Retaining Rings - External - Spiral Rings - Light Duty - Carbon Steel

3 Products in this selection
  • Includes series CE / VS / US - Spring Steel
  • Light duty single turn rings used in low clearance applications.
  • Also used as a positioning point for light loads.
  • Radius notch on one end for removal.
  • Narrow radial wall yields moderate thrust loads.
  • Equivalent to Associated Spring: CE, Smalley: VS, Spirolox and Ramsey: US
Additional resources:
Spiral Rings and Snap Rings PDF
A more concise listing may be found on the Smallparts store at Retaining Rings - External - Spiral Rings - Light Duty - Carbon Steel. Smallparts promote the most popular MBA products.
Shaft Diameter (Ds) Clip Thickness (T) Groove Dia. (Dg) Approx. Loose Circlip ID (A) Radial Wall (S) Groove Width (W) Indicative
Shaft Diameter (Ds)
9.525
mm

(0.375 in.)
Clip Thickness (T)
0.38
mm
+/- 0.05
(0.015 in.)
Groove Dia. (Dg)
8.92
mm

(0.351 in.)
Approx. Loose Circlip ID (A)
8.83
mm
+ 0.00 / - 0.25
Radial Wall (S)
0.635
mm
+/- 0.10
Groove Width (W)
0.46
mm
+/- 0.05
External Retaining Rings - 9.525x0.38x8.92 mm - Spring Steel
Material: Spring Steel    Approx. Loose Clip OD: 10.10 +/- - 0.03   Groove Depth (d): 0.30
Part Number: US-037 (25 Pcs) External Retaining Rings - 9.525x0.38x8.92 mm - Spring Steel
Out of Stock | Backorder Now | Orders can be expected around Wed, Jun 18, 2025
$56.86 AUD
$56.86 AUD
Per 25
Shaft Diameter (Ds) Clip Thickness (T) Groove Dia. (Dg) Approx. Loose Circlip ID (A) Indicative
Shaft Diameter (Ds)
9.525
mm

(0.375 in.)
Clip Thickness (T)
0.38
mm
+/- 0.05
(0.015 in.)
Groove Dia. (Dg)
8.92
mm

(0.351 in.)
Approx. Loose Circlip ID (A)
8.83
mm
+ 0.00 / - 0.25
External Retaining Rings - 9.525x0.38x8.92 mm - Spring Steel
Material: Spring Steel    Radial Wall (S): 0.635 mm +/- 0.10    Groove Width (W): 0.46 mm +/- 0.05   Approx. Loose Clip OD: 10.10 +/- - 0.03   Groove Depth (d): 0.30
Part Number: US-037 (25 Pcs) External Retaining Rings - 9.525x0.38x8.92 mm - Spring Steel
Out of Stock | Backorder Now | Orders can be expected around Wed, Jun 18, 2025
$56.86 AUD
$56.86 AUD
Per 25
