Collection: Washers - Disc Spring - Standard - Stainless Steel

Washers (With Images)

Disc Spring

Standard

Carbon Steel
Plastic
Stainless Steel

106 Products in this selection

Includes disc springs to DIN 2093 and belleville washers to DIN 6796.
Manufactured under strict quality control to conform to DIN 2093

Additional resources:
Disc Spring Washers PDF
Screws

A more concise listing may be found on the Smallparts store at Washers - Disc Spring - Standard - Stainless Steel. Smallparts promote the most popular MBA products.

Nominal OD (A)	Nominal ID (B)	Stock Thickness (C)	Load to flatten	Loaded Height (L1)	Load at L1	Indicative Image
Nominal OD (A) 70.00 mm _{(2.756 in.)}	Nominal ID (B) 25.00 mm + 0.40 / - 0.00 _{(0.984 in.)}	Stock Thickness (C) 2.00 mm _{(0.079 in.)}		Loaded Height (L1) 2.63 mm	Load at L1 444.0 kg
Material: Stainless Steel 17-7 PH Free Height (E): 4.50 mm Actual ID (Ref): 25.5 mm Inside Height (D): 2.50 mm
Part Number: W0250-D-070-020-S17 (5 Pcs) Disc Spring Washers - 70x25x2 mm - Stainless Steel 17-7 PH Out of Stock \| Backorder Now \| Orders can be expected around Thu, Jul 24, 2025 Regular price $206.50 AUD Regular price Sale price $206.50 AUD Unit price per Per 5
Nominal OD (A)	Nominal ID (B)	Stock Thickness (C)	Load to flatten	Indicative Image
Nominal OD (A) 70.00 mm _{(2.756 in.)}	Nominal ID (B) 25.00 mm + 0.40 / - 0.00 _{(0.984 in.)}	Stock Thickness (C) 2.00 mm _{(0.079 in.)}
Material: Stainless Steel 17-7 PH Loaded Height (L1): 2.63 mm Load at L1: 444.0 kg Free Height (E): 4.50 mm Actual ID (Ref): 25.5 mm Inside Height (D): 2.50 mm
Part Number: W0250-D-070-020-S17 (5 Pcs) Disc Spring Washers - 70x25x2 mm - Stainless Steel 17-7 PH Out of Stock \| Backorder Now \| Orders can be expected around Thu, Jul 24, 2025 Regular price $206.50 AUD Regular price Sale price $206.50 AUD Unit price per Per 5 View the product page first if you are unsure.
W0250-D-070-020-S17 (5 Pcs) --- Disc Spring Washers - 70x25x2 mm - Stainless Steel 17-7 PH W0250-D-070-020-S17 (5 Pcs) --- Disc Spring Washers - 70x25x2 mm - Stainless Steel 17-7 PH Regular price $206.50 AUD Regular price Sale price $206.50 AUD Unit price per Out of stock! Backorder Now
Nominal OD (A) 70.00 mm _{(2.756 in.)}	Nominal ID (B) 35.00 mm + 0.50 / - 0.00 _{(1.378 in.)}	Stock Thickness (C) 4.00 mm _{(0.157 in.)}		Loaded Height (L1) 4.45 mm	Load at L1 2391.0 kg
Material: Stainless Steel 17-7 PH Free Height (E): 5.80 mm Actual ID (Ref): 35.5 mm Inside Height (D): 1.80 mm
Part Number: W0350-D-070-040-S17 (5 Pcs) Disc Spring Washers - 70x35x4 mm - Stainless Steel 17-7 PH Out of Stock \| Backorder Now \| Orders can be expected around Thu, Jul 24, 2025 Regular price $233.95 AUD Regular price Sale price $233.95 AUD Unit price per Per 5
Nominal OD (A) 70.00 mm _{(2.756 in.)}	Nominal ID (B) 35.00 mm + 0.50 / - 0.00 _{(1.378 in.)}	Stock Thickness (C) 4.00 mm _{(0.157 in.)}
Material: Stainless Steel 17-7 PH Loaded Height (L1): 4.45 mm Load at L1: 2391.0 kg Free Height (E): 5.80 mm Actual ID (Ref): 35.5 mm Inside Height (D): 1.80 mm
Part Number: W0350-D-070-040-S17 (5 Pcs) Disc Spring Washers - 70x35x4 mm - Stainless Steel 17-7 PH Out of Stock \| Backorder Now \| Orders can be expected around Thu, Jul 24, 2025 Regular price $233.95 AUD Regular price Sale price $233.95 AUD Unit price per Per 5 View the product page first if you are unsure.
W0350-D-070-040-S17 (5 Pcs) --- Disc Spring Washers - 70x35x4 mm - Stainless Steel 17-7 PH W0350-D-070-040-S17 (5 Pcs) --- Disc Spring Washers - 70x35x4 mm - Stainless Steel 17-7 PH Regular price $233.95 AUD Regular price Sale price $233.95 AUD Unit price per Out of stock! Backorder Now
Nominal OD (A) 70.00 mm _{(2.756 in.)}	Nominal ID (B) 40.00 mm + 0.50 / - 0.00 _{(1.575 in.)}	Stock Thickness (C) 4.00 mm _{(0.157 in.)}		Loaded Height (L1) 4.40 mm	Load at L1 2334.0 kg
Material: Stainless Steel 17-7 PH Free Height (E): 5.60 mm Actual ID (Ref): 40.5 mm Inside Height (D): 1.60 mm
Part Number: W0400-D-070-040-S17 (5 Pcs) Disc Spring Washers - 70x40x4 mm - Stainless Steel 17-7 PH Out of Stock \| Backorder Now \| Orders can be expected around Fri, Jul 25, 2025 Regular price $95.14 AUD Regular price Sale price $95.14 AUD Unit price per Per 5
Nominal OD (A) 70.00 mm _{(2.756 in.)}	Nominal ID (B) 40.00 mm + 0.50 / - 0.00 _{(1.575 in.)}	Stock Thickness (C) 4.00 mm _{(0.157 in.)}
Material: Stainless Steel 17-7 PH Loaded Height (L1): 4.40 mm Load at L1: 2334.0 kg Free Height (E): 5.60 mm Actual ID (Ref): 40.5 mm Inside Height (D): 1.60 mm
Part Number: W0400-D-070-040-S17 (5 Pcs) Disc Spring Washers - 70x40x4 mm - Stainless Steel 17-7 PH Out of Stock \| Backorder Now \| Orders can be expected around Fri, Jul 25, 2025 Regular price $95.14 AUD Regular price Sale price $95.14 AUD Unit price per Per 5 View the product page first if you are unsure.
W0400-D-070-040-S17 (5 Pcs) --- Disc Spring Washers - 70x40x4 mm - Stainless Steel 17-7 PH W0400-D-070-040-S17 (5 Pcs) --- Disc Spring Washers - 70x40x4 mm - Stainless Steel 17-7 PH Regular price $95.14 AUD Regular price Sale price $95.14 AUD Unit price per Out of stock! Backorder Now
Nominal OD (A) 71.00 mm _{(2.795 in.)}	Nominal ID (B) 35.00 mm + 1.00 / - 0.00 _{(1.378 in.)}	Stock Thickness (C) 2.00 mm _{(0.079 in.)}		Loaded Height (L1) 2.65 mm	Load at L1 541.0 kg
Material: Stainless Steel 17-7 PH Free Height (E): 4.60 mm Actual ID (Ref): 36.0 mm Inside Height (D): 2.60 mm
Part Number: W0360-D-071-020-S17 (5 Pcs) Disc Spring Washers - 71x35x2 mm - Stainless Steel 17-7 PH Out of Stock \| Backorder Now \| Orders can be expected around Thu, Jul 24, 2025 Regular price $274.50 AUD Regular price Sale price $274.50 AUD Unit price per Per 5
Nominal OD (A) 71.00 mm _{(2.795 in.)}	Nominal ID (B) 35.00 mm + 1.00 / - 0.00 _{(1.378 in.)}	Stock Thickness (C) 2.00 mm _{(0.079 in.)}
Material: Stainless Steel 17-7 PH Loaded Height (L1): 2.65 mm Load at L1: 541.0 kg Free Height (E): 4.60 mm Actual ID (Ref): 36.0 mm Inside Height (D): 2.60 mm
Part Number: W0360-D-071-020-S17 (5 Pcs) Disc Spring Washers - 71x35x2 mm - Stainless Steel 17-7 PH Out of Stock \| Backorder Now \| Orders can be expected around Thu, Jul 24, 2025 Regular price $274.50 AUD Regular price Sale price $274.50 AUD Unit price per Per 5 View the product page first if you are unsure.
W0360-D-071-020-S17 (5 Pcs) --- Disc Spring Washers - 71x35x2 mm - Stainless Steel 17-7 PH W0360-D-071-020-S17 (5 Pcs) --- Disc Spring Washers - 71x35x2 mm - Stainless Steel 17-7 PH Regular price $274.50 AUD Regular price Sale price $274.50 AUD Unit price per Out of stock! Backorder Now
Nominal OD (A) 71.00 mm _{(2.795 in.)}	Nominal ID (B) 35.00 mm + 1.00 / - 0.00 _{(1.378 in.)}	Stock Thickness (C) 2.50 mm _{(0.098 in.)}		Loaded Height (L1) 3.00 mm	Load at L1 672.0 kg
Material: Stainless Steel 17-7 PH Free Height (E): 4.50 mm Actual ID (Ref): 36.0 mm Inside Height (D): 2.00 mm
Part Number: W0360-D-071-025-S17 (5 Pcs) Disc Spring Washers - 71x35x2.5 mm - Stainless Steel 17-7 PH Out of Stock \| Backorder Now \| Orders can be expected around Thu, Jul 24, 2025 Regular price $274.59 AUD Regular price Sale price $274.59 AUD Unit price per Per 5
Nominal OD (A) 71.00 mm _{(2.795 in.)}	Nominal ID (B) 35.00 mm + 1.00 / - 0.00 _{(1.378 in.)}	Stock Thickness (C) 2.50 mm _{(0.098 in.)}
Material: Stainless Steel 17-7 PH Loaded Height (L1): 3.00 mm Load at L1: 672.0 kg Free Height (E): 4.50 mm Actual ID (Ref): 36.0 mm Inside Height (D): 2.00 mm
Part Number: W0360-D-071-025-S17 (5 Pcs) Disc Spring Washers - 71x35x2.5 mm - Stainless Steel 17-7 PH Out of Stock \| Backorder Now \| Orders can be expected around Thu, Jul 24, 2025 Regular price $274.59 AUD Regular price Sale price $274.59 AUD Unit price per Per 5 View the product page first if you are unsure.
W0360-D-071-025-S17 (5 Pcs) --- Disc Spring Washers - 71x35x2.5 mm - Stainless Steel 17-7 PH W0360-D-071-025-S17 (5 Pcs) --- Disc Spring Washers - 71x35x2.5 mm - Stainless Steel 17-7 PH Regular price $274.59 AUD Regular price Sale price $274.59 AUD Unit price per Out of stock! Backorder Now
Nominal OD (A) 71.00 mm _{(2.795 in.)}	Nominal ID (B) 35.00 mm + 1.00 / - 0.00 _{(1.378 in.)}	Stock Thickness (C) 4.00 mm _{(0.157 in.)}		Loaded Height (L1) 4.40 mm	Load at L1 2052.0 kg
Material: Stainless Steel 17-7 PH Free Height (E): 5.60 mm Actual ID (Ref): 36.0 mm Inside Height (D): 1.60 mm
Part Number: W0360-D-071-040-S17 (5 Pcs) Disc Spring Washers - 71x35x4 mm - Stainless Steel 17-7 PH Out of Stock \| Backorder Now \| Orders can be expected around Thu, Jul 24, 2025 Regular price $308.95 AUD Regular price Sale price $308.95 AUD Unit price per Per 5
Nominal OD (A) 71.00 mm _{(2.795 in.)}	Nominal ID (B) 35.00 mm + 1.00 / - 0.00 _{(1.378 in.)}	Stock Thickness (C) 4.00 mm _{(0.157 in.)}
Material: Stainless Steel 17-7 PH Loaded Height (L1): 4.40 mm Load at L1: 2052.0 kg Free Height (E): 5.60 mm Actual ID (Ref): 36.0 mm Inside Height (D): 1.60 mm
Part Number: W0360-D-071-040-S17 (5 Pcs) Disc Spring Washers - 71x35x4 mm - Stainless Steel 17-7 PH Out of Stock \| Backorder Now \| Orders can be expected around Thu, Jul 24, 2025 Regular price $308.95 AUD Regular price Sale price $308.95 AUD Unit price per Per 5 View the product page first if you are unsure.
W0360-D-071-040-S17 (5 Pcs) --- Disc Spring Washers - 71x35x4 mm - Stainless Steel 17-7 PH W0360-D-071-040-S17 (5 Pcs) --- Disc Spring Washers - 71x35x4 mm - Stainless Steel 17-7 PH Regular price $308.95 AUD Regular price Sale price $308.95 AUD Unit price per Out of stock! Backorder Now
Nominal OD (A) 80.00 mm _{(3.15 in.)}	Nominal ID (B) 40.00 mm + 1.00 / - 0.00 _{(1.575 in.)}	Stock Thickness (C) 2.25 mm _{(0.089 in.)}		Loaded Height (L1) 2.99 mm	Load at L1 661.0 kg
Material: Stainless Steel 17-7 PH Free Height (E): 5.20 mm Actual ID (Ref): 41.0 mm Inside Height (D): 2.95 mm
Part Number: W0410-D-080-023-S17 (5 Pcs) Disc Spring Washers - 80x40x2.25 mm - Stainless Steel 17-7 PH Out of Stock \| Backorder Now \| Orders can be expected around Thu, Jul 24, 2025 Regular price $410.77 AUD Regular price Sale price $410.77 AUD Unit price per Per 5
Nominal OD (A) 80.00 mm _{(3.15 in.)}	Nominal ID (B) 40.00 mm + 1.00 / - 0.00 _{(1.575 in.)}	Stock Thickness (C) 2.25 mm _{(0.089 in.)}
Material: Stainless Steel 17-7 PH Loaded Height (L1): 2.99 mm Load at L1: 661.0 kg Free Height (E): 5.20 mm Actual ID (Ref): 41.0 mm Inside Height (D): 2.95 mm
Part Number: W0410-D-080-023-S17 (5 Pcs) Disc Spring Washers - 80x40x2.25 mm - Stainless Steel 17-7 PH Out of Stock \| Backorder Now \| Orders can be expected around Thu, Jul 24, 2025 Regular price $410.77 AUD Regular price Sale price $410.77 AUD Unit price per Per 5 View the product page first if you are unsure.
W0410-D-080-023-S17 (5 Pcs) --- Disc Spring Washers - 80x40x2.25 mm - Stainless Steel 17-7 PH W0410-D-080-023-S17 (5 Pcs) --- Disc Spring Washers - 80x40x2.25 mm - Stainless Steel 17-7 PH Regular price $410.77 AUD Regular price Sale price $410.77 AUD Unit price per Out of stock! Backorder Now
Nominal OD (A) 80.00 mm _{(3.15 in.)}	Nominal ID (B) 40.00 mm + 1.00 / - 0.00 _{(1.575 in.)}	Stock Thickness (C) 3.00 mm _{(0.118 in.)}		Loaded Height (L1) 3.58 mm	Load at L1 1051.0 kg
Material: Stainless Steel 17-7 PH Free Height (E): 5.30 mm Actual ID (Ref): 41.0 mm Inside Height (D): 2.30 mm
Part Number: W0410-D-080-030-S17 (5 Pcs) Disc Spring Washers - 80x40x3 mm - Stainless Steel 17-7 PH Out of Stock \| Backorder Now \| Orders can be expected around Thu, Jul 24, 2025 Regular price $513.14 AUD Regular price Sale price $513.14 AUD Unit price per Per 5
Nominal OD (A) 80.00 mm _{(3.15 in.)}	Nominal ID (B) 40.00 mm + 1.00 / - 0.00 _{(1.575 in.)}	Stock Thickness (C) 3.00 mm _{(0.118 in.)}
Material: Stainless Steel 17-7 PH Loaded Height (L1): 3.58 mm Load at L1: 1051.0 kg Free Height (E): 5.30 mm Actual ID (Ref): 41.0 mm Inside Height (D): 2.30 mm
Part Number: W0410-D-080-030-S17 (5 Pcs) Disc Spring Washers - 80x40x3 mm - Stainless Steel 17-7 PH Out of Stock \| Backorder Now \| Orders can be expected around Thu, Jul 24, 2025 Regular price $513.14 AUD Regular price Sale price $513.14 AUD Unit price per Per 5 View the product page first if you are unsure.
W0410-D-080-030-S17 (5 Pcs) --- Disc Spring Washers - 80x40x3 mm - Stainless Steel 17-7 PH W0410-D-080-030-S17 (5 Pcs) --- Disc Spring Washers - 80x40x3 mm - Stainless Steel 17-7 PH Regular price $513.14 AUD Regular price Sale price $513.14 AUD Unit price per Out of stock! Backorder Now
Nominal OD (A) 90.00 mm _{(3.543 in.)}	Nominal ID (B) 45.00 mm + 1.00 / - 0.00 _{(1.772 in.)}	Stock Thickness (C) 2.50 mm _{(0.098 in.)}		Loaded Height (L1) 3.30 mm	Load at L1 768.0 kg
Material: Stainless Steel 17-7 PH Free Height (E): 5.70 mm Actual ID (Ref): 46.0 mm Inside Height (D): 3.20 mm
Part Number: W0460-D-090-025-S17 (5 Pcs) Disc Spring Washers - 90x45x2.5 mm - Stainless Steel 17-7 PH Out of Stock \| Backorder Now \| Orders can be expected around Thu, Jul 24, 2025 Regular price $513.05 AUD Regular price Sale price $513.05 AUD Unit price per Per 5
Nominal OD (A) 90.00 mm _{(3.543 in.)}	Nominal ID (B) 45.00 mm + 1.00 / - 0.00 _{(1.772 in.)}	Stock Thickness (C) 2.50 mm _{(0.098 in.)}
Material: Stainless Steel 17-7 PH Loaded Height (L1): 3.30 mm Load at L1: 768.0 kg Free Height (E): 5.70 mm Actual ID (Ref): 46.0 mm Inside Height (D): 3.20 mm
Part Number: W0460-D-090-025-S17 (5 Pcs) Disc Spring Washers - 90x45x2.5 mm - Stainless Steel 17-7 PH Out of Stock \| Backorder Now \| Orders can be expected around Thu, Jul 24, 2025 Regular price $513.05 AUD Regular price Sale price $513.05 AUD Unit price per Per 5 View the product page first if you are unsure.
W0460-D-090-025-S17 (5 Pcs) --- Disc Spring Washers - 90x45x2.5 mm - Stainless Steel 17-7 PH W0460-D-090-025-S17 (5 Pcs) --- Disc Spring Washers - 90x45x2.5 mm - Stainless Steel 17-7 PH Regular price $513.05 AUD Regular price Sale price $513.05 AUD Unit price per Out of stock! Backorder Now
Nominal OD (A) 112.00 mm _{(4.409 in.)}	Nominal ID (B) 55.00 mm + 2.00 / - 0.00 _{(2.165 in.)}	Stock Thickness (C) 3.00 mm _{(0.118 in.)}		Loaded Height (L1) 3.97 mm	Load at L1 1048.0 kg
Material: Stainless Steel 17-7 PH Free Height (E): 6.90 mm Actual ID (Ref): 57.0 mm Inside Height (D): 3.90 mm
Part Number: W0570-D-112-030-S17 Disc Spring Washers - 112x55x3 mm - Stainless Steel 17-7 PH Out of Stock \| Backorder Now \| Orders can be expected around Thu, Jul 24, 2025 Regular price $204.41 AUD Regular price Sale price $204.41 AUD Unit price per Each
Nominal OD (A) 112.00 mm _{(4.409 in.)}	Nominal ID (B) 55.00 mm + 2.00 / - 0.00 _{(2.165 in.)}	Stock Thickness (C) 3.00 mm _{(0.118 in.)}
Material: Stainless Steel 17-7 PH Loaded Height (L1): 3.97 mm Load at L1: 1048.0 kg Free Height (E): 6.90 mm Actual ID (Ref): 57.0 mm Inside Height (D): 3.90 mm
Part Number: W0570-D-112-030-S17 Disc Spring Washers - 112x55x3 mm - Stainless Steel 17-7 PH Out of Stock \| Backorder Now \| Orders can be expected around Thu, Jul 24, 2025 Regular price $204.41 AUD Regular price Sale price $204.41 AUD Unit price per Each View the product page first if you are unsure.
W0570-D-112-030-S17 --- Disc Spring Washers - 112x55x3 mm - Stainless Steel 17-7 PH W0570-D-112-030-S17 --- Disc Spring Washers - 112x55x3 mm - Stainless Steel 17-7 PH Regular price $204.41 AUD Regular price Sale price $204.41 AUD Unit price per Out of stock! Backorder Now
