-251-400-600 - Bearing 3-10-4mm
• Shimano - Chronarch 100SF - Spool Bearing 3-10-4mm
• Shimano - Curado 200 - Bearing 3-10-4mm
• Align - Trex 600 CF - Bearing 3-10-4mm
• Bergen Machine - Intrepid 60 - Bearing 3-10-4mm
• Bergen Machine - Intrepid Gas - Bearing 3-10-4mm
• Century - Hawk II - Bearing 3-10-4mm
• Century - Hawk II Upgrade Kit - Bearing 3-10-4mm
• Century - Hawk Sport All - Bearing 3-10-4mm
• Century - Hawk Sport Upgrade Only - Bearing 3-10-4mm
• JR - Ergo 30/46 Complete Kit - Bearing 3-10-4mm
• JR - Ergo 30/46 Upgrade Kit - Bearing 3-10-4mm
• Mikado - Logo 10 - Bearing 3-10-4mm
• Mikado - Logo 10 3D Version - Bearing 3-10-4mm
• Mikado - Logo 20 - Bearing 3-10-4mm
• Miniature Aircraft - X-Cell 30-40 Upgrade Kit - Bearing 3-10-4mm
• Miniature Aircraft - X-Cell30-40 Upgrade Kit New - Bearing 3-10-4mm
• Schluter - Millenium 60 Upgrade Kit - Bearing 3-10-4mm

We offer equivalents to many brands including Anderton, Barden, Berg, Designatronics, EZO, ISC, Koyo, Myonic, NMB, Nordex, NSK, Ondrives, Reid Industrial, RMB, SDP-SI, Seeger, SKF, and more.
