Collection: Retaining Rings - Internal - Circlips - Standard - Carbon Steel

Retaining Rings (With Images)

Internal

Circlips

Standard

328 Products in this selection

Imperial and metric DIN471 and 472 / D1300 / N1300 / Seeger J and JS. Retaining rings. Snap Rings (USA).
Plain carbon steel
Tolerances on request.

Additional resources:
Anderton Cross Reference PDF
Circlips PDF Catalogue
Circlip Tools

A more concise listing may be found on the Smallparts store at Retaining Rings - Internal - Circlips - Standard - Carbon Steel. Smallparts promote the most popular MBA products.

Housing Bore (B)	Clip Thickness (T)	Groove Dia. (Dg)	Approx. Loose Circlip OD (Dr)	Radial Wall (S)	Groove Width (W)
Housing Bore (B) 220.00 mm _{(8.661 in.)}	Clip Thickness (T) 5.00 mm + 0.72 / - 0.00 _{(0.197 in.)}	Groove Dia. (Dg) 226.00 mm + 0.00 / - 0.12 _{(8.898 in.)}	Approx. Loose Circlip OD (Dr) 232.00 mm + 1.70 / - 0.72		Groove Width (W) 5.15 mm + 0.20 / - 0.00
Material: Carbon Steel Clearance in Bore (C): 190.20 mm Clearance in Groove (C1): 197.00 mm Min. Lug Diameter (h): 4.00 mm Min. Extension (n): 9.00 Standard: DIN472
Part Number: CCI-22000-C Internal Retaining Rings - 220x5x226 mm - Carbon Steel Out of Stock \| Backorder Now \| Orders can be expected around Sun, Jun 08, 2025 Regular price $58.59 AUD Regular price Sale price $58.59 AUD Unit price per Each
Housing Bore (B)	Clip Thickness (T)	Groove Dia. (Dg)	Approx. Loose Circlip OD (Dr)	Indicative Image
Housing Bore (B) 220.00 mm _{(8.661 in.)}	Clip Thickness (T) 5.00 mm + 0.72 / - 0.00 _{(0.197 in.)}	Groove Dia. (Dg) 226.00 mm + 0.00 / - 0.12 _{(8.898 in.)}	Approx. Loose Circlip OD (Dr) 232.00 mm + 1.70 / - 0.72
Material: Carbon Steel Groove Width (W): 5.15 mm + 0.20 / - 0.00 Clearance in Bore (C): 190.20 mm Clearance in Groove (C1): 197.00 mm Min. Lug Diameter (h): 4.00 mm Min. Extension (n): 9.00 Standard: DIN472
Part Number: CCI-22000-C Internal Retaining Rings - 220x5x226 mm - Carbon Steel Out of Stock \| Backorder Now \| Orders can be expected around Sun, Jun 08, 2025 Regular price $58.59 AUD Regular price Sale price $58.59 AUD Unit price per Each View the product page first if you are unsure.
CCI-22000-C --- Internal Retaining Rings - 220x5x226 mm - Carbon Steel CCI-22000-C --- Internal Retaining Rings - 220x5x226 mm - Carbon Steel Regular price $58.59 AUD Regular price Sale price $58.59 AUD Unit price per Out of stock! Backorder Now
Housing Bore (B) 222.00 mm _{(8.74 in.)}	Clip Thickness (T) 5.00 mm + 0.72 / - 0.00 _{(0.197 in.)}	Groove Dia. (Dg) 228.00 mm + 0.00 / - 0.12 _{(8.976 in.)}	Approx. Loose Circlip OD (Dr) 232.00 mm + 1.70 / - 0.72		Groove Width (W) 5.15 mm + 0.20 / - 0.00
Material: Carbon Spring Steel phosphate and oil finish Standard: DIN472
Part Number: CCI-22200-C Internal Retaining Rings - 222x5x228 mm - Carbon Spring Steel phosphate and oil finish Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Housing Bore (B) 222.00 mm _{(8.74 in.)}	Clip Thickness (T) 5.00 mm + 0.72 / - 0.00 _{(0.197 in.)}	Groove Dia. (Dg) 228.00 mm + 0.00 / - 0.12 _{(8.976 in.)}	Approx. Loose Circlip OD (Dr) 232.00 mm + 1.70 / - 0.72
Material: Carbon Spring Steel phosphate and oil finish Groove Width (W): 5.15 mm + 0.20 / - 0.00 Standard: DIN472
Part Number: CCI-22200-C Internal Retaining Rings - 222x5x228 mm - Carbon Spring Steel phosphate and oil finish Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Housing Bore (B) 222.25 mm _{(8.75 in.)}	Clip Thickness (T) 4.75 mm +/- 0.204 _{(0.187 in.)}	Groove Dia. (Dg) 232.28 mm + 0.00 / - 0.12 _{(9.145 in.)}	Approx. Loose Circlip OD (Dr) 242.77 mm + 2.29 / - 2.29		Groove Width (W) 5.31 mm + 0.20 / - 0.00
Material: Carbon Steel Standard: MIL-16625
Part Number: CCI-22225-C Internal Retaining Rings - 222.25x4.75x232.28 mm - Carbon Steel Out of Stock \| Backorder Now \| Orders can be expected around Sun, Jun 08, 2025 Regular price $302.86 AUD Regular price Sale price $302.86 AUD Unit price per Each
Housing Bore (B) 222.25 mm _{(8.75 in.)}	Clip Thickness (T) 4.75 mm +/- 0.204 _{(0.187 in.)}	Groove Dia. (Dg) 232.28 mm + 0.00 / - 0.12 _{(9.145 in.)}	Approx. Loose Circlip OD (Dr) 242.77 mm + 2.29 / - 2.29
Material: Carbon Steel Groove Width (W): 5.31 mm + 0.20 / - 0.00 Standard: MIL-16625
Part Number: CCI-22225-C Internal Retaining Rings - 222.25x4.75x232.28 mm - Carbon Steel Out of Stock \| Backorder Now \| Orders can be expected around Sun, Jun 08, 2025 Regular price $302.86 AUD Regular price Sale price $302.86 AUD Unit price per Each View the product page first if you are unsure.
CCI-22225-C --- Internal Retaining Rings - 222.25x4.75x232.28 mm - Carbon Steel CCI-22225-C --- Internal Retaining Rings - 222.25x4.75x232.28 mm - Carbon Steel Regular price $302.86 AUD Regular price Sale price $302.86 AUD Unit price per Out of stock! Backorder Now
Housing Bore (B) 225.00 mm _{(8.858 in.)}	Clip Thickness (T) 5.00 mm + 0.72 / - 0.00 _{(0.197 in.)}	Groove Dia. (Dg) 236.00 mm + 0.00 / - 0.12 _{(9.291 in.)}	Approx. Loose Circlip OD (Dr) 237.00 mm + 1.70 / - 0.72		Groove Width (W) 5.15 mm + 0.20 / - 0.00
Material: Carbon Steel Clearance in Bore (C): 195.20 mm Clearance in Groove (C1): 202.00 mm Min. Lug Diameter (h): 4.00 mm Min. Extension (n): 9.00 Standard: DIN472
Part Number: CCI-22500-C Internal Retaining Rings - 225x5x236 mm - Carbon Steel Out of Stock \| Backorder Now \| Orders can be expected around Sun, Jun 08, 2025 Regular price $59.32 AUD Regular price Sale price $59.32 AUD Unit price per Each
Housing Bore (B) 225.00 mm _{(8.858 in.)}	Clip Thickness (T) 5.00 mm + 0.72 / - 0.00 _{(0.197 in.)}	Groove Dia. (Dg) 236.00 mm + 0.00 / - 0.12 _{(9.291 in.)}	Approx. Loose Circlip OD (Dr) 237.00 mm + 1.70 / - 0.72
Material: Carbon Steel Groove Width (W): 5.15 mm + 0.20 / - 0.00 Clearance in Bore (C): 195.20 mm Clearance in Groove (C1): 202.00 mm Min. Lug Diameter (h): 4.00 mm Min. Extension (n): 9.00 Standard: DIN472
Part Number: CCI-22500-C Internal Retaining Rings - 225x5x236 mm - Carbon Steel Out of Stock \| Backorder Now \| Orders can be expected around Sun, Jun 08, 2025 Regular price $59.32 AUD Regular price Sale price $59.32 AUD Unit price per Each View the product page first if you are unsure.
CCI-22500-C --- Internal Retaining Rings - 225x5x236 mm - Carbon Steel CCI-22500-C --- Internal Retaining Rings - 225x5x236 mm - Carbon Steel Regular price $59.32 AUD Regular price Sale price $59.32 AUD Unit price per Out of stock! Backorder Now
Housing Bore (B) 227.00 mm _{(8.937 in.)}	Clip Thickness (T) 5.00 mm + 0.72 / - 0.00 _{(0.197 in.)}	Groove Dia. (Dg) 233.00 mm + 0.00 / - 0.12 _{(9.173 in.)}	Approx. Loose Circlip OD (Dr) 237.00 mm + 1.70 / - 0.72		Groove Width (W) 5.15 mm + 0.20 / - 0.00
Material: Carbon Spring Steel phosphate and oil finish Standard: DIN472
Part Number: CCI-22700-C Internal Retaining Rings - 227x5x233 mm - Carbon Spring Steel phosphate and oil finish Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Housing Bore (B) 227.00 mm _{(8.937 in.)}	Clip Thickness (T) 5.00 mm + 0.72 / - 0.00 _{(0.197 in.)}	Groove Dia. (Dg) 233.00 mm + 0.00 / - 0.12 _{(9.173 in.)}	Approx. Loose Circlip OD (Dr) 237.00 mm + 1.70 / - 0.72
Material: Carbon Spring Steel phosphate and oil finish Groove Width (W): 5.15 mm + 0.20 / - 0.00 Standard: DIN472
Part Number: CCI-22700-C Internal Retaining Rings - 227x5x233 mm - Carbon Spring Steel phosphate and oil finish Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Housing Bore (B) 228.00 mm _{(8.976 in.)}	Clip Thickness (T) 5.00 mm + 0.72 / - 0.00 _{(0.197 in.)}	Groove Dia. (Dg) 234.00 mm + 0.00 / - 0.12 _{(9.213 in.)}	Approx. Loose Circlip OD (Dr) 242.00 mm + 1.70 / - 0.72		Groove Width (W) 5.15 mm + 0.20 / - 0.00
Material: Carbon Spring Steel phosphate and oil finish Standard: DIN472
Part Number: CCI-22800-C Internal Retaining Rings - 228x5x234 mm - Carbon Spring Steel phosphate and oil finish Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Housing Bore (B) 228.00 mm _{(8.976 in.)}	Clip Thickness (T) 5.00 mm + 0.72 / - 0.00 _{(0.197 in.)}	Groove Dia. (Dg) 234.00 mm + 0.00 / - 0.12 _{(9.213 in.)}	Approx. Loose Circlip OD (Dr) 242.00 mm + 1.70 / - 0.72
Material: Carbon Spring Steel phosphate and oil finish Groove Width (W): 5.15 mm + 0.20 / - 0.00 Standard: DIN472
Part Number: CCI-22800-C Internal Retaining Rings - 228x5x234 mm - Carbon Spring Steel phosphate and oil finish Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Housing Bore (B) 228.60 mm _{(9 in.)}	Clip Thickness (T) 4.75 mm +/- 0.204 _{(0.187 in.)}	Groove Dia. (Dg) 238.89 mm + 0.00 / - 0.12 _{(9.405 in.)}	Approx. Loose Circlip OD (Dr) 253.75 mm + 2.29 / - 2.29		Groove Width (W) 5.31 mm + 0.20 / - 0.00
Material: Carbon Steel Standard: MIL-16625
Part Number: CCI-22860-C Internal Retaining Rings - 228.6x4.75x238.89 mm - Carbon Steel Out of Stock \| Backorder Now \| Orders can be expected around Sun, Jun 08, 2025 Regular price $326.05 AUD Regular price Sale price $326.05 AUD Unit price per Each
Housing Bore (B) 228.60 mm _{(9 in.)}	Clip Thickness (T) 4.75 mm +/- 0.204 _{(0.187 in.)}	Groove Dia. (Dg) 238.89 mm + 0.00 / - 0.12 _{(9.405 in.)}	Approx. Loose Circlip OD (Dr) 253.75 mm + 2.29 / - 2.29
Material: Carbon Steel Groove Width (W): 5.31 mm + 0.20 / - 0.00 Standard: MIL-16625
Part Number: CCI-22860-C Internal Retaining Rings - 228.6x4.75x238.89 mm - Carbon Steel Out of Stock \| Backorder Now \| Orders can be expected around Sun, Jun 08, 2025 Regular price $326.05 AUD Regular price Sale price $326.05 AUD Unit price per Each View the product page first if you are unsure.
CCI-22860-C --- Internal Retaining Rings - 228.6x4.75x238.89 mm - Carbon Steel CCI-22860-C --- Internal Retaining Rings - 228.6x4.75x238.89 mm - Carbon Steel Regular price $326.05 AUD Regular price Sale price $326.05 AUD Unit price per Out of stock! Backorder Now
Housing Bore (B) 230.00 mm _{(9.055 in.)}	Clip Thickness (T) 5.00 mm + 0.72 / - 0.00 _{(0.197 in.)}	Groove Dia. (Dg) 236.00 mm + 0.00 / - 0.12 _{(9.291 in.)}	Approx. Loose Circlip OD (Dr) 242.00 mm + 1.70 / - 0.72		Groove Width (W) 5.15 mm + 0.20 / - 0.00
Material: Carbon Steel Clearance in Bore (C): 200.20 mm Clearance in Groove (C1): 207.00 mm Min. Lug Diameter (h): 4.00 mm Min. Extension (n): 9.00 Standard: DIN472
Part Number: CCI-23000-C Internal Retaining Rings - 230x5x236 mm - Carbon Steel Out of Stock \| Backorder Now \| Orders can be expected around Sun, Jun 08, 2025 Regular price $60.86 AUD Regular price Sale price $60.86 AUD Unit price per Each
Housing Bore (B) 230.00 mm _{(9.055 in.)}	Clip Thickness (T) 5.00 mm + 0.72 / - 0.00 _{(0.197 in.)}	Groove Dia. (Dg) 236.00 mm + 0.00 / - 0.12 _{(9.291 in.)}	Approx. Loose Circlip OD (Dr) 242.00 mm + 1.70 / - 0.72
Material: Carbon Steel Groove Width (W): 5.15 mm + 0.20 / - 0.00 Clearance in Bore (C): 200.20 mm Clearance in Groove (C1): 207.00 mm Min. Lug Diameter (h): 4.00 mm Min. Extension (n): 9.00 Standard: DIN472
Part Number: CCI-23000-C Internal Retaining Rings - 230x5x236 mm - Carbon Steel Out of Stock \| Backorder Now \| Orders can be expected around Sun, Jun 08, 2025 Regular price $60.86 AUD Regular price Sale price $60.86 AUD Unit price per Each View the product page first if you are unsure.
CCI-23000-C --- Internal Retaining Rings - 230x5x236 mm - Carbon Steel CCI-23000-C --- Internal Retaining Rings - 230x5x236 mm - Carbon Steel Regular price $60.86 AUD Regular price Sale price $60.86 AUD Unit price per Out of stock! Backorder Now
Housing Bore (B) 232.00 mm _{(9.134 in.)}	Clip Thickness (T) 5.00 mm + 0.72 / - 0.00 _{(0.197 in.)}	Groove Dia. (Dg) 238.00 mm + 0.00 / - 0.12 _{(9.37 in.)}	Approx. Loose Circlip OD (Dr) 242.00 mm + 1.70 / - 0.72		Groove Width (W) 5.15 mm + 0.20 / - 0.00
Material: Carbon Spring Steel phosphate and oil finish Standard: DIN472
Part Number: CCI-23200-C Internal Retaining Rings - 232x5x238 mm - Carbon Spring Steel phosphate and oil finish Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Housing Bore (B) 232.00 mm _{(9.134 in.)}	Clip Thickness (T) 5.00 mm + 0.72 / - 0.00 _{(0.197 in.)}	Groove Dia. (Dg) 238.00 mm + 0.00 / - 0.12 _{(9.37 in.)}	Approx. Loose Circlip OD (Dr) 242.00 mm + 1.70 / - 0.72
Material: Carbon Spring Steel phosphate and oil finish Groove Width (W): 5.15 mm + 0.20 / - 0.00 Standard: DIN472
Part Number: CCI-23200-C Internal Retaining Rings - 232x5x238 mm - Carbon Spring Steel phosphate and oil finish Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Housing Bore (B) 235.00 mm _{(9.252 in.)}	Clip Thickness (T) 5.00 mm + 0.72 / - 0.00 _{(0.197 in.)}	Groove Dia. (Dg) 241.00 mm + 0.00 / - 0.12 _{(9.488 in.)}	Approx. Loose Circlip OD (Dr) 247.00 mm + 2.00 / - 0.81		Groove Width (W) 5.15 mm + 0.20 / - 0.00
Material: Carbon Steel Min. Extension (n): 9.00 Standard: DIN472
Part Number: CCI-23500-C Internal Retaining Rings - 235x5x241 mm - Carbon Steel Out of Stock \| Backorder Now \| Orders can be expected around Sun, Jun 08, 2025 Regular price $56.95 AUD Regular price Sale price $56.95 AUD Unit price per Each
Housing Bore (B) 235.00 mm _{(9.252 in.)}	Clip Thickness (T) 5.00 mm + 0.72 / - 0.00 _{(0.197 in.)}	Groove Dia. (Dg) 241.00 mm + 0.00 / - 0.12 _{(9.488 in.)}	Approx. Loose Circlip OD (Dr) 247.00 mm + 2.00 / - 0.81
Material: Carbon Steel Groove Width (W): 5.15 mm + 0.20 / - 0.00 Min. Extension (n): 9.00 Standard: DIN472
Part Number: CCI-23500-C Internal Retaining Rings - 235x5x241 mm - Carbon Steel Out of Stock \| Backorder Now \| Orders can be expected around Sun, Jun 08, 2025 Regular price $56.95 AUD Regular price Sale price $56.95 AUD Unit price per Each View the product page first if you are unsure.
CCI-23500-C --- Internal Retaining Rings - 235x5x241 mm - Carbon Steel CCI-23500-C --- Internal Retaining Rings - 235x5x241 mm - Carbon Steel Regular price $56.95 AUD Regular price Sale price $56.95 AUD Unit price per Out of stock! Backorder Now
Housing Bore (B) 237.00 mm _{(9.331 in.)}	Clip Thickness (T) 5.00 mm + 0.72 / - 0.00 _{(0.197 in.)}	Groove Dia. (Dg) 243.00 mm + 0.00 / - 0.12 _{(9.567 in.)}	Approx. Loose Circlip OD (Dr) 247.00 mm + 2.00 / - 0.81		Groove Width (W) 5.15 mm + 0.20 / - 0.00
Material: Carbon Spring Steel phosphate and oil finish Standard: DIN472
Part Number: CCI-23700-C Internal Retaining Rings - 237x5x243 mm - Carbon Spring Steel phosphate and oil finish Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Housing Bore (B) 237.00 mm _{(9.331 in.)}	Clip Thickness (T) 5.00 mm + 0.72 / - 0.00 _{(0.197 in.)}	Groove Dia. (Dg) 243.00 mm + 0.00 / - 0.12 _{(9.567 in.)}	Approx. Loose Circlip OD (Dr) 247.00 mm + 2.00 / - 0.81
Material: Carbon Spring Steel phosphate and oil finish Groove Width (W): 5.15 mm + 0.20 / - 0.00 Standard: DIN472
Part Number: CCI-23700-C Internal Retaining Rings - 237x5x243 mm - Carbon Spring Steel phosphate and oil finish Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Housing Bore (B) 238.00 mm _{(9.37 in.)}	Clip Thickness (T) 5.00 mm + 0.72 / - 0.00 _{(0.197 in.)}	Groove Dia. (Dg) 244.00 mm + 0.00 / - 0.12 _{(9.606 in.)}	Approx. Loose Circlip OD (Dr) 252.00 mm + 2.00 / - 0.81		Groove Width (W) 5.15 mm + 0.20 / - 0.00
Material: Carbon Spring Steel phosphate and oil finish Standard: DIN472
Part Number: CCI-23800-C Internal Retaining Rings - 238x5x244 mm - Carbon Spring Steel phosphate and oil finish Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Housing Bore (B) 238.00 mm _{(9.37 in.)}	Clip Thickness (T) 5.00 mm + 0.72 / - 0.00 _{(0.197 in.)}	Groove Dia. (Dg) 244.00 mm + 0.00 / - 0.12 _{(9.606 in.)}	Approx. Loose Circlip OD (Dr) 252.00 mm + 2.00 / - 0.81
Material: Carbon Spring Steel phosphate and oil finish Groove Width (W): 5.15 mm + 0.20 / - 0.00 Standard: DIN472
Part Number: CCI-23800-C Internal Retaining Rings - 238x5x244 mm - Carbon Spring Steel phosphate and oil finish Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Housing Bore (B) 240.00 mm _{(9.449 in.)}	Clip Thickness (T) 5.00 mm + 0.72 / - 0.00 _{(0.197 in.)}	Groove Dia. (Dg) 246.00 mm + 0.00 / - 0.12 _{(9.685 in.)}	Approx. Loose Circlip OD (Dr) 252.00 mm + 2.00 / - 0.81		Groove Width (W) 5.15 mm + 0.20 / - 0.00
Material: Carbon Steel Clearance in Bore (C): 210.20 mm Clearance in Groove (C1): 217.00 mm Min. Lug Diameter (h): 4.00 mm Min. Extension (n): 9.00 Standard: DIN472
Part Number: CCI-24000-C Internal Retaining Rings - 240x5x246 mm - Carbon Steel Out of Stock \| Backorder Now \| Orders can be expected around Sun, Jun 08, 2025 Regular price $65.41 AUD Regular price Sale price $65.41 AUD Unit price per Each
Housing Bore (B) 240.00 mm _{(9.449 in.)}	Clip Thickness (T) 5.00 mm + 0.72 / - 0.00 _{(0.197 in.)}	Groove Dia. (Dg) 246.00 mm + 0.00 / - 0.12 _{(9.685 in.)}	Approx. Loose Circlip OD (Dr) 252.00 mm + 2.00 / - 0.81
Material: Carbon Steel Groove Width (W): 5.15 mm + 0.20 / - 0.00 Clearance in Bore (C): 210.20 mm Clearance in Groove (C1): 217.00 mm Min. Lug Diameter (h): 4.00 mm Min. Extension (n): 9.00 Standard: DIN472
Part Number: CCI-24000-C Internal Retaining Rings - 240x5x246 mm - Carbon Steel Out of Stock \| Backorder Now \| Orders can be expected around Sun, Jun 08, 2025 Regular price $65.41 AUD Regular price Sale price $65.41 AUD Unit price per Each View the product page first if you are unsure.
CCI-24000-C --- Internal Retaining Rings - 240x5x246 mm - Carbon Steel CCI-24000-C --- Internal Retaining Rings - 240x5x246 mm - Carbon Steel Regular price $65.41 AUD Regular price Sale price $65.41 AUD Unit price per Out of stock! Backorder Now
Housing Bore (B) 242.00 mm _{(9.528 in.)}	Clip Thickness (T) 5.00 mm + 0.72 / - 0.00 _{(0.197 in.)}	Groove Dia. (Dg) 248.00 mm + 0.00 / - 0.12 _{(9.764 in.)}	Approx. Loose Circlip OD (Dr) 252.00 mm + 2.00 / - 0.81		Groove Width (W) 5.15 mm + 0.20 / - 0.00
Material: Carbon Spring Steel phosphate and oil finish Standard: DIN472
Part Number: CCI-24200-C Internal Retaining Rings - 242x5x248 mm - Carbon Spring Steel phosphate and oil finish Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Housing Bore (B) 242.00 mm _{(9.528 in.)}	Clip Thickness (T) 5.00 mm + 0.72 / - 0.00 _{(0.197 in.)}	Groove Dia. (Dg) 248.00 mm + 0.00 / - 0.12 _{(9.764 in.)}	Approx. Loose Circlip OD (Dr) 252.00 mm + 2.00 / - 0.81
Material: Carbon Spring Steel phosphate and oil finish Groove Width (W): 5.15 mm + 0.20 / - 0.00 Standard: DIN472
Part Number: CCI-24200-C Internal Retaining Rings - 242x5x248 mm - Carbon Spring Steel phosphate and oil finish Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Housing Bore (B) 247.00 mm _{(9.724 in.)}	Clip Thickness (T) 5.00 mm + 0.81 / - 0.00 _{(0.197 in.)}	Groove Dia. (Dg) 253.00 mm + 0.00 / - 0.12 _{(9.961 in.)}	Approx. Loose Circlip OD (Dr) 257.00 mm + 2.00 / - 0.81		Groove Width (W) 5.15 mm + 0.20 / - 0.00
Material: Carbon Spring Steel phosphate and oil finish Standard: DIN472
Part Number: CCI-24700-C Internal Retaining Rings - 247x5x253 mm - Carbon Spring Steel phosphate and oil finish Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Housing Bore (B) 247.00 mm _{(9.724 in.)}	Clip Thickness (T) 5.00 mm + 0.81 / - 0.00 _{(0.197 in.)}	Groove Dia. (Dg) 253.00 mm + 0.00 / - 0.12 _{(9.961 in.)}	Approx. Loose Circlip OD (Dr) 257.00 mm + 2.00 / - 0.81
Material: Carbon Spring Steel phosphate and oil finish Groove Width (W): 5.15 mm + 0.20 / - 0.00 Standard: DIN472
Part Number: CCI-24700-C Internal Retaining Rings - 247x5x253 mm - Carbon Spring Steel phosphate and oil finish Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Housing Bore (B) 248.00 mm _{(9.764 in.)}	Clip Thickness (T) 5.00 mm + 0.81 / - 0.00 _{(0.197 in.)}	Groove Dia. (Dg) 254.00 mm + 0.00 / - 0.12 _{(10 in.)}	Approx. Loose Circlip OD (Dr) 262.00 mm + 2.00 / - 0.81		Groove Width (W) 5.15 mm + 0.20 / - 0.00
Material: Carbon Spring Steel phosphate and oil finish Standard: DIN472
Part Number: CCI-24800-C Internal Retaining Rings - 248x5x254 mm - Carbon Spring Steel phosphate and oil finish Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Housing Bore (B) 248.00 mm _{(9.764 in.)}	Clip Thickness (T) 5.00 mm + 0.81 / - 0.00 _{(0.197 in.)}	Groove Dia. (Dg) 254.00 mm + 0.00 / - 0.12 _{(10 in.)}	Approx. Loose Circlip OD (Dr) 262.00 mm + 2.00 / - 0.81
Material: Carbon Spring Steel phosphate and oil finish Groove Width (W): 5.15 mm + 0.20 / - 0.00 Standard: DIN472
Part Number: CCI-24800-C Internal Retaining Rings - 248x5x254 mm - Carbon Spring Steel phosphate and oil finish Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Housing Bore (B) 250.00 mm _{(9.843 in.)}	Clip Thickness (T) 5.00 mm + 0.81 / - 0.00 _{(0.197 in.)}	Groove Dia. (Dg) 256.00 mm + 0.00 / - 0.12 _{(10.079 in.)}	Approx. Loose Circlip OD (Dr) 262.00 mm + 2.00 / - 0.81		Groove Width (W) 5.15 mm + 0.20 / - 0.00
Material: Carbon Steel Clearance in Bore (C): 220.20 mm Clearance in Groove (C1): 227.00 mm Min. Lug Diameter (h): 4.00 mm Min. Extension (n): 9.00 Standard: DIN472
Part Number: CCI-25000-C Internal Retaining Rings - 250x5x256 mm - Carbon Steel Out of Stock \| Backorder Now \| Orders can be expected around Sun, Jun 08, 2025 Regular price $73.86 AUD Regular price Sale price $73.86 AUD Unit price per Each
Housing Bore (B) 250.00 mm _{(9.843 in.)}	Clip Thickness (T) 5.00 mm + 0.81 / - 0.00 _{(0.197 in.)}	Groove Dia. (Dg) 256.00 mm + 0.00 / - 0.12 _{(10.079 in.)}	Approx. Loose Circlip OD (Dr) 262.00 mm + 2.00 / - 0.81
Material: Carbon Steel Groove Width (W): 5.15 mm + 0.20 / - 0.00 Clearance in Bore (C): 220.20 mm Clearance in Groove (C1): 227.00 mm Min. Lug Diameter (h): 4.00 mm Min. Extension (n): 9.00 Standard: DIN472
Part Number: CCI-25000-C Internal Retaining Rings - 250x5x256 mm - Carbon Steel Out of Stock \| Backorder Now \| Orders can be expected around Sun, Jun 08, 2025 Regular price $73.86 AUD Regular price Sale price $73.86 AUD Unit price per Each View the product page first if you are unsure.
CCI-25000-C --- Internal Retaining Rings - 250x5x256 mm - Carbon Steel CCI-25000-C --- Internal Retaining Rings - 250x5x256 mm - Carbon Steel Regular price $73.86 AUD Regular price Sale price $73.86 AUD Unit price per Out of stock! Backorder Now
Housing Bore (B) 252.00 mm _{(9.921 in.)}	Clip Thickness (T) 5.00 mm + 0.81 / - 0.00 _{(0.197 in.)}	Groove Dia. (Dg) 260.00 mm + 0.00 / - 0.12 _{(10.236 in.)}	Approx. Loose Circlip OD (Dr) 262.00 mm + 2.00 / - 0.81		Groove Width (W) 5.15 mm + 0.20 / - 0.00
Material: Carbon Spring Steel phosphate and oil finish Standard: DIN472
Part Number: CCI-25200-C Internal Retaining Rings - 252x5x260 mm - Carbon Spring Steel phosphate and oil finish Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Housing Bore (B) 252.00 mm _{(9.921 in.)}	Clip Thickness (T) 5.00 mm + 0.81 / - 0.00 _{(0.197 in.)}	Groove Dia. (Dg) 260.00 mm + 0.00 / - 0.12 _{(10.236 in.)}	Approx. Loose Circlip OD (Dr) 262.00 mm + 2.00 / - 0.81
Material: Carbon Spring Steel phosphate and oil finish Groove Width (W): 5.15 mm + 0.20 / - 0.00 Standard: DIN472
Part Number: CCI-25200-C Internal Retaining Rings - 252x5x260 mm - Carbon Spring Steel phosphate and oil finish Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Housing Bore (B) 254.00 mm _{(10 in.)}	Clip Thickness (T) 4.75 mm +/- 0.178 _{(0.187 in.)}	Groove Dia. (Dg) 265.43 mm + 0.00 / - 0.12 _{(10.45 in.)}	Approx. Loose Circlip OD (Dr) 281.94 mm + 2.29 / - 2.29		Groove Width (W) 5.71 mm + 0.20 / - 0.00
Material: Carbon Steel Standard: MIL-16625
Part Number: CCI-25400-C Internal Retaining Rings - 254x4.75x265.43 mm - Carbon Steel Out of Stock \| Backorder Now \| Orders can be expected around Fri, Aug 08, 2025 Regular price $371.86 AUD Regular price Sale price $371.86 AUD Unit price per Each
Housing Bore (B) 254.00 mm _{(10 in.)}	Clip Thickness (T) 4.75 mm +/- 0.178 _{(0.187 in.)}	Groove Dia. (Dg) 265.43 mm + 0.00 / - 0.12 _{(10.45 in.)}	Approx. Loose Circlip OD (Dr) 281.94 mm + 2.29 / - 2.29
Material: Carbon Steel Groove Width (W): 5.71 mm + 0.20 / - 0.00 Standard: MIL-16625
Part Number: CCI-25400-C Internal Retaining Rings - 254x4.75x265.43 mm - Carbon Steel Out of Stock \| Backorder Now \| Orders can be expected around Fri, Aug 08, 2025 Regular price $371.86 AUD Regular price Sale price $371.86 AUD Unit price per Each View the product page first if you are unsure.
CCI-25400-C --- Internal Retaining Rings - 254x4.75x265.43 mm - Carbon Steel CCI-25400-C --- Internal Retaining Rings - 254x4.75x265.43 mm - Carbon Steel Regular price $371.86 AUD Regular price Sale price $371.86 AUD Unit price per Out of stock! Backorder Now
Housing Bore (B) 255.00 mm _{(10.039 in.)}	Clip Thickness (T) 5.00 mm + 0.81 / - 0.00 _{(0.197 in.)}	Groove Dia. (Dg) 263.00 mm + 0.00 / - 0.12 _{(10.354 in.)}	Approx. Loose Circlip OD (Dr) 270.00 mm + 2.00 / - 0.81		Groove Width (W) 5.15 mm + 0.20 / - 0.00
Material: Carbon Steel Standard: DIN472
Part Number: CCI-25500-C Internal Retaining Rings - 255x5x263 mm - Carbon Steel Out of Stock \| Backorder Now \| Orders can be expected around Sun, Jun 08, 2025 Regular price $113.14 AUD Regular price Sale price $113.14 AUD Unit price per Each
Housing Bore (B) 255.00 mm _{(10.039 in.)}	Clip Thickness (T) 5.00 mm + 0.81 / - 0.00 _{(0.197 in.)}	Groove Dia. (Dg) 263.00 mm + 0.00 / - 0.12 _{(10.354 in.)}	Approx. Loose Circlip OD (Dr) 270.00 mm + 2.00 / - 0.81
Material: Carbon Steel Groove Width (W): 5.15 mm + 0.20 / - 0.00 Standard: DIN472
Part Number: CCI-25500-C Internal Retaining Rings - 255x5x263 mm - Carbon Steel Out of Stock \| Backorder Now \| Orders can be expected around Sun, Jun 08, 2025 Regular price $113.14 AUD Regular price Sale price $113.14 AUD Unit price per Each View the product page first if you are unsure.
CCI-25500-C --- Internal Retaining Rings - 255x5x263 mm - Carbon Steel CCI-25500-C --- Internal Retaining Rings - 255x5x263 mm - Carbon Steel Regular price $113.14 AUD Regular price Sale price $113.14 AUD Unit price per Out of stock! Backorder Now
Housing Bore (B) 257.00 mm _{(10.118 in.)}	Clip Thickness (T) 5.00 mm + 0.81 / - 0.00 _{(0.197 in.)}	Groove Dia. (Dg) 265.00 mm + 0.00 / - 0.12 _{(10.433 in.)}	Approx. Loose Circlip OD (Dr) 270.00 mm + 2.00 / - 0.81		Groove Width (W) 5.15 mm + 0.20 / - 0.00
Material: Carbon Spring Steel phosphate and oil finish Standard: DIN472
Part Number: CCI-25700-C Internal Retaining Rings - 257x5x265 mm - Carbon Spring Steel phosphate and oil finish Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Housing Bore (B) 257.00 mm _{(10.118 in.)}	Clip Thickness (T) 5.00 mm + 0.81 / - 0.00 _{(0.197 in.)}	Groove Dia. (Dg) 265.00 mm + 0.00 / - 0.12 _{(10.433 in.)}	Approx. Loose Circlip OD (Dr) 270.00 mm + 2.00 / - 0.81
Material: Carbon Spring Steel phosphate and oil finish Groove Width (W): 5.15 mm + 0.20 / - 0.00 Standard: DIN472
Part Number: CCI-25700-C Internal Retaining Rings - 257x5x265 mm - Carbon Spring Steel phosphate and oil finish Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Housing Bore (B) 258.00 mm _{(10.157 in.)}	Clip Thickness (T) 5.00 mm + 0.81 / - 0.00 _{(0.197 in.)}	Groove Dia. (Dg) 266.00 mm + 0.00 / - 0.12 _{(10.472 in.)}	Approx. Loose Circlip OD (Dr) 275.00 mm + 2.00 / - 0.81		Groove Width (W) 5.15 mm + 0.20 / - 0.00
Material: Carbon Spring Steel phosphate and oil finish Standard: DIN472
Part Number: CCI-25800-C Internal Retaining Rings - 258x5x266 mm - Carbon Spring Steel phosphate and oil finish Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Housing Bore (B) 258.00 mm _{(10.157 in.)}	Clip Thickness (T) 5.00 mm + 0.81 / - 0.00 _{(0.197 in.)}	Groove Dia. (Dg) 266.00 mm + 0.00 / - 0.12 _{(10.472 in.)}	Approx. Loose Circlip OD (Dr) 275.00 mm + 2.00 / - 0.81
Material: Carbon Spring Steel phosphate and oil finish Groove Width (W): 5.15 mm + 0.20 / - 0.00 Standard: DIN472
Part Number: CCI-25800-C Internal Retaining Rings - 258x5x266 mm - Carbon Spring Steel phosphate and oil finish Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Housing Bore (B) 260.00 mm _{(10.236 in.)}	Clip Thickness (T) 5.00 mm + 0.81 / - 0.00 _{(0.197 in.)}	Groove Dia. (Dg) 268.00 mm + 0.00 / - 0.12 _{(10.551 in.)}	Approx. Loose Circlip OD (Dr) 275.00 mm + 2.00 / - 0.81		Groove Width (W) 5.15 mm + 0.20 / - 0.00
Material: Carbon Steel Clearance in Bore (C): 226.00 mm Clearance in Groove (C1): 235.00 mm Min. Lug Diameter (h): 5.00 mm Min. Extension (n): 12.00 Standard: DIN472
Part Number: CCI-26000-C Internal Retaining Rings - 260x5x268 mm - Carbon Steel Out of Stock \| Backorder Now \| Orders can be expected around Sun, Jun 08, 2025 Regular price $82.50 AUD Regular price Sale price $82.50 AUD Unit price per Each
Housing Bore (B) 260.00 mm _{(10.236 in.)}	Clip Thickness (T) 5.00 mm + 0.81 / - 0.00 _{(0.197 in.)}	Groove Dia. (Dg) 268.00 mm + 0.00 / - 0.12 _{(10.551 in.)}	Approx. Loose Circlip OD (Dr) 275.00 mm + 2.00 / - 0.81
Material: Carbon Steel Groove Width (W): 5.15 mm + 0.20 / - 0.00 Clearance in Bore (C): 226.00 mm Clearance in Groove (C1): 235.00 mm Min. Lug Diameter (h): 5.00 mm Min. Extension (n): 12.00 Standard: DIN472
Part Number: CCI-26000-C Internal Retaining Rings - 260x5x268 mm - Carbon Steel Out of Stock \| Backorder Now \| Orders can be expected around Sun, Jun 08, 2025 Regular price $82.50 AUD Regular price Sale price $82.50 AUD Unit price per Each View the product page first if you are unsure.
CCI-26000-C --- Internal Retaining Rings - 260x5x268 mm - Carbon Steel CCI-26000-C --- Internal Retaining Rings - 260x5x268 mm - Carbon Steel Regular price $82.50 AUD Regular price Sale price $82.50 AUD Unit price per Out of stock! Backorder Now
Housing Bore (B) 262.00 mm _{(10.315 in.)}	Clip Thickness (T) 5.00 mm + 0.81 / - 0.00 _{(0.197 in.)}	Groove Dia. (Dg) 270.00 mm + 0.00 / - 0.12 _{(10.63 in.)}	Approx. Loose Circlip OD (Dr) 275.00 mm + 2.00 / - 0.81		Groove Width (W) 5.15 mm + 0.20 / - 0.00
Material: Carbon Spring Steel phosphate and oil finish Standard: DIN472
Part Number: CCI-26200-C Internal Retaining Rings - 262x5x270 mm - Carbon Spring Steel phosphate and oil finish Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Housing Bore (B) 262.00 mm _{(10.315 in.)}	Clip Thickness (T) 5.00 mm + 0.81 / - 0.00 _{(0.197 in.)}	Groove Dia. (Dg) 270.00 mm + 0.00 / - 0.12 _{(10.63 in.)}	Approx. Loose Circlip OD (Dr) 275.00 mm + 2.00 / - 0.81
Material: Carbon Spring Steel phosphate and oil finish Groove Width (W): 5.15 mm + 0.20 / - 0.00 Standard: DIN472
Part Number: CCI-26200-C Internal Retaining Rings - 262x5x270 mm - Carbon Spring Steel phosphate and oil finish Contact Us \| Item Discontinued - Please contact us if you need a large quantity
