Collection: Retaining Rings - Internal - Round Wire

Retaining Rings (With Images)

Internal

57 Products in this selection

Includes DIN7993B / RB / M1700 / BN826. Retaining rings. Snap Rings (USA). Round section circlips.
Round section wire rings are mostly used in semicircular grooves.
Applications include gear systems, automotive engineering and open gudgeon pins.

Additional resources:
Anderton Cross Reference PDF
Circlips PDF Catalogue

A more concise listing may be found on the Smallparts store at Retaining Rings - Internal - Round Wire. Smallparts promote the most popular MBA products.

Housing Bore (B)	Clip Thickness (T)	Groove Dia. (Dg)	Approx. Loose Circlip OD (Dr)	Radial Wall (S)	Groove Width (W)
Housing Bore (B) 24.00 mm _{(0.945 in.)}	Clip Thickness (T) 2.0 mm B DIN 2076 _{(0.079 in.)}	Groove Dia. (Dg) 26.00 mm + 0.5 / - 0.0 _{(1.024 in.)}	Approx. Loose Circlip OD (Dr) 26.30 mm		Groove Width (W) 2.20
Material: Spring Steel Free Inside Diameter (D): 22.3 Info: DIN7993 Section Profile: Round Section Groove Radius (r): 1.10 mm Gap (g): 10.000 mm
Part Number: WRI-0240-RD Internal Retaining Rings - 24x2x26 mm - Spring Steel Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Housing Bore (B)	Clip Thickness (T)	Groove Dia. (Dg)	Approx. Loose Circlip OD (Dr)	Indicative Image
Housing Bore (B) 24.00 mm _{(0.945 in.)}	Clip Thickness (T) 2.0 mm B DIN 2076 _{(0.079 in.)}	Groove Dia. (Dg) 26.00 mm + 0.5 / - 0.0 _{(1.024 in.)}	Approx. Loose Circlip OD (Dr) 26.30 mm
Material: Spring Steel Groove Width (W): 2.20 Free Inside Diameter (D): 22.3 Info: DIN7993 Section Profile: Round Section Groove Radius (r): 1.10 mm Gap (g): 10.000 mm
Part Number: WRI-0240-RD Internal Retaining Rings - 24x2x26 mm - Spring Steel Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Housing Bore (B) 25.00 mm _{(0.984 in.)}	Clip Thickness (T) 1.8 mm + 0.08 / - 0.04 _{(0.071 in.)}	Groove Dia. (Dg) 27.10 mm Min. _{(1.067 in.)}	Approx. Loose Circlip OD (Dr) 27.90 mm		Groove Width (W) 1.90 + 0.08 / - 0.00
Material: Spring Steel Free Inside Diameter (D): 24.3 Info: DIN7993 Section Profile: Round Section Groove Radius (r): 0.95 mm Gap (g): 10.000 mm
Part Number: WRI-0250A-RD Internal Retaining Rings - 25x1.8x27.1 mm - Spring Steel Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Housing Bore (B) 25.00 mm _{(0.984 in.)}	Clip Thickness (T) 1.8 mm + 0.08 / - 0.04 _{(0.071 in.)}	Groove Dia. (Dg) 27.10 mm Min. _{(1.067 in.)}	Approx. Loose Circlip OD (Dr) 27.90 mm
Material: Spring Steel Groove Width (W): 1.90 + 0.08 / - 0.00 Free Inside Diameter (D): 24.3 Info: DIN7993 Section Profile: Round Section Groove Radius (r): 0.95 mm Gap (g): 10.000 mm
Part Number: WRI-0250A-RD Internal Retaining Rings - 25x1.8x27.1 mm - Spring Steel Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Housing Bore (B) 25.00 mm _{(0.984 in.)}	Clip Thickness (T) 2.0 mm B DIN 2076 _{(0.079 in.)}	Groove Dia. (Dg) 27.00 mm + 0.5 / - 0.0 _{(1.063 in.)}	Approx. Loose Circlip OD (Dr) 27.30 mm		Groove Width (W) 2.20
Material: Spring Steel Free Inside Diameter (D): 23.3 Info: DIN7993 Section Profile: Round Section Groove Radius (r): 1.10 mm Gap (g): 10.000 mm
Part Number: WRI-0250-RD Internal Retaining Rings - 25x2x27 mm - Spring Steel Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Housing Bore (B) 25.00 mm _{(0.984 in.)}	Clip Thickness (T) 2.0 mm B DIN 2076 _{(0.079 in.)}	Groove Dia. (Dg) 27.00 mm + 0.5 / - 0.0 _{(1.063 in.)}	Approx. Loose Circlip OD (Dr) 27.30 mm
Material: Spring Steel Groove Width (W): 2.20 Free Inside Diameter (D): 23.3 Info: DIN7993 Section Profile: Round Section Groove Radius (r): 1.10 mm Gap (g): 10.000 mm
Part Number: WRI-0250-RD Internal Retaining Rings - 25x2x27 mm - Spring Steel Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Housing Bore (B) 26.00 mm _{(1.024 in.)}	Clip Thickness (T) 2.0 mm B DIN 2076 _{(0.079 in.)}	Groove Dia. (Dg) 28.00 mm + 0.5 / - 0.0 _{(1.102 in.)}	Approx. Loose Circlip OD (Dr) 28.30 mm		Groove Width (W) 2.20
Material: Spring Steel Free Inside Diameter (D): 24.3 Info: DIN7993 Section Profile: Round Section Groove Radius (r): 1.10 mm Gap (g): 10.000 mm
Part Number: WRI-0260-RD Internal Retaining Rings - 26x2x28 mm - Spring Steel 466 Available Immediately \| Further orders can be expected around Sat, Jun 07, 2025 Regular price $2.14 AUD Regular price Sale price $2.14 AUD Unit price per Each
Housing Bore (B) 26.00 mm _{(1.024 in.)}	Clip Thickness (T) 2.0 mm B DIN 2076 _{(0.079 in.)}	Groove Dia. (Dg) 28.00 mm + 0.5 / - 0.0 _{(1.102 in.)}	Approx. Loose Circlip OD (Dr) 28.30 mm
Material: Spring Steel Groove Width (W): 2.20 Free Inside Diameter (D): 24.3 Info: DIN7993 Section Profile: Round Section Groove Radius (r): 1.10 mm Gap (g): 10.000 mm
Part Number: WRI-0260-RD Internal Retaining Rings - 26x2x28 mm - Spring Steel 466 Available Immediately \| Further orders can be expected around Sat, Jun 07, 2025 Regular price $2.14 AUD Regular price Sale price $2.14 AUD Unit price per Each View the product page first if you are unsure.
WRI-0260-RD --- Internal Retaining Rings - 26x2x28 mm - Spring Steel WRI-0260-RD --- Internal Retaining Rings - 26x2x28 mm - Spring Steel Regular price $2.14 AUD Regular price Sale price $2.14 AUD Unit price per 466 Available Now
Housing Bore (B) 28.00 mm _{(1.102 in.)}	Clip Thickness (T) 2.0 mm B DIN 2076 _{(0.079 in.)}	Groove Dia. (Dg) 30.00 mm + 0.5 / - 0.0 _{(1.181 in.)}	Approx. Loose Circlip OD (Dr) 30.30 mm		Groove Width (W) 2.20
Material: Spring Steel Free Inside Diameter (D): 26.3 Info: DIN7993 Section Profile: Round Section Groove Radius (r): 1.10 mm Gap (g): 10.000 mm
Part Number: WRI-0280-RD Internal Retaining Rings - 28x2x30 mm - Spring Steel 40 Available Immediately \| Further orders can be expected around Sat, Jun 07, 2025 Regular price $5.59 AUD Regular price Sale price $5.59 AUD Unit price per Each
Housing Bore (B) 28.00 mm _{(1.102 in.)}	Clip Thickness (T) 2.0 mm B DIN 2076 _{(0.079 in.)}	Groove Dia. (Dg) 30.00 mm + 0.5 / - 0.0 _{(1.181 in.)}	Approx. Loose Circlip OD (Dr) 30.30 mm
Material: Spring Steel Groove Width (W): 2.20 Free Inside Diameter (D): 26.3 Info: DIN7993 Section Profile: Round Section Groove Radius (r): 1.10 mm Gap (g): 10.000 mm
Part Number: WRI-0280-RD Internal Retaining Rings - 28x2x30 mm - Spring Steel 40 Available Immediately \| Further orders can be expected around Sat, Jun 07, 2025 Regular price $5.59 AUD Regular price Sale price $5.59 AUD Unit price per Each View the product page first if you are unsure.
WRI-0280-RD --- Internal Retaining Rings - 28x2x30 mm - Spring Steel WRI-0280-RD --- Internal Retaining Rings - 28x2x30 mm - Spring Steel Regular price $5.59 AUD Regular price Sale price $5.59 AUD Unit price per 40 Available Now
Housing Bore (B) 28.00 mm _{(1.102 in.)}	Clip Thickness (T) 2.0 mm + 0.10 / - 0.05 _{(0.079 in.)}	Groove Dia. (Dg) 30.30 mm Min. _{(1.193 in.)}	Approx. Loose Circlip OD (Dr) 31.10 mm		Groove Width (W) 2.10 + 0.10 / - 0.00
Material: Spring Steel Free Inside Diameter (D): 27.1 Info: DIN7993 Section Profile: Round Section Groove Radius (r): 1.05 mm Gap (g): 11.000 mm
Part Number: WRI-0280A-RD Internal Retaining Rings - 28x2x30.3 mm - Spring Steel Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Housing Bore (B) 28.00 mm _{(1.102 in.)}	Clip Thickness (T) 2.0 mm + 0.10 / - 0.05 _{(0.079 in.)}	Groove Dia. (Dg) 30.30 mm Min. _{(1.193 in.)}	Approx. Loose Circlip OD (Dr) 31.10 mm
Material: Spring Steel Groove Width (W): 2.10 + 0.10 / - 0.00 Free Inside Diameter (D): 27.1 Info: DIN7993 Section Profile: Round Section Groove Radius (r): 1.05 mm Gap (g): 11.000 mm
Part Number: WRI-0280A-RD Internal Retaining Rings - 28x2x30.3 mm - Spring Steel Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Housing Bore (B) 30.00 mm _{(1.181 in.)}	Clip Thickness (T) 2.0 mm B DIN 2076 _{(0.079 in.)}	Groove Dia. (Dg) 32.00 mm + 0.5 / - 0.0 _{(1.26 in.)}	Approx. Loose Circlip OD (Dr) 32.30 mm		Groove Width (W) 2.20
Material: Spring Steel Free Inside Diameter (D): 28.3 Info: DIN7993 Section Profile: Round Section Groove Radius (r): 1.10 mm Gap (g): 10.000 mm
Part Number: WRI-0300-RD (2 Pcs) Internal Retaining Rings - 30x2x32 mm - Spring Steel 99 units (198 pcs) Available Immediately \| Further orders can be expected around Sat, Jun 07, 2025 Regular price $1.59 AUD Regular price Sale price $1.59 AUD Unit price per Per 2
Housing Bore (B) 30.00 mm _{(1.181 in.)}	Clip Thickness (T) 2.0 mm B DIN 2076 _{(0.079 in.)}	Groove Dia. (Dg) 32.00 mm + 0.5 / - 0.0 _{(1.26 in.)}	Approx. Loose Circlip OD (Dr) 32.30 mm
Material: Spring Steel Groove Width (W): 2.20 Free Inside Diameter (D): 28.3 Info: DIN7993 Section Profile: Round Section Groove Radius (r): 1.10 mm Gap (g): 10.000 mm
Part Number: WRI-0300-RD (2 Pcs) Internal Retaining Rings - 30x2x32 mm - Spring Steel 99 units (198 pcs) Available Immediately \| Further orders can be expected around Sat, Jun 07, 2025 Regular price $1.59 AUD Regular price Sale price $1.59 AUD Unit price per Per 2 View the product page first if you are unsure.
WRI-0300-RD (2 Pcs) --- Internal Retaining Rings - 30x2x32 mm - Spring Steel WRI-0300-RD (2 Pcs) --- Internal Retaining Rings - 30x2x32 mm - Spring Steel Regular price $1.59 AUD Regular price Sale price $1.59 AUD Unit price per 99 Available Now
Housing Bore (B) 30.00 mm _{(1.181 in.)}	Clip Thickness (T) 2.0 mm + 0.10 / - 0.05 _{(0.079 in.)}	Groove Dia. (Dg) 32.30 mm Min. _{(1.272 in.)}	Approx. Loose Circlip OD (Dr) 33.10 mm		Groove Width (W) 2.10 + 0.10 / - 0.00
Material: Spring Steel Free Inside Diameter (D): 29.1 Info: DIN7993 Section Profile: Round Section Groove Radius (r): 1.05 mm Gap (g): 11.000 mm
Part Number: WRI-0300A-RD Internal Retaining Rings - 30x2x32.3 mm - Spring Steel Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Housing Bore (B) 30.00 mm _{(1.181 in.)}	Clip Thickness (T) 2.0 mm + 0.10 / - 0.05 _{(0.079 in.)}	Groove Dia. (Dg) 32.30 mm Min. _{(1.272 in.)}	Approx. Loose Circlip OD (Dr) 33.10 mm
Material: Spring Steel Groove Width (W): 2.10 + 0.10 / - 0.00 Free Inside Diameter (D): 29.1 Info: DIN7993 Section Profile: Round Section Groove Radius (r): 1.05 mm Gap (g): 11.000 mm
Part Number: WRI-0300A-RD Internal Retaining Rings - 30x2x32.3 mm - Spring Steel Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Housing Bore (B) 32.00 mm _{(1.26 in.)}	Clip Thickness (T) 2.0 mm + 0.10 / - 0.05 _{(0.079 in.)}	Groove Dia. (Dg) 34.30 mm Min. _{(1.35 in.)}	Approx. Loose Circlip OD (Dr) 35.10 mm		Groove Width (W) 2.10 + 0.10 / - 0.00
Material: Spring Steel Free Inside Diameter (D): 31.1 Info: DIN7993 Section Profile: Round Section Groove Radius (r): 1.05 mm Gap (g): 11.000 mm
Part Number: WRI-0320A-RD Internal Retaining Rings - 32x2x34.3 mm - Spring Steel Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Housing Bore (B) 32.00 mm _{(1.26 in.)}	Clip Thickness (T) 2.0 mm + 0.10 / - 0.05 _{(0.079 in.)}	Groove Dia. (Dg) 34.30 mm Min. _{(1.35 in.)}	Approx. Loose Circlip OD (Dr) 35.10 mm
Material: Spring Steel Groove Width (W): 2.10 + 0.10 / - 0.00 Free Inside Diameter (D): 31.1 Info: DIN7993 Section Profile: Round Section Groove Radius (r): 1.05 mm Gap (g): 11.000 mm
Part Number: WRI-0320A-RD Internal Retaining Rings - 32x2x34.3 mm - Spring Steel Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Housing Bore (B) 32.00 mm _{(1.26 in.)}	Clip Thickness (T) 2.5 mm B DIN 2076 _{(0.098 in.)}	Groove Dia. (Dg) 34.50 mm + 0.6 / - 0.0 _{(1.358 in.)}	Approx. Loose Circlip OD (Dr) 34.90 mm		Groove Width (W) 2.80
Material: Spring Steel Free Inside Diameter (D): 29.9 Info: DIN7993 Section Profile: Round Section Groove Radius (r): 1.40 mm Gap (g): 12.000 mm
Part Number: WRI-0320-RD (100 Pcs) Internal Retaining Rings - 32x2.5x34.5 mm - Spring Steel Out of Stock \| Backorder Now \| Orders can be expected around Sat, Jun 07, 2025 Regular price $57.95 AUD Regular price Sale price $57.95 AUD Unit price per Per 100
Housing Bore (B) 32.00 mm _{(1.26 in.)}	Clip Thickness (T) 2.5 mm B DIN 2076 _{(0.098 in.)}	Groove Dia. (Dg) 34.50 mm + 0.6 / - 0.0 _{(1.358 in.)}	Approx. Loose Circlip OD (Dr) 34.90 mm
Material: Spring Steel Groove Width (W): 2.80 Free Inside Diameter (D): 29.9 Info: DIN7993 Section Profile: Round Section Groove Radius (r): 1.40 mm Gap (g): 12.000 mm
Part Number: WRI-0320-RD (100 Pcs) Internal Retaining Rings - 32x2.5x34.5 mm - Spring Steel Out of Stock \| Backorder Now \| Orders can be expected around Sat, Jun 07, 2025 Regular price $57.95 AUD Regular price Sale price $57.95 AUD Unit price per Per 100 View the product page first if you are unsure.
WRI-0320-RD (100 Pcs) --- Internal Retaining Rings - 32x2.5x34.5 mm - Spring Steel WRI-0320-RD (100 Pcs) --- Internal Retaining Rings - 32x2.5x34.5 mm - Spring Steel Regular price $57.95 AUD Regular price Sale price $57.95 AUD Unit price per Out of stock! Backorder Now
Housing Bore (B) 34.00 mm _{(1.339 in.)}	Clip Thickness (T) 2.0 mm + 0.10 / - 0.05 _{(0.079 in.)}	Groove Dia. (Dg) 36.32 mm Min. _{(1.43 in.)}	Approx. Loose Circlip OD (Dr) 37.10 mm		Groove Width (W) 2.10 + 0.10 / - 0.00
Material: Spring Steel Free Inside Diameter (D): 33.1 Info: DIN7993 Section Profile: Round Section Groove Radius (r): 1.05 mm Gap (g): 11.000 mm
Part Number: WRI-0340A-RD Internal Retaining Rings - 34x2x36.32 mm - Spring Steel Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Housing Bore (B) 34.00 mm _{(1.339 in.)}	Clip Thickness (T) 2.0 mm + 0.10 / - 0.05 _{(0.079 in.)}	Groove Dia. (Dg) 36.32 mm Min. _{(1.43 in.)}	Approx. Loose Circlip OD (Dr) 37.10 mm
Material: Spring Steel Groove Width (W): 2.10 + 0.10 / - 0.00 Free Inside Diameter (D): 33.1 Info: DIN7993 Section Profile: Round Section Groove Radius (r): 1.05 mm Gap (g): 11.000 mm
Part Number: WRI-0340A-RD Internal Retaining Rings - 34x2x36.32 mm - Spring Steel Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Housing Bore (B) 35.00 mm _{(1.378 in.)}	Clip Thickness (T) 2.5 mm B DIN 2076 _{(0.098 in.)}	Groove Dia. (Dg) 37.50 mm + 0.6 / - 0.0 _{(1.476 in.)}	Approx. Loose Circlip OD (Dr) 37.90 mm		Groove Width (W) 2.80
Material: Spring Steel Free Inside Diameter (D): 32.9 Info: DIN7993 Section Profile: Round Section Groove Radius (r): 1.40 mm Gap (g): 12.000 mm
Part Number: WRI-0350-RD (100 Pcs) Internal Retaining Rings - 35x2.5x37.5 mm - Spring Steel Out of Stock \| Backorder Now \| Orders can be expected around Sat, Jun 07, 2025 Regular price $59.23 AUD Regular price Sale price $59.23 AUD Unit price per Per 100
Housing Bore (B) 35.00 mm _{(1.378 in.)}	Clip Thickness (T) 2.5 mm B DIN 2076 _{(0.098 in.)}	Groove Dia. (Dg) 37.50 mm + 0.6 / - 0.0 _{(1.476 in.)}	Approx. Loose Circlip OD (Dr) 37.90 mm
Material: Spring Steel Groove Width (W): 2.80 Free Inside Diameter (D): 32.9 Info: DIN7993 Section Profile: Round Section Groove Radius (r): 1.40 mm Gap (g): 12.000 mm
Part Number: WRI-0350-RD (100 Pcs) Internal Retaining Rings - 35x2.5x37.5 mm - Spring Steel Out of Stock \| Backorder Now \| Orders can be expected around Sat, Jun 07, 2025 Regular price $59.23 AUD Regular price Sale price $59.23 AUD Unit price per Per 100 View the product page first if you are unsure.
WRI-0350-RD (100 Pcs) --- Internal Retaining Rings - 35x2.5x37.5 mm - Spring Steel WRI-0350-RD (100 Pcs) --- Internal Retaining Rings - 35x2.5x37.5 mm - Spring Steel Regular price $59.23 AUD Regular price Sale price $59.23 AUD Unit price per Out of stock! Backorder Now
Housing Bore (B) 38.00 mm _{(1.496 in.)}	Clip Thickness (T) 2.5 mm B DIN 2076 _{(0.098 in.)}	Groove Dia. (Dg) 40.50 mm + 0.6 / - 0.0 _{(1.594 in.)}	Approx. Loose Circlip OD (Dr) 40.90 mm		Groove Width (W) 2.80
Material: Spring Steel Free Inside Diameter (D): 35.9 Info: DIN7993 Section Profile: Round Section Groove Radius (r): 1.40 mm Gap (g): 12.000 mm
Part Number: WRI-0380-RD Internal Retaining Rings - 38x2.5x40.5 mm - Spring Steel Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Housing Bore (B) 38.00 mm _{(1.496 in.)}	Clip Thickness (T) 2.5 mm B DIN 2076 _{(0.098 in.)}	Groove Dia. (Dg) 40.50 mm + 0.6 / - 0.0 _{(1.594 in.)}	Approx. Loose Circlip OD (Dr) 40.90 mm
Material: Spring Steel Groove Width (W): 2.80 Free Inside Diameter (D): 35.9 Info: DIN7993 Section Profile: Round Section Groove Radius (r): 1.40 mm Gap (g): 12.000 mm
Part Number: WRI-0380-RD Internal Retaining Rings - 38x2.5x40.5 mm - Spring Steel Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Housing Bore (B) 40.00 mm _{(1.575 in.)}	Clip Thickness (T) 2.5 mm B DIN 2076 _{(0.098 in.)}	Groove Dia. (Dg) 42.50 mm + 0.6 / - 0.0 _{(1.673 in.)}	Approx. Loose Circlip OD (Dr) 42.90 mm		Groove Width (W) 2.80
Material: Spring Steel Free Inside Diameter (D): 37.9 Info: DIN7993 Section Profile: Round Section Groove Radius (r): 1.40 mm Gap (g): 12.000 mm
Part Number: WRI-0400-RD Internal Retaining Rings - 40x2.5x42.5 mm - Spring Steel Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Housing Bore (B) 40.00 mm _{(1.575 in.)}	Clip Thickness (T) 2.5 mm B DIN 2076 _{(0.098 in.)}	Groove Dia. (Dg) 42.50 mm + 0.6 / - 0.0 _{(1.673 in.)}	Approx. Loose Circlip OD (Dr) 42.90 mm
Material: Spring Steel Groove Width (W): 2.80 Free Inside Diameter (D): 37.9 Info: DIN7993 Section Profile: Round Section Groove Radius (r): 1.40 mm Gap (g): 12.000 mm
Part Number: WRI-0400-RD Internal Retaining Rings - 40x2.5x42.5 mm - Spring Steel Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Housing Bore (B) 42.00 mm _{(1.654 in.)}	Clip Thickness (T) 2.5 mm B DIN 2076 _{(0.098 in.)}	Groove Dia. (Dg) 44.50 mm + 0.8 / - 0.0 _{(1.752 in.)}	Approx. Loose Circlip OD (Dr) 45.00 mm		Groove Width (W) 2.80
Material: Spring Steel Free Inside Diameter (D): 40 Info: DIN7993 Section Profile: Round Section Groove Radius (r): 1.40 mm Gap (g): 16.00 mm
Part Number: WRI-0420-RD (10 Pcs) Internal Retaining Rings - 42x2.5x44.5 mm - Spring Steel 12 units (120 pcs) Available Immediately \| Item Discontinued - Only the quantity available may be ordered - Please contact us if you need a larger quantity Regular price $20.00 AUD Regular price ~~$38.00 AUD~~ Sale price $20.00 AUD Unit price per Per 10
Housing Bore (B) 42.00 mm _{(1.654 in.)}	Clip Thickness (T) 2.5 mm B DIN 2076 _{(0.098 in.)}	Groove Dia. (Dg) 44.50 mm + 0.8 / - 0.0 _{(1.752 in.)}	Approx. Loose Circlip OD (Dr) 45.00 mm
Material: Spring Steel Groove Width (W): 2.80 Free Inside Diameter (D): 40 Info: DIN7993 Section Profile: Round Section Groove Radius (r): 1.40 mm Gap (g): 16.00 mm
Part Number: WRI-0420-RD (10 Pcs) Internal Retaining Rings - 42x2.5x44.5 mm - Spring Steel 12 units (120 pcs) Available Immediately \| Item Discontinued - Only the quantity available may be ordered - Please contact us if you need a larger quantity Regular price $20.00 AUD Regular price ~~$38.00 AUD~~ Sale price $20.00 AUD Unit price per Per 10
WRI-0420-RD (10 Pcs) --- Internal Retaining Rings - 42x2.5x44.5 mm - Spring Steel Sale WRI-0420-RD (10 Pcs) --- Internal Retaining Rings - 42x2.5x44.5 mm - Spring Steel Regular price $20.00 AUD Regular price ~~$38.00 AUD~~ Sale price $20.00 AUD Unit price per 12 Available Now Sale
Housing Bore (B) 45.00 mm _{(1.772 in.)}	Clip Thickness (T) 2.5 mm B DIN 2076 _{(0.098 in.)}	Groove Dia. (Dg) 47.50 mm + 0.8 / - 0.0 _{(1.87 in.)}	Approx. Loose Circlip OD (Dr) 48.80 mm		Groove Width (W) 2.80
Material: Spring Steel Free Inside Diameter (D): 43.8 Info: DIN7993 Section Profile: Round Section Groove Radius (r): 1.40 mm Gap (g): 16.000 mm
Part Number: WRI-0450-RD Internal Retaining Rings - 45x2.5x47.5 mm - Spring Steel Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Housing Bore (B) 45.00 mm _{(1.772 in.)}	Clip Thickness (T) 2.5 mm B DIN 2076 _{(0.098 in.)}	Groove Dia. (Dg) 47.50 mm + 0.8 / - 0.0 _{(1.87 in.)}	Approx. Loose Circlip OD (Dr) 48.80 mm
Material: Spring Steel Groove Width (W): 2.80 Free Inside Diameter (D): 43.8 Info: DIN7993 Section Profile: Round Section Groove Radius (r): 1.40 mm Gap (g): 16.000 mm
Part Number: WRI-0450-RD Internal Retaining Rings - 45x2.5x47.5 mm - Spring Steel Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Housing Bore (B) 48.00 mm _{(1.89 in.)}	Clip Thickness (T) 2.5 mm B DIN 2076 _{(0.098 in.)}	Groove Dia. (Dg) 50.50 mm + 0.8 / - 0.0 _{(1.988 in.)}	Approx. Loose Circlip OD (Dr) 51.00 mm		Groove Width (W) 2.80
Material: Spring Steel Free Inside Diameter (D): 46 Info: DIN7993 Section Profile: Round Section Groove Radius (r): 1.40 mm Gap (g): 16.000 mm
Part Number: WRI-0480-RD Internal Retaining Rings - 48x2.5x50.5 mm - Spring Steel Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Housing Bore (B) 48.00 mm _{(1.89 in.)}	Clip Thickness (T) 2.5 mm B DIN 2076 _{(0.098 in.)}	Groove Dia. (Dg) 50.50 mm + 0.8 / - 0.0 _{(1.988 in.)}	Approx. Loose Circlip OD (Dr) 51.00 mm
Material: Spring Steel Groove Width (W): 2.80 Free Inside Diameter (D): 46 Info: DIN7993 Section Profile: Round Section Groove Radius (r): 1.40 mm Gap (g): 16.000 mm
Part Number: WRI-0480-RD Internal Retaining Rings - 48x2.5x50.5 mm - Spring Steel Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Housing Bore (B) 50.00 mm _{(1.969 in.)}	Clip Thickness (T) 2.5 mm B DIN 2076 _{(0.098 in.)}	Groove Dia. (Dg) 52.50 mm + 0.8 / - 0.0 _{(2.067 in.)}	Approx. Loose Circlip OD (Dr) 53.00 mm		Groove Width (W) 2.80
Material: Spring Steel Free Inside Diameter (D): 48 Info: DIN7993 Section Profile: Round Section Groove Radius (r): 1.40 mm Gap (g): 16.000 mm
Part Number: WRI-0500-RD Internal Retaining Rings - 50x2.5x52.5 mm - Spring Steel Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Housing Bore (B) 50.00 mm _{(1.969 in.)}	Clip Thickness (T) 2.5 mm B DIN 2076 _{(0.098 in.)}	Groove Dia. (Dg) 52.50 mm + 0.8 / - 0.0 _{(2.067 in.)}	Approx. Loose Circlip OD (Dr) 53.00 mm
Material: Spring Steel Groove Width (W): 2.80 Free Inside Diameter (D): 48 Info: DIN7993 Section Profile: Round Section Groove Radius (r): 1.40 mm Gap (g): 16.000 mm
Part Number: WRI-0500-RD Internal Retaining Rings - 50x2.5x52.5 mm - Spring Steel Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Housing Bore (B) 55.00 mm _{(2.165 in.)}	Clip Thickness (T) 3.2 mm B DIN 2076 _{(0.126 in.)}	Groove Dia. (Dg) 58.20 mm + 0.8 / - 0.0 _{(2.291 in.)}	Approx. Loose Circlip OD (Dr) 58.90 mm		Groove Width (W) 3.60
Material: Spring Steel Free Inside Diameter (D): 52.5 Info: DIN7993 Section Profile: Round Section Groove Radius (r): 1.80 mm Gap (g): 20.000 mm
Part Number: WRI-0550-RD Internal Retaining Rings - 55x3.2x58.2 mm - Spring Steel Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Housing Bore (B) 55.00 mm _{(2.165 in.)}	Clip Thickness (T) 3.2 mm B DIN 2076 _{(0.126 in.)}	Groove Dia. (Dg) 58.20 mm + 0.8 / - 0.0 _{(2.291 in.)}	Approx. Loose Circlip OD (Dr) 58.90 mm
Material: Spring Steel Groove Width (W): 3.60 Free Inside Diameter (D): 52.5 Info: DIN7993 Section Profile: Round Section Groove Radius (r): 1.80 mm Gap (g): 20.000 mm
Part Number: WRI-0550-RD Internal Retaining Rings - 55x3.2x58.2 mm - Spring Steel Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Housing Bore (B) 60.00 mm _{(2.362 in.)}	Clip Thickness (T) 3.2 mm B DIN 2076 _{(0.126 in.)}	Groove Dia. (Dg) 63.20 mm + 0.8 / - 0.0 _{(2.488 in.)}	Approx. Loose Circlip OD (Dr) 63.90 mm		Groove Width (W) 3.60
Material: Spring Steel Free Inside Diameter (D): 57.5 Info: DIN7993 Section Profile: Round Section Groove Radius (r): 1.80 mm Gap (g): 20.000 mm
Part Number: WRI-0600-RD Internal Retaining Rings - 60x3.2x63.2 mm - Spring Steel Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Housing Bore (B) 60.00 mm _{(2.362 in.)}	Clip Thickness (T) 3.2 mm B DIN 2076 _{(0.126 in.)}	Groove Dia. (Dg) 63.20 mm + 0.8 / - 0.0 _{(2.488 in.)}	Approx. Loose Circlip OD (Dr) 63.90 mm
Material: Spring Steel Groove Width (W): 3.60 Free Inside Diameter (D): 57.5 Info: DIN7993 Section Profile: Round Section Groove Radius (r): 1.80 mm Gap (g): 20.000 mm
Part Number: WRI-0600-RD Internal Retaining Rings - 60x3.2x63.2 mm - Spring Steel Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Housing Bore (B) 65.00 mm _{(2.559 in.)}	Clip Thickness (T) 3.2 mm B DIN 2076 _{(0.126 in.)}	Groove Dia. (Dg) 68.20 mm + 0.8 / - 0.0 _{(2.685 in.)}	Approx. Loose Circlip OD (Dr) 68.90 mm		Groove Width (W) 3.60
Material: Spring Steel Free Inside Diameter (D): 62.5 Info: DIN7993 Section Profile: Round Section Groove Radius (r): 1.80 mm Gap (g): 20.000 mm
Part Number: WRI-0650-RD Internal Retaining Rings - 65x3.2x68.2 mm - Spring Steel Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Housing Bore (B) 65.00 mm _{(2.559 in.)}	Clip Thickness (T) 3.2 mm B DIN 2076 _{(0.126 in.)}	Groove Dia. (Dg) 68.20 mm + 0.8 / - 0.0 _{(2.685 in.)}	Approx. Loose Circlip OD (Dr) 68.90 mm
Material: Spring Steel Groove Width (W): 3.60 Free Inside Diameter (D): 62.5 Info: DIN7993 Section Profile: Round Section Groove Radius (r): 1.80 mm Gap (g): 20.000 mm
Part Number: WRI-0650-RD Internal Retaining Rings - 65x3.2x68.2 mm - Spring Steel Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Housing Bore (B) 70.00 mm _{(2.756 in.)}	Clip Thickness (T) 3.2 mm B DIN 2076 _{(0.126 in.)}	Groove Dia. (Dg) 73.20 mm + 1.0 / - 0.0 _{(2.882 in.)}	Approx. Loose Circlip OD (Dr) 74.00 mm		Groove Width (W) 3.60
Material: Spring Steel Free Inside Diameter (D): 67.6 Info: DIN7993 Section Profile: Round Section Groove Radius (r): 1.80 mm Gap (g): 25.000 mm
Part Number: WRI-0700-RD (6 Pcs) Internal Retaining Rings - 70x3.2x73.2 mm - Spring Steel Out of Stock \| Backorder Now \| Orders can be expected around Sat, Jun 07, 2025 Regular price $18.95 AUD Regular price Sale price $18.95 AUD Unit price per Per 6
Housing Bore (B) 70.00 mm _{(2.756 in.)}	Clip Thickness (T) 3.2 mm B DIN 2076 _{(0.126 in.)}	Groove Dia. (Dg) 73.20 mm + 1.0 / - 0.0 _{(2.882 in.)}	Approx. Loose Circlip OD (Dr) 74.00 mm
Material: Spring Steel Groove Width (W): 3.60 Free Inside Diameter (D): 67.6 Info: DIN7993 Section Profile: Round Section Groove Radius (r): 1.80 mm Gap (g): 25.000 mm
Part Number: WRI-0700-RD (6 Pcs) Internal Retaining Rings - 70x3.2x73.2 mm - Spring Steel Out of Stock \| Backorder Now \| Orders can be expected around Sat, Jun 07, 2025 Regular price $18.95 AUD Regular price Sale price $18.95 AUD Unit price per Per 6 View the product page first if you are unsure.
WRI-0700-RD (6 Pcs) --- Internal Retaining Rings - 70x3.2x73.2 mm - Spring Steel WRI-0700-RD (6 Pcs) --- Internal Retaining Rings - 70x3.2x73.2 mm - Spring Steel Regular price $18.95 AUD Regular price Sale price $18.95 AUD Unit price per Out of stock! Backorder Now
Housing Bore (B) 75.00 mm _{(2.953 in.)}	Clip Thickness (T) 3.2 mm B DIN 2076 _{(0.126 in.)}	Groove Dia. (Dg) 78.20 mm + 1.0 / - 0.0 _{(3.079 in.)}	Approx. Loose Circlip OD (Dr) 79.00 mm		Groove Width (W) 3.60
Material: Spring Steel Free Inside Diameter (D): 72.6 Info: DIN7993 Section Profile: Round Section Groove Radius (r): 1.80 mm Gap (g): 25.000 mm
Part Number: WRI-0750-RD (150 Pcs) Internal Retaining Rings - 75x3.2x78.2 mm - Spring Steel Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Housing Bore (B) 75.00 mm _{(2.953 in.)}	Clip Thickness (T) 3.2 mm B DIN 2076 _{(0.126 in.)}	Groove Dia. (Dg) 78.20 mm + 1.0 / - 0.0 _{(3.079 in.)}	Approx. Loose Circlip OD (Dr) 79.00 mm
Material: Spring Steel Groove Width (W): 3.60 Free Inside Diameter (D): 72.6 Info: DIN7993 Section Profile: Round Section Groove Radius (r): 1.80 mm Gap (g): 25.000 mm
Part Number: WRI-0750-RD (150 Pcs) Internal Retaining Rings - 75x3.2x78.2 mm - Spring Steel Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Housing Bore (B) 80.00 mm _{(3.15 in.)}	Clip Thickness (T) 3.2 mm B DIN 2076 _{(0.126 in.)}	Groove Dia. (Dg) 83.20 mm + 1.0 / - 0.0 _{(3.276 in.)}	Approx. Loose Circlip OD (Dr) 84.00 mm		Groove Width (W) 3.60
Material: Spring Steel Free Inside Diameter (D): 77.6 Info: DIN7993 Section Profile: Round Section Groove Radius (r): 1.80 mm Gap (g): 25.000 mm
Part Number: WRI-0800-RD (4 Pcs) Internal Retaining Rings - 80x3.2x83.2 mm - Spring Steel Out of Stock \| Backorder Now \| Orders can be expected around Sat, Jun 07, 2025 Regular price $20.59 AUD Regular price Sale price $20.59 AUD Unit price per Per 4
Housing Bore (B) 80.00 mm _{(3.15 in.)}	Clip Thickness (T) 3.2 mm B DIN 2076 _{(0.126 in.)}	Groove Dia. (Dg) 83.20 mm + 1.0 / - 0.0 _{(3.276 in.)}	Approx. Loose Circlip OD (Dr) 84.00 mm
Material: Spring Steel Groove Width (W): 3.60 Free Inside Diameter (D): 77.6 Info: DIN7993 Section Profile: Round Section Groove Radius (r): 1.80 mm Gap (g): 25.000 mm
Part Number: WRI-0800-RD (4 Pcs) Internal Retaining Rings - 80x3.2x83.2 mm - Spring Steel Out of Stock \| Backorder Now \| Orders can be expected around Sat, Jun 07, 2025 Regular price $20.59 AUD Regular price Sale price $20.59 AUD Unit price per Per 4 View the product page first if you are unsure.
WRI-0800-RD (4 Pcs) --- Internal Retaining Rings - 80x3.2x83.2 mm - Spring Steel WRI-0800-RD (4 Pcs) --- Internal Retaining Rings - 80x3.2x83.2 mm - Spring Steel Regular price $20.59 AUD Regular price Sale price $20.59 AUD Unit price per Out of stock! Backorder Now
