Collection: Pins - Dowel - Standard - Rounded Ends - 316 Stainless

Pins (With Images)

Dowel

Standard

Rounded Ends

55 Products in this selection

Also known as parallel pins
Dowel pins are not used as bearing shafts under normal circumstances, due to their oversized tolerances
Precision Dowel Pins - 316 Grade - Based on DIN7
Rounded end dowel pins are measured from the start of the edge rounding. This allows the pin to completely fill the hole after you grind off the rounded end.
Diameter tolerances are m6 unless otherwise listed

Additional resources:
Dowel Pins Catalogue PDF
Master Pins Catalogue PDF

A more concise listing may be found on the Smallparts store at Pins - Dowel - Standard - Rounded Ends - 316 Stainless. Smallparts promote the most popular MBA products.

Diameter (D)	Length (L)	Approx. Overall Length	Type	Indicative Image
Diameter (D) 3.000 mm + 0.004 / + 0.012 _{(0.118 in.)}	Length (L) 18.00 mm +/- 0.420 _{(0.709 in.)}	Approx. Overall Length 18.90 mm +/ - 0.420 _{(0.744 in.)}	Type 3 (Rounded Ends)
Material: Stainless Steel 316 (Similar to A4, 18-10) Standard: Based on DIN 7
Part Number: DP030-018-316-3 (10 Pcs) Dowel Pins - 3x18x18.9 mm - Stainless Steel 316 Similar to A4, 18-10 349 units (3490 pcs) Available Immediately \| Further orders can be expected around Wed, Jul 23, 2025 Regular price $8.32 AUD Regular price Sale price $8.32 AUD Unit price per Per 10
Diameter (D)	Length (L)	Approx. Overall Length	Indicative Image
Diameter (D) 3.000 mm + 0.004 / + 0.012 _{(0.118 in.)}	Length (L) 18.00 mm +/- 0.420 _{(0.709 in.)}	Approx. Overall Length 18.90 mm +/ - 0.420 _{(0.744 in.)}
Material: Stainless Steel 316 (Similar to A4, 18-10) Type: 3 (Rounded Ends) Standard: Based on DIN 7
Part Number: DP030-018-316-3 (10 Pcs) Dowel Pins - 3x18x18.9 mm - Stainless Steel 316 Similar to A4, 18-10 349 units (3490 pcs) Available Immediately \| Further orders can be expected around Wed, Jul 23, 2025 Regular price $8.32 AUD Regular price Sale price $8.32 AUD Unit price per Per 10 View the product page first if you are unsure.
DP030-018-316-3 (10 Pcs) --- Dowel Pins - 3x18x18.9 mm - Stainless Steel 316 Similar to A4, 18-10 DP030-018-316-3 (10 Pcs) --- Dowel Pins - 3x18x18.9 mm - Stainless Steel 316 Similar to A4, 18-10 Regular price $8.32 AUD Regular price Sale price $8.32 AUD Unit price per 349 Available Now
Diameter (D) 3.000 mm + 0.004 / + 0.012 _{(0.118 in.)}	Length (L) 24.00 mm +/- 0.420 _{(0.945 in.)}	Approx. Overall Length 24.90 mm +/ - 0.420 _{(0.98 in.)}	Type 3 (Rounded Ends)
Material: Stainless Steel 316 (Similar to A4, 18-10) Standard: Based on DIN 7
Part Number: DP030-024-316-3 (50 Pcs) Dowel Pins - 3x24x24.9 mm - Stainless Steel 316 Similar to A4, 18-10 168 units (8400 pcs) Available Immediately \| Item Discontinued - Only the quantity available may be ordered - Please contact us if you need a larger quantity Regular price $4.00 AUD Regular price ~~$7.60 AUD~~ Sale price $4.00 AUD Unit price per Per 50
Diameter (D) 3.000 mm + 0.004 / + 0.012 _{(0.118 in.)}	Length (L) 24.00 mm +/- 0.420 _{(0.945 in.)}	Approx. Overall Length 24.90 mm +/ - 0.420 _{(0.98 in.)}
Material: Stainless Steel 316 (Similar to A4, 18-10) Type: 3 (Rounded Ends) Standard: Based on DIN 7
Part Number: DP030-024-316-3 (50 Pcs) Dowel Pins - 3x24x24.9 mm - Stainless Steel 316 Similar to A4, 18-10 168 units (8400 pcs) Available Immediately \| Item Discontinued - Only the quantity available may be ordered - Please contact us if you need a larger quantity Regular price $4.00 AUD Regular price ~~$7.60 AUD~~ Sale price $4.00 AUD Unit price per Per 50
DP030-024-316-3 (50 Pcs) --- Dowel Pins - 3x24x24.9 mm - Stainless Steel 316 Similar to A4, 18-10 Sale DP030-024-316-3 (50 Pcs) --- Dowel Pins - 3x24x24.9 mm - Stainless Steel 316 Similar to A4, 18-10 Regular price $4.00 AUD Regular price ~~$7.60 AUD~~ Sale price $4.00 AUD Unit price per 168 Available Now Sale
Diameter (D) 4.000 mm + 0.004 / + 0.012 _{(0.157 in.)}	Length (L) 10.00 mm +/- 0.350 _{(0.394 in.)}	Approx. Overall Length 11.20 mm +/ - 0.350 _{(0.441 in.)}	Type 3 (Rounded Ends)
Material: Stainless Steel 316 (Similar to A4, 18-10) Standard: Based on DIN 7
Part Number: DP040-010-316-3 (500 Pcs) Dowel Pins - 4x10x11.2 mm - Stainless Steel 316 Similar to A4, 18-10 Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Diameter (D) 4.000 mm + 0.004 / + 0.012 _{(0.157 in.)}	Length (L) 10.00 mm +/- 0.350 _{(0.394 in.)}	Approx. Overall Length 11.20 mm +/ - 0.350 _{(0.441 in.)}
Material: Stainless Steel 316 (Similar to A4, 18-10) Type: 3 (Rounded Ends) Standard: Based on DIN 7
Part Number: DP040-010-316-3 (500 Pcs) Dowel Pins - 4x10x11.2 mm - Stainless Steel 316 Similar to A4, 18-10 Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Diameter (D) 4.000 mm + 0.004 / + 0.012 _{(0.157 in.)}	Length (L) 12.00 mm +/- 0.350 _{(0.472 in.)}	Approx. Overall Length 13.20 mm +/ - 0.350 _{(0.52 in.)}	Type 3 (Rounded Ends)
Material: Stainless Steel 316 (Similar to A4, 18-10) Standard: Based on DIN 7
Part Number: DP040-012-316-3 (500 Pcs) Dowel Pins - 4x12x13.2 mm - Stainless Steel 316 Similar to A4, 18-10 Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Diameter (D) 4.000 mm + 0.004 / + 0.012 _{(0.157 in.)}	Length (L) 12.00 mm +/- 0.350 _{(0.472 in.)}	Approx. Overall Length 13.20 mm +/ - 0.350 _{(0.52 in.)}
Material: Stainless Steel 316 (Similar to A4, 18-10) Type: 3 (Rounded Ends) Standard: Based on DIN 7
Part Number: DP040-012-316-3 (500 Pcs) Dowel Pins - 4x12x13.2 mm - Stainless Steel 316 Similar to A4, 18-10 Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Diameter (D) 4.000 mm + 0.004 / + 0.012 _{(0.157 in.)}	Length (L) 16.00 mm +/- 0.350 _{(0.63 in.)}	Approx. Overall Length 17.20 mm +/ - 0.350 _{(0.677 in.)}	Type 3 (Rounded Ends)
Material: Stainless Steel 316 (Similar to A4, 18-10) Standard: Based on DIN 7
Part Number: DP040-016-316-3 (500 Pcs) Dowel Pins - 4x16x17.2 mm - Stainless Steel 316 Similar to A4, 18-10 Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Diameter (D) 4.000 mm + 0.004 / + 0.012 _{(0.157 in.)}	Length (L) 16.00 mm +/- 0.350 _{(0.63 in.)}	Approx. Overall Length 17.20 mm +/ - 0.350 _{(0.677 in.)}
Material: Stainless Steel 316 (Similar to A4, 18-10) Type: 3 (Rounded Ends) Standard: Based on DIN 7
Part Number: DP040-016-316-3 (500 Pcs) Dowel Pins - 4x16x17.2 mm - Stainless Steel 316 Similar to A4, 18-10 Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Diameter (D) 4.000 mm + 0.004 / + 0.012 _{(0.157 in.)}	Length (L) 20.00 mm +/- 0.420 _{(0.787 in.)}	Approx. Overall Length 21.20 mm +/ - 0.420 _{(0.835 in.)}	Type 3 (Rounded Ends)
Material: Stainless Steel 316 (Similar to A4, 18-10) Standard: Based on DIN 7
Part Number: DP040-020-316-3 (500 Pcs) Dowel Pins - 4x20x21.2 mm - Stainless Steel 316 Similar to A4, 18-10 Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Diameter (D) 4.000 mm + 0.004 / + 0.012 _{(0.157 in.)}	Length (L) 20.00 mm +/- 0.420 _{(0.787 in.)}	Approx. Overall Length 21.20 mm +/ - 0.420 _{(0.835 in.)}
Material: Stainless Steel 316 (Similar to A4, 18-10) Type: 3 (Rounded Ends) Standard: Based on DIN 7
Part Number: DP040-020-316-3 (500 Pcs) Dowel Pins - 4x20x21.2 mm - Stainless Steel 316 Similar to A4, 18-10 Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Diameter (D) 4.000 mm + 0.004 / + 0.012 _{(0.157 in.)}	Length (L) 24.00 mm +/- 0.420 _{(0.945 in.)}	Approx. Overall Length 25.20 mm +/ - 0.420 _{(0.992 in.)}	Type 3 (Rounded Ends)
Material: Stainless Steel 316 (Similar to A4, 18-10) Standard: Based on DIN 7
Part Number: DP040-024-316-3 (20 Pcs) Dowel Pins - 4x24x25.2 mm - Stainless Steel 316 Similar to A4, 18-10 65 units (1300 pcs) Available Immediately \| Item Discontinued - Only the quantity available may be ordered - Please contact us if you need a larger quantity Regular price $5.00 AUD Regular price ~~$9.50 AUD~~ Sale price $5.00 AUD Unit price per Per 20
Diameter (D) 4.000 mm + 0.004 / + 0.012 _{(0.157 in.)}	Length (L) 24.00 mm +/- 0.420 _{(0.945 in.)}	Approx. Overall Length 25.20 mm +/ - 0.420 _{(0.992 in.)}
Material: Stainless Steel 316 (Similar to A4, 18-10) Type: 3 (Rounded Ends) Standard: Based on DIN 7
Part Number: DP040-024-316-3 (20 Pcs) Dowel Pins - 4x24x25.2 mm - Stainless Steel 316 Similar to A4, 18-10 65 units (1300 pcs) Available Immediately \| Item Discontinued - Only the quantity available may be ordered - Please contact us if you need a larger quantity Regular price $5.00 AUD Regular price ~~$9.50 AUD~~ Sale price $5.00 AUD Unit price per Per 20
DP040-024-316-3 (20 Pcs) --- Dowel Pins - 4x24x25.2 mm - Stainless Steel 316 Similar to A4, 18-10 Sale DP040-024-316-3 (20 Pcs) --- Dowel Pins - 4x24x25.2 mm - Stainless Steel 316 Similar to A4, 18-10 Regular price $5.00 AUD Regular price ~~$9.50 AUD~~ Sale price $5.00 AUD Unit price per 65 Available Now Sale
Diameter (D) 4.000 mm + 0.004 / + 0.012 _{(0.157 in.)}	Length (L) 28.00 mm +/- 0.420 _{(1.102 in.)}	Approx. Overall Length 29.20 mm +/ - 0.420 _{(1.15 in.)}	Type 3 (Rounded Ends)
Material: Stainless Steel 316 (Similar to A4, 18-10) Standard: Based on DIN 7
Part Number: DP040-028-316-3 (50 Pcs) Dowel Pins - 4x28x29.2 mm - Stainless Steel 316 Similar to A4, 18-10 6 units (300 pcs) Available Immediately \| Item Discontinued - Only the quantity available may be ordered - Please contact us if you need a larger quantity Regular price $9.00 AUD Regular price ~~$17.10 AUD~~ Sale price $9.00 AUD Unit price per Per 50
Diameter (D) 4.000 mm + 0.004 / + 0.012 _{(0.157 in.)}	Length (L) 28.00 mm +/- 0.420 _{(1.102 in.)}	Approx. Overall Length 29.20 mm +/ - 0.420 _{(1.15 in.)}
Material: Stainless Steel 316 (Similar to A4, 18-10) Type: 3 (Rounded Ends) Standard: Based on DIN 7
Part Number: DP040-028-316-3 (50 Pcs) Dowel Pins - 4x28x29.2 mm - Stainless Steel 316 Similar to A4, 18-10 6 units (300 pcs) Available Immediately \| Item Discontinued - Only the quantity available may be ordered - Please contact us if you need a larger quantity Regular price $9.00 AUD Regular price ~~$17.10 AUD~~ Sale price $9.00 AUD Unit price per Per 50
DP040-028-316-3 (50 Pcs) --- Dowel Pins - 4x28x29.2 mm - Stainless Steel 316 Similar to A4, 18-10 Sale DP040-028-316-3 (50 Pcs) --- Dowel Pins - 4x28x29.2 mm - Stainless Steel 316 Similar to A4, 18-10 Regular price $9.00 AUD Regular price ~~$17.10 AUD~~ Sale price $9.00 AUD Unit price per 6 Available Now Sale
Diameter (D) 4.000 mm + 0.004 / + 0.012 _{(0.157 in.)}	Length (L) 30.00 mm +/- 0.500 _{(1.181 in.)}	Approx. Overall Length 31.20 mm +/ - 0.500 _{(1.228 in.)}	Type 3 (Rounded Ends)
Material: Stainless Steel 316 (Similar to A4, 18-10) Standard: Based on DIN 7
Part Number: DP040-030-316-3 Dowel Pins - 4x30x31.2 mm - Stainless Steel 316 Similar to A4, 18-10 Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Diameter (D) 4.000 mm + 0.004 / + 0.012 _{(0.157 in.)}	Length (L) 30.00 mm +/- 0.500 _{(1.181 in.)}	Approx. Overall Length 31.20 mm +/ - 0.500 _{(1.228 in.)}
Material: Stainless Steel 316 (Similar to A4, 18-10) Type: 3 (Rounded Ends) Standard: Based on DIN 7
Part Number: DP040-030-316-3 Dowel Pins - 4x30x31.2 mm - Stainless Steel 316 Similar to A4, 18-10 Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Diameter (D) 5.000 mm + 0.004 / + 0.012 _{(0.197 in.)}	Length (L) 10.00 mm +/- 0.350 _{(0.394 in.)}	Approx. Overall Length 11.50 mm +/ - 0.350 _{(0.453 in.)}	Type 3 (Rounded Ends)
Material: Stainless Steel 316 (Similar to A4, 18-10) Standard: Based on DIN 7
Part Number: DP050-010-316-3 Dowel Pins - 5x10x11.5 mm - Stainless Steel 316 Similar to A4, 18-10 Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Diameter (D) 5.000 mm + 0.004 / + 0.012 _{(0.197 in.)}	Length (L) 10.00 mm +/- 0.350 _{(0.394 in.)}	Approx. Overall Length 11.50 mm +/ - 0.350 _{(0.453 in.)}
Material: Stainless Steel 316 (Similar to A4, 18-10) Type: 3 (Rounded Ends) Standard: Based on DIN 7
Part Number: DP050-010-316-3 Dowel Pins - 5x10x11.5 mm - Stainless Steel 316 Similar to A4, 18-10 Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Diameter (D) 5.000 mm + 0.004 / + 0.012 _{(0.197 in.)}	Length (L) 12.00 mm +/- 0.350 _{(0.472 in.)}	Approx. Overall Length 13.50 mm +/ - 0.350 _{(0.531 in.)}	Type 3 (Rounded Ends)
Material: Stainless Steel 316 (Similar to A4, 18-10) Standard: Based on DIN 7
Part Number: DP050-012-316-3 Dowel Pins - 5x12x13.5 mm - Stainless Steel 316 Similar to A4, 18-10 Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Diameter (D) 5.000 mm + 0.004 / + 0.012 _{(0.197 in.)}	Length (L) 12.00 mm +/- 0.350 _{(0.472 in.)}	Approx. Overall Length 13.50 mm +/ - 0.350 _{(0.531 in.)}
Material: Stainless Steel 316 (Similar to A4, 18-10) Type: 3 (Rounded Ends) Standard: Based on DIN 7
Part Number: DP050-012-316-3 Dowel Pins - 5x12x13.5 mm - Stainless Steel 316 Similar to A4, 18-10 Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Diameter (D) 5.000 mm + 0.004 / + 0.012 _{(0.197 in.)}	Length (L) 16.00 mm +/- 0.350 _{(0.63 in.)}	Approx. Overall Length 17.50 mm +/ - 0.350 _{(0.689 in.)}	Type 3 (Rounded Ends)
Material: Stainless Steel 316 (Similar to A4, 18-10) Standard: Based on DIN 7
Part Number: DP050-016-316-3 (2500 Pcs) Dowel Pins - 5x16x17.5 mm - Stainless Steel 316 Similar to A4, 18-10 Out of Stock \| Backorder Now \| Orders can be expected around Sun, Jul 13, 2025 Regular price $3,608.68 AUD Regular price Sale price $3,608.68 AUD Unit price per Per 2500
Diameter (D) 5.000 mm + 0.004 / + 0.012 _{(0.197 in.)}	Length (L) 16.00 mm +/- 0.350 _{(0.63 in.)}	Approx. Overall Length 17.50 mm +/ - 0.350 _{(0.689 in.)}
Material: Stainless Steel 316 (Similar to A4, 18-10) Type: 3 (Rounded Ends) Standard: Based on DIN 7
Part Number: DP050-016-316-3 (2500 Pcs) Dowel Pins - 5x16x17.5 mm - Stainless Steel 316 Similar to A4, 18-10 Out of Stock \| Backorder Now \| Orders can be expected around Sun, Jul 13, 2025 Regular price $3,608.68 AUD Regular price Sale price $3,608.68 AUD Unit price per Per 2500 View the product page first if you are unsure.
DP050-016-316-3 (2500 Pcs) --- Dowel Pins - 5x16x17.5 mm - Stainless Steel 316 Similar to A4, 18-10 DP050-016-316-3 (2500 Pcs) --- Dowel Pins - 5x16x17.5 mm - Stainless Steel 316 Similar to A4, 18-10 Regular price $3,608.68 AUD Regular price Sale price $3,608.68 AUD Unit price per Out of stock! Backorder Now
Diameter (D) 5.000 mm + 0.004 / + 0.012 _{(0.197 in.)}	Length (L) 20.00 mm +/- 0.420 _{(0.787 in.)}	Approx. Overall Length 21.50 mm +/ - 0.420 _{(0.846 in.)}	Type 3 (Rounded Ends)
Material: Stainless Steel 316 (Similar to A4, 18-10) Standard: Based on DIN 7
Part Number: DP050-020-316-3 Dowel Pins - 5x20x21.5 mm - Stainless Steel 316 Similar to A4, 18-10 Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Diameter (D) 5.000 mm + 0.004 / + 0.012 _{(0.197 in.)}	Length (L) 20.00 mm +/- 0.420 _{(0.787 in.)}	Approx. Overall Length 21.50 mm +/ - 0.420 _{(0.846 in.)}
Material: Stainless Steel 316 (Similar to A4, 18-10) Type: 3 (Rounded Ends) Standard: Based on DIN 7
Part Number: DP050-020-316-3 Dowel Pins - 5x20x21.5 mm - Stainless Steel 316 Similar to A4, 18-10 Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Diameter (D) 5.000 mm + 0.004 / + 0.012 _{(0.197 in.)}	Length (L) 24.00 mm +/- 0.420 _{(0.945 in.)}	Approx. Overall Length 25.50 mm +/ - 0.420 _{(1.004 in.)}	Type 3 (Rounded Ends)
Material: Stainless Steel 316 (Similar to A4, 18-10) Standard: Based on DIN 7
Part Number: DP050-024-316-3 Dowel Pins - 5x24x25.5 mm - Stainless Steel 316 Similar to A4, 18-10 Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Diameter (D) 5.000 mm + 0.004 / + 0.012 _{(0.197 in.)}	Length (L) 24.00 mm +/- 0.420 _{(0.945 in.)}	Approx. Overall Length 25.50 mm +/ - 0.420 _{(1.004 in.)}
Material: Stainless Steel 316 (Similar to A4, 18-10) Type: 3 (Rounded Ends) Standard: Based on DIN 7
Part Number: DP050-024-316-3 Dowel Pins - 5x24x25.5 mm - Stainless Steel 316 Similar to A4, 18-10 Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Diameter (D) 5.000 mm + 0.004 / + 0.012 _{(0.197 in.)}	Length (L) 30.00 mm +/- 0.500 _{(1.181 in.)}	Approx. Overall Length 31.50 mm +/ - 0.500 _{(1.24 in.)}	Type 3 (Rounded Ends)
Material: Stainless Steel 316 (Similar to A4, 18-10) Standard: Based on DIN 7
Part Number: DP050-030-316-3 Dowel Pins - 5x30x31.5 mm - Stainless Steel 316 Similar to A4, 18-10 Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Diameter (D) 5.000 mm + 0.004 / + 0.012 _{(0.197 in.)}	Length (L) 30.00 mm +/- 0.500 _{(1.181 in.)}	Approx. Overall Length 31.50 mm +/ - 0.500 _{(1.24 in.)}
Material: Stainless Steel 316 (Similar to A4, 18-10) Type: 3 (Rounded Ends) Standard: Based on DIN 7
Part Number: DP050-030-316-3 Dowel Pins - 5x30x31.5 mm - Stainless Steel 316 Similar to A4, 18-10 Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Diameter (D) 5.000 mm + 0.004 / + 0.012 _{(0.197 in.)}	Length (L) 40.00 mm +/- 0.500 _{(1.575 in.)}	Approx. Overall Length 41.50 mm +/ - 0.500 _{(1.634 in.)}	Type 3 (Rounded Ends)
Material: Stainless Steel 316 (Similar to A4, 18-10) Standard: Based on DIN 7
Part Number: DP050-040-316-3 Dowel Pins - 5x40x41.5 mm - Stainless Steel 316 Similar to A4, 18-10 Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Diameter (D) 5.000 mm + 0.004 / + 0.012 _{(0.197 in.)}	Length (L) 40.00 mm +/- 0.500 _{(1.575 in.)}	Approx. Overall Length 41.50 mm +/ - 0.500 _{(1.634 in.)}
Material: Stainless Steel 316 (Similar to A4, 18-10) Type: 3 (Rounded Ends) Standard: Based on DIN 7
Part Number: DP050-040-316-3 Dowel Pins - 5x40x41.5 mm - Stainless Steel 316 Similar to A4, 18-10 Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Diameter (D) 6.000 mm + 0.006 / + 0.015 _{(0.236 in.)}	Length (L) 12.00 mm +/- 0.350 _{(0.472 in.)}	Approx. Overall Length 13.80 mm +/ - 0.350 _{(0.543 in.)}	Type 3 (Rounded Ends)
Material: Stainless Steel 316 (Similar to A4, 18-10) Standard: Based on DIN 7
Part Number: DP060-012-316-3 Dowel Pins - 6x12x13.8 mm - Stainless Steel 316 Similar to A4, 18-10 Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Diameter (D) 6.000 mm + 0.006 / + 0.015 _{(0.236 in.)}	Length (L) 12.00 mm +/- 0.350 _{(0.472 in.)}	Approx. Overall Length 13.80 mm +/ - 0.350 _{(0.543 in.)}
Material: Stainless Steel 316 (Similar to A4, 18-10) Type: 3 (Rounded Ends) Standard: Based on DIN 7
Part Number: DP060-012-316-3 Dowel Pins - 6x12x13.8 mm - Stainless Steel 316 Similar to A4, 18-10 Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Diameter (D) 6.000 mm + 0.006 / + 0.015 _{(0.236 in.)}	Length (L) 20.00 mm +/- 0.420 _{(0.787 in.)}	Approx. Overall Length 21.80 mm +/ - 0.420 _{(0.858 in.)}	Type 3 (Rounded Ends)
Material: Stainless Steel 316 (Similar to A4, 18-10) Standard: Based on DIN 7
Part Number: DP060-020-316-3 Dowel Pins - 6x20x21.8 mm - Stainless Steel 316 Similar to A4, 18-10 Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Diameter (D) 6.000 mm + 0.006 / + 0.015 _{(0.236 in.)}	Length (L) 20.00 mm +/- 0.420 _{(0.787 in.)}	Approx. Overall Length 21.80 mm +/ - 0.420 _{(0.858 in.)}
Material: Stainless Steel 316 (Similar to A4, 18-10) Type: 3 (Rounded Ends) Standard: Based on DIN 7
Part Number: DP060-020-316-3 Dowel Pins - 6x20x21.8 mm - Stainless Steel 316 Similar to A4, 18-10 Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Diameter (D) 6.000 mm + 0.006 / + 0.015 _{(0.236 in.)}	Length (L) 24.00 mm +/- 0.420 _{(0.945 in.)}	Approx. Overall Length 25.80 mm +/ - 0.420 _{(1.016 in.)}	Type 3 (Rounded Ends)
Material: Stainless Steel 316 (Similar to A4, 18-10) Standard: Based on DIN 7
Part Number: DP060-024-316-3 Dowel Pins - 6x24x25.8 mm - Stainless Steel 316 Similar to A4, 18-10 Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Diameter (D) 6.000 mm + 0.006 / + 0.015 _{(0.236 in.)}	Length (L) 24.00 mm +/- 0.420 _{(0.945 in.)}	Approx. Overall Length 25.80 mm +/ - 0.420 _{(1.016 in.)}
Material: Stainless Steel 316 (Similar to A4, 18-10) Type: 3 (Rounded Ends) Standard: Based on DIN 7
Part Number: DP060-024-316-3 Dowel Pins - 6x24x25.8 mm - Stainless Steel 316 Similar to A4, 18-10 Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Diameter (D) 6.000 mm + 0.006 / + 0.015 _{(0.236 in.)}	Length (L) 30.00 mm +/- 0.500 _{(1.181 in.)}	Approx. Overall Length 31.80 mm +/ - 0.500 _{(1.252 in.)}	Type 3 (Rounded Ends)
Material: Stainless Steel 316 (Similar to A4, 18-10) Standard: Based on DIN 7
Part Number: DP060-030-316-3 Dowel Pins - 6x30x31.8 mm - Stainless Steel 316 Similar to A4, 18-10 Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Diameter (D) 6.000 mm + 0.006 / + 0.015 _{(0.236 in.)}	Length (L) 30.00 mm +/- 0.500 _{(1.181 in.)}	Approx. Overall Length 31.80 mm +/ - 0.500 _{(1.252 in.)}
Material: Stainless Steel 316 (Similar to A4, 18-10) Type: 3 (Rounded Ends) Standard: Based on DIN 7
Part Number: DP060-030-316-3 Dowel Pins - 6x30x31.8 mm - Stainless Steel 316 Similar to A4, 18-10 Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Diameter (D) 6.000 mm + 0.006 / + 0.015 _{(0.236 in.)}	Length (L) 40.00 mm +/- 0.500 _{(1.575 in.)}	Approx. Overall Length 41.80 mm +/ - 0.500 _{(1.646 in.)}	Type 3 (Rounded Ends)
Material: Stainless Steel 316 (Similar to A4, 18-10) Standard: Based on DIN 7
Part Number: DP060-040-316-3 Dowel Pins - 6x40x41.8 mm - Stainless Steel 316 Similar to A4, 18-10 Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Diameter (D) 6.000 mm + 0.006 / + 0.015 _{(0.236 in.)}	Length (L) 40.00 mm +/- 0.500 _{(1.575 in.)}	Approx. Overall Length 41.80 mm +/ - 0.500 _{(1.646 in.)}
Material: Stainless Steel 316 (Similar to A4, 18-10) Type: 3 (Rounded Ends) Standard: Based on DIN 7
Part Number: DP060-040-316-3 Dowel Pins - 6x40x41.8 mm - Stainless Steel 316 Similar to A4, 18-10 Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Diameter (D) 6.000 mm + 0.006 / + 0.015 _{(0.236 in.)}	Length (L) 50.00 mm +/- 0.600 _{(1.969 in.)}	Approx. Overall Length 51.80 mm +/ - 0.600 _{(2.039 in.)}	Type 3 (Rounded Ends)
Material: Stainless Steel 316 (Similar to A4, 18-10) Standard: Based on DIN 7
Part Number: DP060-050-316-3 Dowel Pins - 6x50x51.8 mm - Stainless Steel 316 Similar to A4, 18-10 Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Diameter (D) 6.000 mm + 0.006 / + 0.015 _{(0.236 in.)}	Length (L) 50.00 mm +/- 0.600 _{(1.969 in.)}	Approx. Overall Length 51.80 mm +/ - 0.600 _{(2.039 in.)}
Material: Stainless Steel 316 (Similar to A4, 18-10) Type: 3 (Rounded Ends) Standard: Based on DIN 7
Part Number: DP060-050-316-3 Dowel Pins - 6x50x51.8 mm - Stainless Steel 316 Similar to A4, 18-10 Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Diameter (D) 8.000 mm + 0.006 / + 0.015 _{(0.315 in.)}	Length (L) 12.00 mm +/- 0.350 _{(0.472 in.)}	Approx. Overall Length 14.40 mm +/ - 0.350 _{(0.567 in.)}	Type 3 (Rounded Ends)
Material: Stainless Steel 316 (Similar to A4, 18-10) Standard: Based on DIN 7
Part Number: DP080-012-316-3 Dowel Pins - 8x12x14.4 mm - Stainless Steel 316 Similar to A4, 18-10 Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Diameter (D) 8.000 mm + 0.006 / + 0.015 _{(0.315 in.)}	Length (L) 12.00 mm +/- 0.350 _{(0.472 in.)}	Approx. Overall Length 14.40 mm +/ - 0.350 _{(0.567 in.)}
Material: Stainless Steel 316 (Similar to A4, 18-10) Type: 3 (Rounded Ends) Standard: Based on DIN 7
Part Number: DP080-012-316-3 Dowel Pins - 8x12x14.4 mm - Stainless Steel 316 Similar to A4, 18-10 Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Diameter (D) 8.000 mm + 0.006 / + 0.015 _{(0.315 in.)}	Length (L) 16.00 mm +/- 0.350 _{(0.63 in.)}	Approx. Overall Length 18.40 mm +/ - 0.350 _{(0.724 in.)}	Type 3 (Rounded Ends)
Material: Stainless Steel 316 (Similar to A4, 18-10) Standard: Based on DIN 7
Part Number: DP080-016-316-3 Dowel Pins - 8x16x18.4 mm - Stainless Steel 316 Similar to A4, 18-10 Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Diameter (D) 8.000 mm + 0.006 / + 0.015 _{(0.315 in.)}	Length (L) 16.00 mm +/- 0.350 _{(0.63 in.)}	Approx. Overall Length 18.40 mm +/ - 0.350 _{(0.724 in.)}
Material: Stainless Steel 316 (Similar to A4, 18-10) Type: 3 (Rounded Ends) Standard: Based on DIN 7
Part Number: DP080-016-316-3 Dowel Pins - 8x16x18.4 mm - Stainless Steel 316 Similar to A4, 18-10 Contact Us \| Item Discontinued - Please contact us if you need a large quantity
