Collection: Washers - Thrust - DP4 Type

Washers -> Thrust -> DP4 Type

There are 9 products in the sub-categories of Washers - Thrust - DP4 Type. Browse the Washers - Thrust - DP4 Type products table.

Category Details

A selection of DP4 Type Thrust Washers. Low static and dynamic friction coefficient, Suitable for sliding, oscillating, reiprocating and rotating applications.

Thrust washers are designed to manage axial loads (forces parallel to a shaft) in rotating machinery.
They prevent axial movement, reduce friction, and extend equipment lifespan by providing a bearing surface for rotating parts. Wear resistant helping to prevent wear deposits in the lubricating oil after long working periods.
Designed for use in oil pumps and dampers.
High reistance to be cavitation and flow erosion damage of the polymer bearing surface by the lubricant, Excellent wear resistant.
Also suitable for use with non-lubricating fluids and in light duty unlubricated applications, Lead free.
Operating Temperature -200 deg to 280 degCelsius. Maximum load 250N per mm2.

Miniature Bearings Australia - MBA Minibearings

Additional resources:

Screws

A more concise listing may be found in the Washers - Thrust - DP4 Type category on the Small Parts & Bearings online store.

Nominal Inside Diameter (d1)	Nominal Outside Diameter (Do)	Thickness ST	Dowel Hole Dia dD	Dowel Hole PCD Dp	Recess Depth Ha
Nominal Inside Diameter (d1) 10.00 mm (Equiv. 0.394 in.)	Nominal Outside Diameter (Do) 20.00 mm (Equiv. 0.787 in.)	Thickness ST 1.50 mm (Equiv. 0.059 in.)	Dowel Hole Dia dD 1.500 mm	Dowel Hole PCD Dp 15.000 mm	Recess Depth Ha 1.000 mm
Material: DP4 Recess Diameter: 20.000 mm
Part Number: W0100-T-020-015-DP4 Thrust Washers - 10x20x1.5 mm DP4 Type - DP4 Washer Out of Stock \| Backorder Now \| Orders can be expected around Wed, Oct 15, 2025 Regular price $21.50 AUD Regular price ~~$25.80 AUD~~ Sale price $21.50 AUD Unit price per Excludes GST and overseas Taxes & Duties Each Quantity Required Backorder: Out of Stock.
Nominal Inside Diameter (d1)	Nominal Outside Diameter (Do)	Thickness ST	Dowel Hole Dia dD	Indicative Image
Nominal Inside Diameter (d1) 10.00 mm (Equiv. 0.394 in.)	Nominal Outside Diameter (Do) 20.00 mm (Equiv. 0.787 in.)	Thickness ST 1.50 mm (Equiv. 0.059 in.)	Dowel Hole Dia dD 1.500 mm
Material: DP4 Dowel Hole PCD Dp: 15.000 mm Recess Depth Ha: 1.000 mm Recess Diameter: 20.000 mm
Part Number: W0100-T-020-015-DP4 Thrust Washers - 10x20x1.5 mm DP4 Type - DP4 Washer Out of Stock \| Backorder Now \| Orders can be expected around Wed, Oct 15, 2025 Regular price $21.50 AUD Regular price ~~$25.80 AUD~~ Sale price $21.50 AUD Unit price per Excludes GST and overseas Taxes & Duties Each Quantity Required Backorder: Out of Stock.
W0100-T-020-015-DP4 --- Thrust Washers - 10x20x1.5 mm DP4 Type - DP4 Washer Sale W0100-T-020-015-DP4 --- Thrust Washers - 10x20x1.5 mm DP4 Type - DP4 Washer Regular price $21.50 AUD Regular price ~~$25.80 AUD~~ Sale price $21.50 AUD Unit price per Excludes GST and overseas Taxes & Duties Out of stock! Backorder Now Sale
Nominal Inside Diameter (d1) 12.00 mm (Equiv. 0.472 in.)	Nominal Outside Diameter (Do) 24.00 mm (Equiv. 0.945 in.)	Thickness ST 1.50 mm (Equiv. 0.059 in.)	Dowel Hole Dia dD 1.500 mm	Dowel Hole PCD Dp 18.000 mm	Recess Depth Ha 1.000 mm
Material: DP4 Recess Diameter: 24.000 mm
Part Number: W0120-T-024-015-DP4 Thrust Washers - 12x24x1.5 mm DP4 Type - DP4 Washer Out of Stock \| Backorder Now \| Orders can be expected around Wed, Oct 15, 2025 Regular price $31.41 AUD Regular price ~~$37.69 AUD~~ Sale price $31.41 AUD Unit price per Excludes GST and overseas Taxes & Duties Each Quantity Required Backorder: Out of Stock.
Nominal Inside Diameter (d1) 12.00 mm (Equiv. 0.472 in.)	Nominal Outside Diameter (Do) 24.00 mm (Equiv. 0.945 in.)	Thickness ST 1.50 mm (Equiv. 0.059 in.)	Dowel Hole Dia dD 1.500 mm
Material: DP4 Dowel Hole PCD Dp: 18.000 mm Recess Depth Ha: 1.000 mm Recess Diameter: 24.000 mm
Part Number: W0120-T-024-015-DP4 Thrust Washers - 12x24x1.5 mm DP4 Type - DP4 Washer Out of Stock \| Backorder Now \| Orders can be expected around Wed, Oct 15, 2025 Regular price $31.41 AUD Regular price ~~$37.69 AUD~~ Sale price $31.41 AUD Unit price per Excludes GST and overseas Taxes & Duties Each Quantity Required Backorder: Out of Stock.
W0120-T-024-015-DP4 --- Thrust Washers - 12x24x1.5 mm DP4 Type - DP4 Washer Sale W0120-T-024-015-DP4 --- Thrust Washers - 12x24x1.5 mm DP4 Type - DP4 Washer Regular price $31.41 AUD Regular price ~~$37.69 AUD~~ Sale price $31.41 AUD Unit price per Excludes GST and overseas Taxes & Duties Out of stock! Backorder Now Sale
Nominal Inside Diameter (d1) 18.00 mm (Equiv. 0.709 in.)	Nominal Outside Diameter (Do) 32.00 mm (Equiv. 1.26 in.)	Thickness ST 1.50 mm (Equiv. 0.059 in.)	Dowel Hole Dia dD 2.000 mm	Dowel Hole PCD Dp 25.000 mm	Recess Depth Ha 1.000 mm
Material: DP4 Recess Diameter: 32.000 mm
Part Number: W0180-T-032-015-DP4 Thrust Washers - 18x32x1.5 mm DP4 Type - DP4 Washer Out of Stock \| Backorder Now \| Orders can be expected around Wed, Oct 15, 2025 Regular price $30.32 AUD Regular price ~~$36.38 AUD~~ Sale price $30.32 AUD Unit price per Excludes GST and overseas Taxes & Duties Each Quantity Required Backorder: Out of Stock.
Nominal Inside Diameter (d1) 18.00 mm (Equiv. 0.709 in.)	Nominal Outside Diameter (Do) 32.00 mm (Equiv. 1.26 in.)	Thickness ST 1.50 mm (Equiv. 0.059 in.)	Dowel Hole Dia dD 2.000 mm
Material: DP4 Dowel Hole PCD Dp: 25.000 mm Recess Depth Ha: 1.000 mm Recess Diameter: 32.000 mm
Part Number: W0180-T-032-015-DP4 Thrust Washers - 18x32x1.5 mm DP4 Type - DP4 Washer Out of Stock \| Backorder Now \| Orders can be expected around Wed, Oct 15, 2025 Regular price $30.32 AUD Regular price ~~$36.38 AUD~~ Sale price $30.32 AUD Unit price per Excludes GST and overseas Taxes & Duties Each Quantity Required Backorder: Out of Stock.
W0180-T-032-015-DP4 --- Thrust Washers - 18x32x1.5 mm DP4 Type - DP4 Washer Sale W0180-T-032-015-DP4 --- Thrust Washers - 18x32x1.5 mm DP4 Type - DP4 Washer Regular price $30.32 AUD Regular price ~~$36.38 AUD~~ Sale price $30.32 AUD Unit price per Excludes GST and overseas Taxes & Duties Out of stock! Backorder Now Sale
Nominal Inside Diameter (d1) 20.00 mm (Equiv. 0.787 in.)	Nominal Outside Diameter (Do) 36.00 mm (Equiv. 1.417 in.)	Thickness ST 1.50 mm (Equiv. 0.059 in.)	Dowel Hole Dia dD 3.000 mm	Dowel Hole PCD Dp 28.000 mm	Recess Depth Ha 1.000 mm
Material: DP4 Recess Diameter: 36.000 mm
Part Number: W0200-T-036-015-DP4 Thrust Washers - 20x36x1.5 mm DP4 Type - DP4 Washer Out of Stock \| Backorder Now \| Orders can be expected around Wed, Oct 15, 2025 Regular price $35.14 AUD Regular price ~~$42.16 AUD~~ Sale price $35.14 AUD Unit price per Excludes GST and overseas Taxes & Duties Each Quantity Required Backorder: Out of Stock.
Nominal Inside Diameter (d1) 20.00 mm (Equiv. 0.787 in.)	Nominal Outside Diameter (Do) 36.00 mm (Equiv. 1.417 in.)	Thickness ST 1.50 mm (Equiv. 0.059 in.)	Dowel Hole Dia dD 3.000 mm
Material: DP4 Dowel Hole PCD Dp: 28.000 mm Recess Depth Ha: 1.000 mm Recess Diameter: 36.000 mm
Part Number: W0200-T-036-015-DP4 Thrust Washers - 20x36x1.5 mm DP4 Type - DP4 Washer Out of Stock \| Backorder Now \| Orders can be expected around Wed, Oct 15, 2025 Regular price $35.14 AUD Regular price ~~$42.16 AUD~~ Sale price $35.14 AUD Unit price per Excludes GST and overseas Taxes & Duties Each Quantity Required Backorder: Out of Stock.
W0200-T-036-015-DP4 --- Thrust Washers - 20x36x1.5 mm DP4 Type - DP4 Washer Sale W0200-T-036-015-DP4 --- Thrust Washers - 20x36x1.5 mm DP4 Type - DP4 Washer Regular price $35.14 AUD Regular price ~~$42.16 AUD~~ Sale price $35.14 AUD Unit price per Excludes GST and overseas Taxes & Duties Out of stock! Backorder Now Sale
Nominal Inside Diameter (d1) 26.00 mm (Equiv. 1.024 in.)	Nominal Outside Diameter (Do) 44.00 mm (Equiv. 1.732 in.)	Thickness ST 1.50 mm (Equiv. 0.059 in.)	Dowel Hole Dia dD 3.000 mm	Dowel Hole PCD Dp 35.000 mm	Recess Depth Ha 1.000 mm
Material: DP4 Recess Diameter: 44.000 mm
Part Number: W0260-T-044-015-DP4 Thrust Washers - 26x44x1.5 mm DP4 Type - DP4 Washer Out of Stock \| Backorder Now \| Orders can be expected around Wed, Oct 15, 2025 Regular price $43.86 AUD Regular price ~~$52.64 AUD~~ Sale price $43.86 AUD Unit price per Excludes GST and overseas Taxes & Duties Each Quantity Required Backorder: Out of Stock.
Nominal Inside Diameter (d1) 26.00 mm (Equiv. 1.024 in.)	Nominal Outside Diameter (Do) 44.00 mm (Equiv. 1.732 in.)	Thickness ST 1.50 mm (Equiv. 0.059 in.)	Dowel Hole Dia dD 3.000 mm
Material: DP4 Dowel Hole PCD Dp: 35.000 mm Recess Depth Ha: 1.000 mm Recess Diameter: 44.000 mm
Part Number: W0260-T-044-015-DP4 Thrust Washers - 26x44x1.5 mm DP4 Type - DP4 Washer Out of Stock \| Backorder Now \| Orders can be expected around Wed, Oct 15, 2025 Regular price $43.86 AUD Regular price ~~$52.64 AUD~~ Sale price $43.86 AUD Unit price per Excludes GST and overseas Taxes & Duties Each Quantity Required Backorder: Out of Stock.
W0260-T-044-015-DP4 --- Thrust Washers - 26x44x1.5 mm DP4 Type - DP4 Washer Sale W0260-T-044-015-DP4 --- Thrust Washers - 26x44x1.5 mm DP4 Type - DP4 Washer Regular price $43.86 AUD Regular price ~~$52.64 AUD~~ Sale price $43.86 AUD Unit price per Excludes GST and overseas Taxes & Duties Out of stock! Backorder Now Sale
Nominal Inside Diameter (d1) 28.00 mm (Equiv. 1.102 in.)	Nominal Outside Diameter (Do) 48.00 mm (Equiv. 1.89 in.)	Thickness ST 1.50 mm (Equiv. 0.059 in.)	Dowel Hole Dia dD 4.000 mm	Dowel Hole PCD Dp 38.000 mm	Recess Depth Ha 1.000 mm
Material: DP4 Recess Diameter: 48.000 mm
Part Number: W0280-T-048-015-DP4 Thrust Washers - 28x48x1.5 mm DP4 Type - DP4 Washer Out of Stock \| Backorder Now \| Orders can be expected around Wed, Oct 15, 2025 Regular price $48.41 AUD Regular price ~~$58.09 AUD~~ Sale price $48.41 AUD Unit price per Excludes GST and overseas Taxes & Duties Each Quantity Required Backorder: Out of Stock.
Nominal Inside Diameter (d1) 28.00 mm (Equiv. 1.102 in.)	Nominal Outside Diameter (Do) 48.00 mm (Equiv. 1.89 in.)	Thickness ST 1.50 mm (Equiv. 0.059 in.)	Dowel Hole Dia dD 4.000 mm
Material: DP4 Dowel Hole PCD Dp: 38.000 mm Recess Depth Ha: 1.000 mm Recess Diameter: 48.000 mm
Part Number: W0280-T-048-015-DP4 Thrust Washers - 28x48x1.5 mm DP4 Type - DP4 Washer Out of Stock \| Backorder Now \| Orders can be expected around Wed, Oct 15, 2025 Regular price $48.41 AUD Regular price ~~$58.09 AUD~~ Sale price $48.41 AUD Unit price per Excludes GST and overseas Taxes & Duties Each Quantity Required Backorder: Out of Stock.
W0280-T-048-015-DP4 --- Thrust Washers - 28x48x1.5 mm DP4 Type - DP4 Washer Sale W0280-T-048-015-DP4 --- Thrust Washers - 28x48x1.5 mm DP4 Type - DP4 Washer Regular price $48.41 AUD Regular price ~~$58.09 AUD~~ Sale price $48.41 AUD Unit price per Excludes GST and overseas Taxes & Duties Out of stock! Backorder Now Sale
Nominal Inside Diameter (d1) 32.00 mm (Equiv. 1.26 in.)	Nominal Outside Diameter (Do) 54.00 mm (Equiv. 2.126 in.)	Thickness ST 1.50 mm (Equiv. 0.059 in.)	Dowel Hole Dia dD 4.000 mm	Dowel Hole PCD Dp 43.000 mm	Recess Depth Ha 1.000 mm
Material: DP4 Recess Diameter: 54.000 mm
Part Number: W0320-T-054-015-DP4 Thrust Washers - 32x54x1.5 mm DP4 Type - DP4 Washer Out of Stock \| Backorder Now \| Orders can be expected around Wed, Oct 15, 2025 Regular price $58.41 AUD Regular price ~~$70.09 AUD~~ Sale price $58.41 AUD Unit price per Excludes GST and overseas Taxes & Duties Each Quantity Required Backorder: Out of Stock.
Nominal Inside Diameter (d1) 32.00 mm (Equiv. 1.26 in.)	Nominal Outside Diameter (Do) 54.00 mm (Equiv. 2.126 in.)	Thickness ST 1.50 mm (Equiv. 0.059 in.)	Dowel Hole Dia dD 4.000 mm
Material: DP4 Dowel Hole PCD Dp: 43.000 mm Recess Depth Ha: 1.000 mm Recess Diameter: 54.000 mm
Part Number: W0320-T-054-015-DP4 Thrust Washers - 32x54x1.5 mm DP4 Type - DP4 Washer Out of Stock \| Backorder Now \| Orders can be expected around Wed, Oct 15, 2025 Regular price $58.41 AUD Regular price ~~$70.09 AUD~~ Sale price $58.41 AUD Unit price per Excludes GST and overseas Taxes & Duties Each Quantity Required Backorder: Out of Stock.
W0320-T-054-015-DP4 --- Thrust Washers - 32x54x1.5 mm DP4 Type - DP4 Washer Sale W0320-T-054-015-DP4 --- Thrust Washers - 32x54x1.5 mm DP4 Type - DP4 Washer Regular price $58.41 AUD Regular price ~~$70.09 AUD~~ Sale price $58.41 AUD Unit price per Excludes GST and overseas Taxes & Duties Out of stock! Backorder Now Sale
Nominal Inside Diameter (d1) 38.00 mm (Equiv. 1.496 in.)	Nominal Outside Diameter (Do) 62.00 mm (Equiv. 2.441 in.)	Thickness ST 1.50 mm (Equiv. 0.059 in.)	Dowel Hole Dia dD 4.000 mm	Dowel Hole PCD Dp 50.000 mm	Recess Depth Ha 1.000 mm
Material: DP4 Recess Diameter: 62.000 mm
Part Number: W0380-T-062-015-DP4 Thrust Washers - 38x62x1.5 mm DP4 Type - DP4 Washer Out of Stock \| Backorder Now \| Orders can be expected around Wed, Oct 15, 2025 Regular price $55.23 AUD Regular price ~~$66.27 AUD~~ Sale price $55.23 AUD Unit price per Excludes GST and overseas Taxes & Duties Each Quantity Required Backorder: Out of Stock.
Nominal Inside Diameter (d1) 38.00 mm (Equiv. 1.496 in.)	Nominal Outside Diameter (Do) 62.00 mm (Equiv. 2.441 in.)	Thickness ST 1.50 mm (Equiv. 0.059 in.)	Dowel Hole Dia dD 4.000 mm
Material: DP4 Dowel Hole PCD Dp: 50.000 mm Recess Depth Ha: 1.000 mm Recess Diameter: 62.000 mm
Part Number: W0380-T-062-015-DP4 Thrust Washers - 38x62x1.5 mm DP4 Type - DP4 Washer Out of Stock \| Backorder Now \| Orders can be expected around Wed, Oct 15, 2025 Regular price $55.23 AUD Regular price ~~$66.27 AUD~~ Sale price $55.23 AUD Unit price per Excludes GST and overseas Taxes & Duties Each Quantity Required Backorder: Out of Stock.
W0380-T-062-015-DP4 --- Thrust Washers - 38x62x1.5 mm DP4 Type - DP4 Washer Sale W0380-T-062-015-DP4 --- Thrust Washers - 38x62x1.5 mm DP4 Type - DP4 Washer Regular price $55.23 AUD Regular price ~~$66.27 AUD~~ Sale price $55.23 AUD Unit price per Excludes GST and overseas Taxes & Duties Out of stock! Backorder Now Sale
Nominal Inside Diameter (d1) 42.00 mm (Equiv. 1.654 in.)	Nominal Outside Diameter (Do) 66.00 mm (Equiv. 2.598 in.)	Thickness ST 1.50 mm (Equiv. 0.059 in.)	Dowel Hole Dia dD 4.000 mm	Dowel Hole PCD Dp 54.000 mm	Recess Depth Ha 1.000 mm
Material: DP4 Recess Diameter: 66.000 mm
Part Number: W0420-T-066-015-DP4 Thrust Washers - 42x66x1.5 mm DP4 Type - DP4 Washer Out of Stock \| Backorder Now \| Orders can be expected around Wed, Oct 15, 2025 Regular price $75.59 AUD Regular price ~~$90.71 AUD~~ Sale price $75.59 AUD Unit price per Excludes GST and overseas Taxes & Duties Each Quantity Required Backorder: Out of Stock.
Nominal Inside Diameter (d1) 42.00 mm (Equiv. 1.654 in.)	Nominal Outside Diameter (Do) 66.00 mm (Equiv. 2.598 in.)	Thickness ST 1.50 mm (Equiv. 0.059 in.)	Dowel Hole Dia dD 4.000 mm
Material: DP4 Dowel Hole PCD Dp: 54.000 mm Recess Depth Ha: 1.000 mm Recess Diameter: 66.000 mm
Part Number: W0420-T-066-015-DP4 Thrust Washers - 42x66x1.5 mm DP4 Type - DP4 Washer Out of Stock \| Backorder Now \| Orders can be expected around Wed, Oct 15, 2025 Regular price $75.59 AUD Regular price ~~$90.71 AUD~~ Sale price $75.59 AUD Unit price per Excludes GST and overseas Taxes & Duties Each Quantity Required Backorder: Out of Stock.
W0420-T-066-015-DP4 --- Thrust Washers - 42x66x1.5 mm DP4 Type - DP4 Washer Sale W0420-T-066-015-DP4 --- Thrust Washers - 42x66x1.5 mm DP4 Type - DP4 Washer Regular price $75.59 AUD Regular price ~~$90.71 AUD~~ Sale price $75.59 AUD Unit price per Excludes GST and overseas Taxes & Duties Out of stock! Backorder Now Sale
