Collection: Retaining Rings - Internal - Circlips - Standard - Carbon Steel

Retaining Rings (With Images)

Internal

Circlips

Standard

328 Products in this selection

Imperial and metric DIN471 and 472 / D1300 / N1300 / Seeger J and JS. Retaining rings. Snap Rings (USA).
Plain carbon steel
Tolerances on request.

Additional resources:
Anderton Cross Reference PDF
Circlips PDF Catalogue
Circlip Tools

A more concise listing may be found on the Smallparts store at Retaining Rings - Internal - Circlips - Standard - Carbon Steel. Smallparts promote the most popular MBA products.

Housing Bore (B)	Clip Thickness (T)	Groove Dia. (Dg)	Approx. Loose Circlip OD (Dr)	Radial Wall (S)	Groove Width (W)
Housing Bore (B) 185.00 mm _{(7.283 in.)}	Clip Thickness (T) 5.00 mm + 0.72 / - 0.00 _{(0.197 in.)}	Groove Dia. (Dg) 190.00 mm + 0.00 / - 0.12 _{(7.48 in.)}	Approx. Loose Circlip OD (Dr) 194.50 mm + 1.70 / - 0.72		Groove Width (W) 5.15 mm + 0.20 / - 0.00
Material: Carbon Spring Steel Self Finish Standard: DIN472
Part Number: CCI-18500H-C Internal Retaining Rings - 185x5x190 mm - Carbon Spring Steel Self Finish Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Housing Bore (B)	Clip Thickness (T)	Groove Dia. (Dg)	Approx. Loose Circlip OD (Dr)	Indicative Image
Housing Bore (B) 185.00 mm _{(7.283 in.)}	Clip Thickness (T) 5.00 mm + 0.72 / - 0.00 _{(0.197 in.)}	Groove Dia. (Dg) 190.00 mm + 0.00 / - 0.12 _{(7.48 in.)}	Approx. Loose Circlip OD (Dr) 194.50 mm + 1.70 / - 0.72
Material: Carbon Spring Steel Self Finish Groove Width (W): 5.15 mm + 0.20 / - 0.00 Standard: DIN472
Part Number: CCI-18500H-C Internal Retaining Rings - 185x5x190 mm - Carbon Spring Steel Self Finish Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Housing Bore (B) 187.00 mm _{(7.362 in.)}	Clip Thickness (T) 4.00 mm + 0.72 / - 0.00 _{(0.157 in.)}	Groove Dia. (Dg) 192.00 mm + 0.00 / - 0.10 _{(7.559 in.)}	Approx. Loose Circlip OD (Dr) 197.50 mm + 1.70 / - 0.72		Groove Width (W) 4.15 mm + 0.20 / - 0.00
Material: Carbon Spring Steel phosphate and oil finish Min. Extension (n): 7.50 Standard: DIN472
Part Number: CCI-18700-C Internal Retaining Rings - 187x4x192 mm - Carbon Spring Steel phosphate and oil finish Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Housing Bore (B) 187.00 mm _{(7.362 in.)}	Clip Thickness (T) 4.00 mm + 0.72 / - 0.00 _{(0.157 in.)}	Groove Dia. (Dg) 192.00 mm + 0.00 / - 0.10 _{(7.559 in.)}	Approx. Loose Circlip OD (Dr) 197.50 mm + 1.70 / - 0.72
Material: Carbon Spring Steel phosphate and oil finish Groove Width (W): 4.15 mm + 0.20 / - 0.00 Min. Extension (n): 7.50 Standard: DIN472
Part Number: CCI-18700-C Internal Retaining Rings - 187x4x192 mm - Carbon Spring Steel phosphate and oil finish Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Housing Bore (B) 188.00 mm _{(7.402 in.)}	Clip Thickness (T) 4.00 mm + 0.72 / - 0.00 _{(0.157 in.)}	Groove Dia. (Dg) 193.00 mm + 0.00 / - 0.10 _{(7.598 in.)}	Approx. Loose Circlip OD (Dr) 197.50 mm + 1.70 / - 0.72		Groove Width (W) 4.15 mm + 0.20 / - 0.00
Material: Carbon Spring Steel phosphate and oil finish Min. Extension (n): 7.50 Standard: DIN472
Part Number: CCI-18800-C Internal Retaining Rings - 188x4x193 mm - Carbon Spring Steel phosphate and oil finish Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Housing Bore (B) 188.00 mm _{(7.402 in.)}	Clip Thickness (T) 4.00 mm + 0.72 / - 0.00 _{(0.157 in.)}	Groove Dia. (Dg) 193.00 mm + 0.00 / - 0.10 _{(7.598 in.)}	Approx. Loose Circlip OD (Dr) 197.50 mm + 1.70 / - 0.72
Material: Carbon Spring Steel phosphate and oil finish Groove Width (W): 4.15 mm + 0.20 / - 0.00 Min. Extension (n): 7.50 Standard: DIN472
Part Number: CCI-18800-C Internal Retaining Rings - 188x4x193 mm - Carbon Spring Steel phosphate and oil finish Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Housing Bore (B) 190.00 mm _{(7.48 in.)}	Clip Thickness (T) 4.00 mm + 0.72 / - 0.00 _{(0.157 in.)}	Groove Dia. (Dg) 195.00 mm + 0.00 / - 0.10 _{(7.677 in.)}	Approx. Loose Circlip OD (Dr) 199.50 mm + 1.70 / - 0.72		Groove Width (W) 4.15 mm + 0.20 / - 0.00
Material: Carbon Steel Clearance in Bore (C): 160.20 mm Clearance in Groove (C1): 166.00 mm Min. Lug Diameter (h): 4.00 mm Min. Extension (n): 7.50 Standard: DIN472
Part Number: CCI-19000-C Internal Retaining Rings - 190x4x195 mm - Carbon Steel 10 Available Immediately \| Further orders can be expected around Sun, Jun 08, 2025 Regular price $36.86 AUD Regular price Sale price $36.86 AUD Unit price per Each
Housing Bore (B) 190.00 mm _{(7.48 in.)}	Clip Thickness (T) 4.00 mm + 0.72 / - 0.00 _{(0.157 in.)}	Groove Dia. (Dg) 195.00 mm + 0.00 / - 0.10 _{(7.677 in.)}	Approx. Loose Circlip OD (Dr) 199.50 mm + 1.70 / - 0.72
Material: Carbon Steel Groove Width (W): 4.15 mm + 0.20 / - 0.00 Clearance in Bore (C): 160.20 mm Clearance in Groove (C1): 166.00 mm Min. Lug Diameter (h): 4.00 mm Min. Extension (n): 7.50 Standard: DIN472
Part Number: CCI-19000-C Internal Retaining Rings - 190x4x195 mm - Carbon Steel 10 Available Immediately \| Further orders can be expected around Sun, Jun 08, 2025 Regular price $36.86 AUD Regular price Sale price $36.86 AUD Unit price per Each View the product page first if you are unsure.
CCI-19000-C --- Internal Retaining Rings - 190x4x195 mm - Carbon Steel CCI-19000-C --- Internal Retaining Rings - 190x4x195 mm - Carbon Steel Regular price $36.86 AUD Regular price Sale price $36.86 AUD Unit price per 10 Available Now
Housing Bore (B) 190.00 mm _{(7.48 in.)}	Clip Thickness (T) 5.00 mm + 0.72 / - 0.00 _{(0.197 in.)}	Groove Dia. (Dg) 195.00 mm + 0.00 / - 0.12 _{(7.677 in.)}	Approx. Loose Circlip OD (Dr) 199.50 mm + 1.70 / - 0.72		Groove Width (W) 5.15 mm + 0.20 / - 0.00
Material: Carbon Spring Steel Self Finish Standard: DIN472
Part Number: CCI-19000H-C Internal Retaining Rings - 190x5x195 mm - Carbon Spring Steel Self Finish Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Housing Bore (B) 190.00 mm _{(7.48 in.)}	Clip Thickness (T) 5.00 mm + 0.72 / - 0.00 _{(0.197 in.)}	Groove Dia. (Dg) 195.00 mm + 0.00 / - 0.12 _{(7.677 in.)}	Approx. Loose Circlip OD (Dr) 199.50 mm + 1.70 / - 0.72
Material: Carbon Spring Steel Self Finish Groove Width (W): 5.15 mm + 0.20 / - 0.00 Standard: DIN472
Part Number: CCI-19000H-C Internal Retaining Rings - 190x5x195 mm - Carbon Spring Steel Self Finish Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Housing Bore (B) 190.50 mm _{(7.5 in.)}	Clip Thickness (T) 4.75 mm +/- 0.204 _{(0.187 in.)}	Groove Dia. (Dg) 199.14 mm + 0.00 / - 0.12 _{(7.84 in.)}	Approx. Loose Circlip OD (Dr) 211.46 mm + 2.29 / - 2.29		Groove Width (W) 5.31 mm + 0.20 / - 0.00
Material: Carbon Steel Standard: MIL-16625
Part Number: CCI-19050-C Internal Retaining Rings - 190.5x4.75x199.14 mm - Carbon Steel Out of Stock \| Backorder Now \| Orders can be expected around Sun, Jun 08, 2025 Regular price $284.14 AUD Regular price Sale price $284.14 AUD Unit price per Each
Housing Bore (B) 190.50 mm _{(7.5 in.)}	Clip Thickness (T) 4.75 mm +/- 0.204 _{(0.187 in.)}	Groove Dia. (Dg) 199.14 mm + 0.00 / - 0.12 _{(7.84 in.)}	Approx. Loose Circlip OD (Dr) 211.46 mm + 2.29 / - 2.29
Material: Carbon Steel Groove Width (W): 5.31 mm + 0.20 / - 0.00 Standard: MIL-16625
Part Number: CCI-19050-C Internal Retaining Rings - 190.5x4.75x199.14 mm - Carbon Steel Out of Stock \| Backorder Now \| Orders can be expected around Sun, Jun 08, 2025 Regular price $284.14 AUD Regular price Sale price $284.14 AUD Unit price per Each View the product page first if you are unsure.
CCI-19050-C --- Internal Retaining Rings - 190.5x4.75x199.14 mm - Carbon Steel CCI-19050-C --- Internal Retaining Rings - 190.5x4.75x199.14 mm - Carbon Steel Regular price $284.14 AUD Regular price Sale price $284.14 AUD Unit price per Out of stock! Backorder Now
Housing Bore (B) 192.00 mm _{(7.559 in.)}	Clip Thickness (T) 4.00 mm + 0.72 / - 0.00 _{(0.157 in.)}	Groove Dia. (Dg) 197.00 mm + 0.00 / - 0.10 _{(7.756 in.)}	Approx. Loose Circlip OD (Dr) 201.50 mm + 1.70 / - 0.72		Groove Width (W) 4.15 mm + 0.20 / - 0.00
Material: Carbon Spring Steel phosphate and oil finish Min. Extension (n): 7.50 Standard: DIN472
Part Number: CCI-19200-C Internal Retaining Rings - 192x4x197 mm - Carbon Spring Steel phosphate and oil finish Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Housing Bore (B) 192.00 mm _{(7.559 in.)}	Clip Thickness (T) 4.00 mm + 0.72 / - 0.00 _{(0.157 in.)}	Groove Dia. (Dg) 197.00 mm + 0.00 / - 0.10 _{(7.756 in.)}	Approx. Loose Circlip OD (Dr) 201.50 mm + 1.70 / - 0.72
Material: Carbon Spring Steel phosphate and oil finish Groove Width (W): 4.15 mm + 0.20 / - 0.00 Min. Extension (n): 7.50 Standard: DIN472
Part Number: CCI-19200-C Internal Retaining Rings - 192x4x197 mm - Carbon Spring Steel phosphate and oil finish Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Housing Bore (B) 195.00 mm _{(7.677 in.)}	Clip Thickness (T) 5.00 mm + 0.72 / - 0.00 _{(0.197 in.)}	Groove Dia. (Dg) 200.00 mm + 0.00 / - 0.12 _{(7.874 in.)}	Approx. Loose Circlip OD (Dr) 204.50 mm + 1.70 / - 0.72		Groove Width (W) 5.15 mm + 0.20 / - 0.00
Material: Carbon Spring Steel Self Finish Standard: DIN472
Part Number: CCI-19500H-C Internal Retaining Rings - 195x5x200 mm - Carbon Spring Steel Self Finish Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Housing Bore (B) 195.00 mm _{(7.677 in.)}	Clip Thickness (T) 5.00 mm + 0.72 / - 0.00 _{(0.197 in.)}	Groove Dia. (Dg) 200.00 mm + 0.00 / - 0.12 _{(7.874 in.)}	Approx. Loose Circlip OD (Dr) 204.50 mm + 1.70 / - 0.72
Material: Carbon Spring Steel Self Finish Groove Width (W): 5.15 mm + 0.20 / - 0.00 Standard: DIN472
Part Number: CCI-19500H-C Internal Retaining Rings - 195x5x200 mm - Carbon Spring Steel Self Finish Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Housing Bore (B) 196.85 mm _{(7.75 in.)}	Clip Thickness (T) 4.75 mm +/- 0.204 _{(0.187 in.)}	Groove Dia. (Dg) 205.74 mm + 0.00 / - 0.12 _{(8.1 in.)}	Approx. Loose Circlip OD (Dr) 218.51 mm + 2.29 / - 2.29		Groove Width (W) 5.31 mm + 0.20 / - 0.00
Material: Carbon Steel Standard: MIL-16625
Part Number: CCI-19685-C Internal Retaining Rings - 196.85x4.75x205.74 mm - Carbon Steel Out of Stock \| Backorder Now \| Orders can be expected around Sun, Jun 08, 2025 Regular price $200.95 AUD Regular price Sale price $200.95 AUD Unit price per Each
Housing Bore (B) 196.85 mm _{(7.75 in.)}	Clip Thickness (T) 4.75 mm +/- 0.204 _{(0.187 in.)}	Groove Dia. (Dg) 205.74 mm + 0.00 / - 0.12 _{(8.1 in.)}	Approx. Loose Circlip OD (Dr) 218.51 mm + 2.29 / - 2.29
Material: Carbon Steel Groove Width (W): 5.31 mm + 0.20 / - 0.00 Standard: MIL-16625
Part Number: CCI-19685-C Internal Retaining Rings - 196.85x4.75x205.74 mm - Carbon Steel Out of Stock \| Backorder Now \| Orders can be expected around Sun, Jun 08, 2025 Regular price $200.95 AUD Regular price Sale price $200.95 AUD Unit price per Each View the product page first if you are unsure.
CCI-19685-C --- Internal Retaining Rings - 196.85x4.75x205.74 mm - Carbon Steel CCI-19685-C --- Internal Retaining Rings - 196.85x4.75x205.74 mm - Carbon Steel Regular price $200.95 AUD Regular price Sale price $200.95 AUD Unit price per Out of stock! Backorder Now
Housing Bore (B) 197.00 mm _{(7.756 in.)}	Clip Thickness (T) 4.00 mm + 0.72 / - 0.00 _{(0.157 in.)}	Groove Dia. (Dg) 202.00 mm + 0.00 / - 0.10 _{(7.953 in.)}	Approx. Loose Circlip OD (Dr) 207.50 mm + 1.70 / - 0.72		Groove Width (W) 4.15 mm + 0.20 / - 0.00
Material: Carbon Spring Steel phosphate and oil finish Min. Extension (n): 7.50 Standard: DIN472
Part Number: CCI-19700-C Internal Retaining Rings - 197x4x202 mm - Carbon Spring Steel phosphate and oil finish Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Housing Bore (B) 197.00 mm _{(7.756 in.)}	Clip Thickness (T) 4.00 mm + 0.72 / - 0.00 _{(0.157 in.)}	Groove Dia. (Dg) 202.00 mm + 0.00 / - 0.10 _{(7.953 in.)}	Approx. Loose Circlip OD (Dr) 207.50 mm + 1.70 / - 0.72
Material: Carbon Spring Steel phosphate and oil finish Groove Width (W): 4.15 mm + 0.20 / - 0.00 Min. Extension (n): 7.50 Standard: DIN472
Part Number: CCI-19700-C Internal Retaining Rings - 197x4x202 mm - Carbon Spring Steel phosphate and oil finish Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Housing Bore (B) 198.00 mm _{(7.795 in.)}	Clip Thickness (T) 4.00 mm + 0.72 / - 0.00 _{(0.157 in.)}	Groove Dia. (Dg) 203.00 mm + 0.00 / - 0.10 _{(7.992 in.)}	Approx. Loose Circlip OD (Dr) 207.50 mm + 1.70 / - 0.72		Groove Width (W) 4.15 mm + 0.20 / - 0.00
Material: Carbon Spring Steel phosphate and oil finish Min. Extension (n): 7.50 Standard: DIN472
Part Number: CCI-19800-C Internal Retaining Rings - 198x4x203 mm - Carbon Spring Steel phosphate and oil finish Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Housing Bore (B) 198.00 mm _{(7.795 in.)}	Clip Thickness (T) 4.00 mm + 0.72 / - 0.00 _{(0.157 in.)}	Groove Dia. (Dg) 203.00 mm + 0.00 / - 0.10 _{(7.992 in.)}	Approx. Loose Circlip OD (Dr) 207.50 mm + 1.70 / - 0.72
Material: Carbon Spring Steel phosphate and oil finish Groove Width (W): 4.15 mm + 0.20 / - 0.00 Min. Extension (n): 7.50 Standard: DIN472
Part Number: CCI-19800-C Internal Retaining Rings - 198x4x203 mm - Carbon Spring Steel phosphate and oil finish Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Housing Bore (B) 200.00 mm _{(7.874 in.)}	Clip Thickness (T) 4.00 mm + 0.72 / - 0.00 _{(0.157 in.)}	Groove Dia. (Dg) 205.00 mm + 0.00 / - 0.10 _{(8.071 in.)}	Approx. Loose Circlip OD (Dr) 209.50 mm + 1.70 / - 0.72		Groove Width (W) 4.15 mm + 0.20 / - 0.00
Material: Carbon Steel Clearance in Bore (C): 170.20 mm Clearance in Groove (C1): 176.00 mm Min. Lug Diameter (h): 4.00 mm Min. Extension (n): 7.50 Standard: DIN472
Part Number: CCI-20000-C Internal Retaining Rings - 200x4x205 mm - Carbon Steel Out of Stock \| Backorder Now \| Orders can be expected around Sun, Jun 08, 2025 Regular price $38.50 AUD Regular price Sale price $38.50 AUD Unit price per Each
Housing Bore (B) 200.00 mm _{(7.874 in.)}	Clip Thickness (T) 4.00 mm + 0.72 / - 0.00 _{(0.157 in.)}	Groove Dia. (Dg) 205.00 mm + 0.00 / - 0.10 _{(8.071 in.)}	Approx. Loose Circlip OD (Dr) 209.50 mm + 1.70 / - 0.72
Material: Carbon Steel Groove Width (W): 4.15 mm + 0.20 / - 0.00 Clearance in Bore (C): 170.20 mm Clearance in Groove (C1): 176.00 mm Min. Lug Diameter (h): 4.00 mm Min. Extension (n): 7.50 Standard: DIN472
Part Number: CCI-20000-C Internal Retaining Rings - 200x4x205 mm - Carbon Steel Out of Stock \| Backorder Now \| Orders can be expected around Sun, Jun 08, 2025 Regular price $38.50 AUD Regular price Sale price $38.50 AUD Unit price per Each View the product page first if you are unsure.
CCI-20000-C --- Internal Retaining Rings - 200x4x205 mm - Carbon Steel CCI-20000-C --- Internal Retaining Rings - 200x4x205 mm - Carbon Steel Regular price $38.50 AUD Regular price Sale price $38.50 AUD Unit price per Out of stock! Backorder Now
Housing Bore (B) 200.00 mm _{(7.874 in.)}	Clip Thickness (T) 5.00 mm + 0.72 / - 0.00 _{(0.197 in.)}	Groove Dia. (Dg) 205.00 mm + 0.00 / - 0.12 _{(8.071 in.)}	Approx. Loose Circlip OD (Dr) 209.50 mm + 1.70 / - 0.72		Groove Width (W) 5.15 mm + 0.20 / - 0.00
Material: Carbon Spring Steel Self Finish Standard: DIN472
Part Number: CCI-20000H-C Internal Retaining Rings - 200x5x205 mm - Carbon Spring Steel Self Finish Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Housing Bore (B) 200.00 mm _{(7.874 in.)}	Clip Thickness (T) 5.00 mm + 0.72 / - 0.00 _{(0.197 in.)}	Groove Dia. (Dg) 205.00 mm + 0.00 / - 0.12 _{(8.071 in.)}	Approx. Loose Circlip OD (Dr) 209.50 mm + 1.70 / - 0.72
Material: Carbon Spring Steel Self Finish Groove Width (W): 5.15 mm + 0.20 / - 0.00 Standard: DIN472
Part Number: CCI-20000H-C Internal Retaining Rings - 200x5x205 mm - Carbon Spring Steel Self Finish Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Housing Bore (B) 202.00 mm _{(7.953 in.)}	Clip Thickness (T) 5.00 mm + 0.72 / - 0.00 _{(0.197 in.)}	Groove Dia. (Dg) 208.00 mm + 0.00 / - 0.12 _{(8.189 in.)}	Approx. Loose Circlip OD (Dr) 214.00 mm + 1.70 / - 0.72		Groove Width (W) 5.15 mm + 0.20 / - 0.00
Material: Carbon Spring Steel phosphate and oil finish Min. Extension (n): 7.50 Standard: DIN472
Part Number: CCI-20200-C Internal Retaining Rings - 202x5x208 mm - Carbon Spring Steel phosphate and oil finish Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Housing Bore (B) 202.00 mm _{(7.953 in.)}	Clip Thickness (T) 5.00 mm + 0.72 / - 0.00 _{(0.197 in.)}	Groove Dia. (Dg) 208.00 mm + 0.00 / - 0.12 _{(8.189 in.)}	Approx. Loose Circlip OD (Dr) 214.00 mm + 1.70 / - 0.72
Material: Carbon Spring Steel phosphate and oil finish Groove Width (W): 5.15 mm + 0.20 / - 0.00 Min. Extension (n): 7.50 Standard: DIN472
Part Number: CCI-20200-C Internal Retaining Rings - 202x5x208 mm - Carbon Spring Steel phosphate and oil finish Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Housing Bore (B) 203.20 mm _{(8 in.)}	Clip Thickness (T) 4.75 mm +/- 0.204 _{(0.187 in.)}	Groove Dia. (Dg) 212.34 mm + 0.00 / - 0.12 _{(8.36 in.)}	Approx. Loose Circlip OD (Dr) 224.03 mm + 2.29 / - 2.29		Groove Width (W) 5.33 mm + 0.20 / - 0.00
Material: Carbon Steel Min. Lug Diameter (h): 4.57 mm Standard: MIL-16625
Part Number: CCI-20320-C Internal Retaining Rings - 203.2x4.75x212.34 mm - Carbon Steel Out of Stock \| Backorder Now \| Orders can be expected around Sun, Jun 08, 2025 Regular price $161.68 AUD Regular price Sale price $161.68 AUD Unit price per Each
Housing Bore (B) 203.20 mm _{(8 in.)}	Clip Thickness (T) 4.75 mm +/- 0.204 _{(0.187 in.)}	Groove Dia. (Dg) 212.34 mm + 0.00 / - 0.12 _{(8.36 in.)}	Approx. Loose Circlip OD (Dr) 224.03 mm + 2.29 / - 2.29
Material: Carbon Steel Groove Width (W): 5.33 mm + 0.20 / - 0.00 Min. Lug Diameter (h): 4.57 mm Standard: MIL-16625
Part Number: CCI-20320-C Internal Retaining Rings - 203.2x4.75x212.34 mm - Carbon Steel Out of Stock \| Backorder Now \| Orders can be expected around Sun, Jun 08, 2025 Regular price $161.68 AUD Regular price Sale price $161.68 AUD Unit price per Each View the product page first if you are unsure.
CCI-20320-C --- Internal Retaining Rings - 203.2x4.75x212.34 mm - Carbon Steel CCI-20320-C --- Internal Retaining Rings - 203.2x4.75x212.34 mm - Carbon Steel Regular price $161.68 AUD Regular price Sale price $161.68 AUD Unit price per Out of stock! Backorder Now
Housing Bore (B) 205.00 mm _{(8.071 in.)}	Clip Thickness (T) 5.00 mm + 0.72 / - 0.00 _{(0.197 in.)}	Groove Dia. (Dg) 211.00 mm + 0.00 / - 0.12 _{(8.307 in.)}	Approx. Loose Circlip OD (Dr) 217.00 mm + 1.70 / - 0.72		Groove Width (W) 5.15 mm + 0.20 / - 0.00
Material: Carbon Steel Standard: DIN472
Part Number: CCI-20500-C Internal Retaining Rings - 205x5x211 mm - Carbon Steel Out of Stock \| Backorder Now \| Orders can be expected around Sun, Jun 08, 2025 Regular price $54.68 AUD Regular price Sale price $54.68 AUD Unit price per Each
Housing Bore (B) 205.00 mm _{(8.071 in.)}	Clip Thickness (T) 5.00 mm + 0.72 / - 0.00 _{(0.197 in.)}	Groove Dia. (Dg) 211.00 mm + 0.00 / - 0.12 _{(8.307 in.)}	Approx. Loose Circlip OD (Dr) 217.00 mm + 1.70 / - 0.72
Material: Carbon Steel Groove Width (W): 5.15 mm + 0.20 / - 0.00 Standard: DIN472
Part Number: CCI-20500-C Internal Retaining Rings - 205x5x211 mm - Carbon Steel Out of Stock \| Backorder Now \| Orders can be expected around Sun, Jun 08, 2025 Regular price $54.68 AUD Regular price Sale price $54.68 AUD Unit price per Each View the product page first if you are unsure.
CCI-20500-C --- Internal Retaining Rings - 205x5x211 mm - Carbon Steel CCI-20500-C --- Internal Retaining Rings - 205x5x211 mm - Carbon Steel Regular price $54.68 AUD Regular price Sale price $54.68 AUD Unit price per Out of stock! Backorder Now
Housing Bore (B) 207.00 mm _{(8.15 in.)}	Clip Thickness (T) 5.00 mm + 0.72 / - 0.00 _{(0.197 in.)}	Groove Dia. (Dg) 213.00 mm + 0.00 / - 0.12 _{(8.386 in.)}	Approx. Loose Circlip OD (Dr) 217.00 mm + 1.70 / - 0.72		Groove Width (W) 5.15 mm + 0.20 / - 0.00
Material: Carbon Spring Steel phosphate and oil finish Standard: DIN472
Part Number: CCI-20700-C Internal Retaining Rings - 207x5x213 mm - Carbon Spring Steel phosphate and oil finish Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Housing Bore (B) 207.00 mm _{(8.15 in.)}	Clip Thickness (T) 5.00 mm + 0.72 / - 0.00 _{(0.197 in.)}	Groove Dia. (Dg) 213.00 mm + 0.00 / - 0.12 _{(8.386 in.)}	Approx. Loose Circlip OD (Dr) 217.00 mm + 1.70 / - 0.72
Material: Carbon Spring Steel phosphate and oil finish Groove Width (W): 5.15 mm + 0.20 / - 0.00 Standard: DIN472
Part Number: CCI-20700-C Internal Retaining Rings - 207x5x213 mm - Carbon Spring Steel phosphate and oil finish Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Housing Bore (B) 208.00 mm _{(8.189 in.)}	Clip Thickness (T) 5.00 mm + 0.72 / - 0.00 _{(0.197 in.)}	Groove Dia. (Dg) 214.00 mm + 0.00 / - 0.12 _{(8.425 in.)}	Approx. Loose Circlip OD (Dr) 222.00 mm + 1.70 / - 0.72		Groove Width (W) 5.15 mm + 0.20 / - 0.00
Material: Carbon Spring Steel phosphate and oil finish Standard: DIN472
Part Number: CCI-20800-C Internal Retaining Rings - 208x5x214 mm - Carbon Spring Steel phosphate and oil finish Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Housing Bore (B) 208.00 mm _{(8.189 in.)}	Clip Thickness (T) 5.00 mm + 0.72 / - 0.00 _{(0.197 in.)}	Groove Dia. (Dg) 214.00 mm + 0.00 / - 0.12 _{(8.425 in.)}	Approx. Loose Circlip OD (Dr) 222.00 mm + 1.70 / - 0.72
Material: Carbon Spring Steel phosphate and oil finish Groove Width (W): 5.15 mm + 0.20 / - 0.00 Standard: DIN472
Part Number: CCI-20800-C Internal Retaining Rings - 208x5x214 mm - Carbon Spring Steel phosphate and oil finish Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Housing Bore (B) 210.00 mm _{(8.268 in.)}	Clip Thickness (T) 5.00 mm + 0.72 / - 0.00 _{(0.197 in.)}	Groove Dia. (Dg) 216.00 mm + 0.00 / - 0.12 _{(8.504 in.)}	Approx. Loose Circlip OD (Dr) 222.00 mm + 1.70 / - 0.72		Groove Width (W) 5.15 mm + 0.20 / - 0.00
Material: Carbon Steel Clearance in Bore (C): 180.20 mm Clearance in Groove (C1): 187.00 mm Min. Lug Diameter (h): 4.00 mm Min. Extension (n): 9.00 Standard: DIN472
Part Number: CCI-21000-C Internal Retaining Rings - 210x5x216 mm - Carbon Steel 4 Available Immediately \| Further orders can be expected around Sun, Jun 08, 2025 Regular price $55.32 AUD Regular price Sale price $55.32 AUD Unit price per Each
Housing Bore (B) 210.00 mm _{(8.268 in.)}	Clip Thickness (T) 5.00 mm + 0.72 / - 0.00 _{(0.197 in.)}	Groove Dia. (Dg) 216.00 mm + 0.00 / - 0.12 _{(8.504 in.)}	Approx. Loose Circlip OD (Dr) 222.00 mm + 1.70 / - 0.72
Material: Carbon Steel Groove Width (W): 5.15 mm + 0.20 / - 0.00 Clearance in Bore (C): 180.20 mm Clearance in Groove (C1): 187.00 mm Min. Lug Diameter (h): 4.00 mm Min. Extension (n): 9.00 Standard: DIN472
Part Number: CCI-21000-C Internal Retaining Rings - 210x5x216 mm - Carbon Steel 4 Available Immediately \| Further orders can be expected around Sun, Jun 08, 2025 Regular price $55.32 AUD Regular price Sale price $55.32 AUD Unit price per Each View the product page first if you are unsure.
CCI-21000-C --- Internal Retaining Rings - 210x5x216 mm - Carbon Steel CCI-21000-C --- Internal Retaining Rings - 210x5x216 mm - Carbon Steel Regular price $55.32 AUD Regular price Sale price $55.32 AUD Unit price per 4 Available Now
Housing Bore (B) 212.00 mm _{(8.346 in.)}	Clip Thickness (T) 5.00 mm + 0.72 / - 0.00 _{(0.197 in.)}	Groove Dia. (Dg) 218.00 mm + 0.00 / - 0.12 _{(8.583 in.)}	Approx. Loose Circlip OD (Dr) 222.00 mm + 1.70 / - 0.72		Groove Width (W) 5.15 mm + 0.20 / - 0.00
Material: Carbon Spring Steel phosphate and oil finish Standard: DIN472
Part Number: CCI-21200-C Internal Retaining Rings - 212x5x218 mm - Carbon Spring Steel phosphate and oil finish Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Housing Bore (B) 212.00 mm _{(8.346 in.)}	Clip Thickness (T) 5.00 mm + 0.72 / - 0.00 _{(0.197 in.)}	Groove Dia. (Dg) 218.00 mm + 0.00 / - 0.12 _{(8.583 in.)}	Approx. Loose Circlip OD (Dr) 222.00 mm + 1.70 / - 0.72
Material: Carbon Spring Steel phosphate and oil finish Groove Width (W): 5.15 mm + 0.20 / - 0.00 Standard: DIN472
Part Number: CCI-21200-C Internal Retaining Rings - 212x5x218 mm - Carbon Spring Steel phosphate and oil finish Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Housing Bore (B) 215.00 mm _{(8.465 in.)}	Clip Thickness (T) 5.00 mm + 0.72 / - 0.00 _{(0.197 in.)}	Groove Dia. (Dg) 221.00 mm + 0.00 / - 0.12 _{(8.701 in.)}	Approx. Loose Circlip OD (Dr) 227.00 mm + 1.70 / - 0.72		Groove Width (W) 5.15 mm + 0.20 / - 0.00
Material: Carbon Steel Clearance in Bore (C): 185.20 mm Clearance in Groove (C1): 192.00 mm Min. Lug Diameter (h): 4.00 mm Min. Extension (n): 9.00 Standard: DIN472
Part Number: CCI-21500-C Internal Retaining Rings - 215x5x221 mm - Carbon Steel Out of Stock \| Backorder Now \| Orders can be expected around Sun, Jun 08, 2025 Regular price $56.95 AUD Regular price Sale price $56.95 AUD Unit price per Each
Housing Bore (B) 215.00 mm _{(8.465 in.)}	Clip Thickness (T) 5.00 mm + 0.72 / - 0.00 _{(0.197 in.)}	Groove Dia. (Dg) 221.00 mm + 0.00 / - 0.12 _{(8.701 in.)}	Approx. Loose Circlip OD (Dr) 227.00 mm + 1.70 / - 0.72
Material: Carbon Steel Groove Width (W): 5.15 mm + 0.20 / - 0.00 Clearance in Bore (C): 185.20 mm Clearance in Groove (C1): 192.00 mm Min. Lug Diameter (h): 4.00 mm Min. Extension (n): 9.00 Standard: DIN472
Part Number: CCI-21500-C Internal Retaining Rings - 215x5x221 mm - Carbon Steel Out of Stock \| Backorder Now \| Orders can be expected around Sun, Jun 08, 2025 Regular price $56.95 AUD Regular price Sale price $56.95 AUD Unit price per Each View the product page first if you are unsure.
CCI-21500-C --- Internal Retaining Rings - 215x5x221 mm - Carbon Steel CCI-21500-C --- Internal Retaining Rings - 215x5x221 mm - Carbon Steel Regular price $56.95 AUD Regular price Sale price $56.95 AUD Unit price per Out of stock! Backorder Now
Housing Bore (B) 215.90 mm _{(8.5 in.)}	Clip Thickness (T) 4.75 mm +/- 0.204 _{(0.187 in.)}	Groove Dia. (Dg) 225.55 mm + 0.00 / - 0.12 _{(8.88 in.)}	Approx. Loose Circlip OD (Dr) 239.65 mm + 2.29 / - 2.29		Groove Width (W) 5.31 mm + 0.20 / - 0.00
Material: Carbon Steel Standard: MIL-16625
Part Number: CCI-21590-C Internal Retaining Rings - 215.9x4.75x225.55 mm - Carbon Steel Out of Stock \| Backorder Now \| Orders can be expected around Fri, Aug 08, 2025 Regular price $309.77 AUD Regular price Sale price $309.77 AUD Unit price per Each
Housing Bore (B) 215.90 mm _{(8.5 in.)}	Clip Thickness (T) 4.75 mm +/- 0.204 _{(0.187 in.)}	Groove Dia. (Dg) 225.55 mm + 0.00 / - 0.12 _{(8.88 in.)}	Approx. Loose Circlip OD (Dr) 239.65 mm + 2.29 / - 2.29
Material: Carbon Steel Groove Width (W): 5.31 mm + 0.20 / - 0.00 Standard: MIL-16625
Part Number: CCI-21590-C Internal Retaining Rings - 215.9x4.75x225.55 mm - Carbon Steel Out of Stock \| Backorder Now \| Orders can be expected around Fri, Aug 08, 2025 Regular price $309.77 AUD Regular price Sale price $309.77 AUD Unit price per Each View the product page first if you are unsure.
CCI-21590-C --- Internal Retaining Rings - 215.9x4.75x225.55 mm - Carbon Steel CCI-21590-C --- Internal Retaining Rings - 215.9x4.75x225.55 mm - Carbon Steel Regular price $309.77 AUD Regular price Sale price $309.77 AUD Unit price per Out of stock! Backorder Now
Housing Bore (B) 217.00 mm _{(8.543 in.)}	Clip Thickness (T) 5.00 mm + 0.72 / - 0.00 _{(0.197 in.)}	Groove Dia. (Dg) 223.00 mm + 0.00 / - 0.12 _{(8.78 in.)}	Approx. Loose Circlip OD (Dr) 227.00 mm + 1.70 / - 0.72		Groove Width (W) 5.15 mm + 0.20 / - 0.00
Material: Carbon Spring Steel phosphate and oil finish Standard: DIN472
Part Number: CCI-21700-C Internal Retaining Rings - 217x5x223 mm - Carbon Spring Steel phosphate and oil finish Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Housing Bore (B) 217.00 mm _{(8.543 in.)}	Clip Thickness (T) 5.00 mm + 0.72 / - 0.00 _{(0.197 in.)}	Groove Dia. (Dg) 223.00 mm + 0.00 / - 0.12 _{(8.78 in.)}	Approx. Loose Circlip OD (Dr) 227.00 mm + 1.70 / - 0.72
Material: Carbon Spring Steel phosphate and oil finish Groove Width (W): 5.15 mm + 0.20 / - 0.00 Standard: DIN472
Part Number: CCI-21700-C Internal Retaining Rings - 217x5x223 mm - Carbon Spring Steel phosphate and oil finish Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Housing Bore (B) 218.00 mm _{(8.583 in.)}	Clip Thickness (T) 5.00 mm + 0.72 / - 0.00 _{(0.197 in.)}	Groove Dia. (Dg) 224.00 mm + 0.00 / - 0.12 _{(8.819 in.)}	Approx. Loose Circlip OD (Dr) 232.00 mm + 1.70 / - 0.72		Groove Width (W) 5.15 mm + 0.20 / - 0.00
Material: Carbon Spring Steel phosphate and oil finish Standard: DIN472
Part Number: CCI-21800-C Internal Retaining Rings - 218x5x224 mm - Carbon Spring Steel phosphate and oil finish Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Housing Bore (B) 218.00 mm _{(8.583 in.)}	Clip Thickness (T) 5.00 mm + 0.72 / - 0.00 _{(0.197 in.)}	Groove Dia. (Dg) 224.00 mm + 0.00 / - 0.12 _{(8.819 in.)}	Approx. Loose Circlip OD (Dr) 232.00 mm + 1.70 / - 0.72
Material: Carbon Spring Steel phosphate and oil finish Groove Width (W): 5.15 mm + 0.20 / - 0.00 Standard: DIN472
Part Number: CCI-21800-C Internal Retaining Rings - 218x5x224 mm - Carbon Spring Steel phosphate and oil finish Contact Us \| Item Discontinued - Please contact us if you need a large quantity
