Collection: Pins - Dowel - Standard - Rounded Ends

Pins (With Images)

Dowel

Standard

Chamfered Ends
Rounded Ends

163 Products in this selection

This is a combined category of Rounded Ends Standard Dowel Pins.

Also known as parallel pins
Dowel pins are not used as bearing shafts under normal circumstances, due to their oversized tolerances

Use the filters in the table below, or the category tree above to refine the selection. To order any item, simply click the part number for a full product page, then add to your cart.

Additional resources:
Dowel Pins Catalogue PDF
Master Pins Catalogue PDF

A more concise listing may be found on the Smallparts store at Pins - Dowel - Standard - Rounded Ends. Smallparts promote the most popular MBA products.

Diameter (D)	Length (L)	Approx. Overall Length	Type
Diameter (D) 6.000 mm + 0.006 / + 0.015 _{(0.236 in.)}	Length (L) 50.00 mm +/- 0.600 _{(1.969 in.)}	Approx. Overall Length 51.80 mm +/ - 0.600 _{(2.039 in.)}	Type 3 (Rounded Ends)
Material: Stainless Steel 316 (Similar to A4, 18-10) Category: Pins - Dowel - Standard - Rounded Ends - 316 Stainless
Part Number: DP060-050-316-3 Dowel Pins - 6x50x51.8 mm - Stainless Steel 316 Similar to A4, 18-10 Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Diameter (D)	Length (L)	Approx. Overall Length	Indicative Image
Diameter (D) 6.000 mm + 0.006 / + 0.015 _{(0.236 in.)}	Length (L) 50.00 mm +/- 0.600 _{(1.969 in.)}	Approx. Overall Length 51.80 mm +/ - 0.600 _{(2.039 in.)}
Material: Stainless Steel 316 (Similar to A4, 18-10) Type: 3 (Rounded Ends) Category: Pins - Dowel - Standard - Rounded Ends - 316 Stainless
Part Number: DP060-050-316-3 Dowel Pins - 6x50x51.8 mm - Stainless Steel 316 Similar to A4, 18-10 Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Diameter (D) 6.000 mm + 0.006 / + 0.015 _{(0.236 in.)}	Length (L) 60.00 mm +/- 0.600 _{(2.362 in.)}	Approx. Overall Length 61.80 mm +/ - 0.600 _{(2.433 in.)}	Type 3 (Rounded Ends)
Material: Stainless Steel 304 (Similar to A2, 18-8) HRB80 Category: Pins - Dowel - Standard - Rounded Ends - 303-304 Stainless
Part Number: DP060-060-304-3 Dowel Pins - 6x60x61.8 mm - Stainless Steel 304 Similar to A2, 18-8 HRB80 Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Diameter (D) 6.000 mm + 0.006 / + 0.015 _{(0.236 in.)}	Length (L) 60.00 mm +/- 0.600 _{(2.362 in.)}	Approx. Overall Length 61.80 mm +/ - 0.600 _{(2.433 in.)}
Material: Stainless Steel 304 (Similar to A2, 18-8) HRB80 Type: 3 (Rounded Ends) Category: Pins - Dowel - Standard - Rounded Ends - 303-304 Stainless
Part Number: DP060-060-304-3 Dowel Pins - 6x60x61.8 mm - Stainless Steel 304 Similar to A2, 18-8 HRB80 Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Diameter (D) 8.000 mm + 0.006 / + 0.015 _{(0.315 in.)}	Length (L) 12.00 mm +/- 0.350 _{(0.472 in.)}	Approx. Overall Length 14.40 mm +/ - 0.350 _{(0.567 in.)}	Type 3 (Rounded Ends)
Material: Stainless Steel 316 (Similar to A4, 18-10) Category: Pins - Dowel - Standard - Rounded Ends - 316 Stainless
Part Number: DP080-012-316-3 Dowel Pins - 8x12x14.4 mm - Stainless Steel 316 Similar to A4, 18-10 Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Diameter (D) 8.000 mm + 0.006 / + 0.015 _{(0.315 in.)}	Length (L) 12.00 mm +/- 0.350 _{(0.472 in.)}	Approx. Overall Length 14.40 mm +/ - 0.350 _{(0.567 in.)}
Material: Stainless Steel 316 (Similar to A4, 18-10) Type: 3 (Rounded Ends) Category: Pins - Dowel - Standard - Rounded Ends - 316 Stainless
Part Number: DP080-012-316-3 Dowel Pins - 8x12x14.4 mm - Stainless Steel 316 Similar to A4, 18-10 Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Diameter (D) 8.000 mm + 0.006 / + 0.015 _{(0.315 in.)}	Length (L) 16.00 mm +/- 0.350 _{(0.63 in.)}	Approx. Overall Length 18.40 mm +/ - 0.350 _{(0.724 in.)}	Type 3 (Rounded Ends)
Material: Stainless Steel 303/304 (Similar to A2, 18-8) HRB80 Category: Pins - Dowel - Standard - Rounded Ends - 303-304 Stainless
Part Number: DP080-016-303-3 (5 Pcs) Dowel Pins - 8x16x18.4 mm - Stainless Steel 303/304 Similar to A2, 18-8 HRB80 501 units (2505 pcs) Available Immediately \| Further orders can be expected around Sun, Jul 13, 2025 Regular price $14.59 AUD Regular price Sale price $14.59 AUD Unit price per Per 5
Diameter (D) 8.000 mm + 0.006 / + 0.015 _{(0.315 in.)}	Length (L) 16.00 mm +/- 0.350 _{(0.63 in.)}	Approx. Overall Length 18.40 mm +/ - 0.350 _{(0.724 in.)}
Material: Stainless Steel 303/304 (Similar to A2, 18-8) HRB80 Type: 3 (Rounded Ends) Category: Pins - Dowel - Standard - Rounded Ends - 303-304 Stainless
Part Number: DP080-016-303-3 (5 Pcs) Dowel Pins - 8x16x18.4 mm - Stainless Steel 303/304 Similar to A2, 18-8 HRB80 501 units (2505 pcs) Available Immediately \| Further orders can be expected around Sun, Jul 13, 2025 Regular price $14.59 AUD Regular price Sale price $14.59 AUD Unit price per Per 5 View the product page first if you are unsure.
DP080-016-303-3 (5 Pcs) --- Dowel Pins - 8x16x18.4 mm - Stainless Steel 303/304 Similar to A2, 18-8 HRB80 DP080-016-303-3 (5 Pcs) --- Dowel Pins - 8x16x18.4 mm - Stainless Steel 303/304 Similar to A2, 18-8 HRB80 Regular price $14.59 AUD Regular price Sale price $14.59 AUD Unit price per 501 Available Now
Diameter (D) 8.000 mm + 0.006 / + 0.015 _{(0.315 in.)}	Length (L) 16.00 mm +/- 0.350 _{(0.63 in.)}	Approx. Overall Length 18.40 mm +/ - 0.350 _{(0.724 in.)}	Type 3 (Rounded Ends)
Material: Stainless Steel 316 (Similar to A4, 18-10) Category: Pins - Dowel - Standard - Rounded Ends - 316 Stainless
Part Number: DP080-016-316-3 Dowel Pins - 8x16x18.4 mm - Stainless Steel 316 Similar to A4, 18-10 Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Diameter (D) 8.000 mm + 0.006 / + 0.015 _{(0.315 in.)}	Length (L) 16.00 mm +/- 0.350 _{(0.63 in.)}	Approx. Overall Length 18.40 mm +/ - 0.350 _{(0.724 in.)}
Material: Stainless Steel 316 (Similar to A4, 18-10) Type: 3 (Rounded Ends) Category: Pins - Dowel - Standard - Rounded Ends - 316 Stainless
Part Number: DP080-016-316-3 Dowel Pins - 8x16x18.4 mm - Stainless Steel 316 Similar to A4, 18-10 Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Diameter (D) 8.000 mm + 0.006 / + 0.015 _{(0.315 in.)}	Length (L) 20.00 mm +/- 0.420 _{(0.787 in.)}	Approx. Overall Length 22.40 mm +/ - 0.420 _{(0.882 in.)}	Type 3 (Rounded Ends)
Material: Stainless Steel 316 (Similar to A4, 18-10) Category: Pins - Dowel - Standard - Rounded Ends - 316 Stainless
Part Number: DP080-020-316-3 (5 Pcs) Dowel Pins - 8x20x22.4 mm - Stainless Steel 316 Similar to A4, 18-10 150 units (750 pcs) Available Immediately \| Further orders can be expected around Wed, Jul 23, 2025 Regular price $21.50 AUD Regular price Sale price $21.50 AUD Unit price per Per 5
Diameter (D) 8.000 mm + 0.006 / + 0.015 _{(0.315 in.)}	Length (L) 20.00 mm +/- 0.420 _{(0.787 in.)}	Approx. Overall Length 22.40 mm +/ - 0.420 _{(0.882 in.)}
Material: Stainless Steel 316 (Similar to A4, 18-10) Type: 3 (Rounded Ends) Category: Pins - Dowel - Standard - Rounded Ends - 316 Stainless
Part Number: DP080-020-316-3 (5 Pcs) Dowel Pins - 8x20x22.4 mm - Stainless Steel 316 Similar to A4, 18-10 150 units (750 pcs) Available Immediately \| Further orders can be expected around Wed, Jul 23, 2025 Regular price $21.50 AUD Regular price Sale price $21.50 AUD Unit price per Per 5 View the product page first if you are unsure.
DP080-020-316-3 (5 Pcs) --- Dowel Pins - 8x20x22.4 mm - Stainless Steel 316 Similar to A4, 18-10 DP080-020-316-3 (5 Pcs) --- Dowel Pins - 8x20x22.4 mm - Stainless Steel 316 Similar to A4, 18-10 Regular price $21.50 AUD Regular price Sale price $21.50 AUD Unit price per 150 Available Now
Diameter (D) 8.000 mm + 0.006 / + 0.015 _{(0.315 in.)}	Length (L) 20.00 mm +/- 0.420 _{(0.787 in.)}	Approx. Overall Length 24.00 mm +/ - 0.420 _{(0.945 in.)}	Type 3 (Rounded Ends)
Material: Stainless Steel 316 (Similar to A4, 18-10) Category: Pins - Dowel - Standard - Rounded Ends - 316 Stainless
Part Number: DP080-020-316-3-L24 (5 Pcs) Dowel Pins - 8x20x24 mm - Stainless Steel 316 Similar to A4, 18-10 46 units (230 pcs) Available Immediately \| Further orders can be expected around Sun, Jul 13, 2025 Regular price $8.05 AUD Regular price Sale price $8.05 AUD Unit price per Per 5
Diameter (D) 8.000 mm + 0.006 / + 0.015 _{(0.315 in.)}	Length (L) 20.00 mm +/- 0.420 _{(0.787 in.)}	Approx. Overall Length 24.00 mm +/ - 0.420 _{(0.945 in.)}
Material: Stainless Steel 316 (Similar to A4, 18-10) Type: 3 (Rounded Ends) Category: Pins - Dowel - Standard - Rounded Ends - 316 Stainless
Part Number: DP080-020-316-3-L24 (5 Pcs) Dowel Pins - 8x20x24 mm - Stainless Steel 316 Similar to A4, 18-10 46 units (230 pcs) Available Immediately \| Further orders can be expected around Sun, Jul 13, 2025 Regular price $8.05 AUD Regular price Sale price $8.05 AUD Unit price per Per 5 View the product page first if you are unsure.
DP080-020-316-3-L24 (5 Pcs) --- Dowel Pins - 8x20x24 mm - Stainless Steel 316 Similar to A4, 18-10 DP080-020-316-3-L24 (5 Pcs) --- Dowel Pins - 8x20x24 mm - Stainless Steel 316 Similar to A4, 18-10 Regular price $8.05 AUD Regular price Sale price $8.05 AUD Unit price per 46 Available Now
Diameter (D) 8.000 mm + 0.006 / + 0.015 _{(0.315 in.)}	Length (L) 24.00 mm +/- 0.420 _{(0.945 in.)}	Approx. Overall Length 26.40 mm +/ - 0.420 _{(1.039 in.)}	Type 3 (Rounded Ends)
Material: Stainless Steel 316 (Similar to A4, 18-10) Category: Pins - Dowel - Standard - Rounded Ends - 316 Stainless
Part Number: DP080-024-316-3 Dowel Pins - 8x24x26.4 mm - Stainless Steel 316 Similar to A4, 18-10 Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Diameter (D) 8.000 mm + 0.006 / + 0.015 _{(0.315 in.)}	Length (L) 24.00 mm +/- 0.420 _{(0.945 in.)}	Approx. Overall Length 26.40 mm +/ - 0.420 _{(1.039 in.)}
Material: Stainless Steel 316 (Similar to A4, 18-10) Type: 3 (Rounded Ends) Category: Pins - Dowel - Standard - Rounded Ends - 316 Stainless
Part Number: DP080-024-316-3 Dowel Pins - 8x24x26.4 mm - Stainless Steel 316 Similar to A4, 18-10 Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Diameter (D) 8.000 mm + 0.006 / + 0.015 _{(0.315 in.)}	Length (L) 30.00 mm +/- 0.500 _{(1.181 in.)}	Approx. Overall Length 32.40 mm +/ - 0.500 _{(1.276 in.)}	Type 2 (Chamfer Both Ends)
Material: Stainless Steel 303/304 (Similar to A2, 18-8) HRB80 Category: Pins - Dowel - Standard - Rounded Ends - 303-304 Stainless
Part Number: DP080-030-303-3 Dowel Pins - 8x30x32.4 mm - Stainless Steel 303/304 Similar to A2, 18-8 HRB80 Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Diameter (D) 8.000 mm + 0.006 / + 0.015 _{(0.315 in.)}	Length (L) 30.00 mm +/- 0.500 _{(1.181 in.)}	Approx. Overall Length 32.40 mm +/ - 0.500 _{(1.276 in.)}
Material: Stainless Steel 303/304 (Similar to A2, 18-8) HRB80 Type: 2 (Chamfer Both Ends) Category: Pins - Dowel - Standard - Rounded Ends - 303-304 Stainless
Part Number: DP080-030-303-3 Dowel Pins - 8x30x32.4 mm - Stainless Steel 303/304 Similar to A2, 18-8 HRB80 Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Diameter (D) 8.000 mm + 0.006 / + 0.015 _{(0.315 in.)}	Length (L) 30.00 mm +/- 0.500 _{(1.181 in.)}	Approx. Overall Length 32.40 mm +/ - 0.500 _{(1.276 in.)}	Type 3 (Rounded Ends)
Material: Stainless Steel 316 (Similar to A4, 18-10) Category: Pins - Dowel - Standard - Rounded Ends - 316 Stainless
Part Number: DP080-030-316-3 Dowel Pins - 8x30x32.4 mm - Stainless Steel 316 Similar to A4, 18-10 Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Diameter (D) 8.000 mm + 0.006 / + 0.015 _{(0.315 in.)}	Length (L) 30.00 mm +/- 0.500 _{(1.181 in.)}	Approx. Overall Length 32.40 mm +/ - 0.500 _{(1.276 in.)}
Material: Stainless Steel 316 (Similar to A4, 18-10) Type: 3 (Rounded Ends) Category: Pins - Dowel - Standard - Rounded Ends - 316 Stainless
Part Number: DP080-030-316-3 Dowel Pins - 8x30x32.4 mm - Stainless Steel 316 Similar to A4, 18-10 Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Diameter (D) 8.000 mm + 0.006 / + 0.015 _{(0.315 in.)}	Length (L) 40.00 mm +/- 0.500 _{(1.575 in.)}	Approx. Overall Length 42.40 mm +/ - 0.500 _{(1.669 in.)}	Type 3 (Rounded Ends)
Material: Stainless Steel 316 (Similar to A4, 18-10) Category: Pins - Dowel - Standard - Rounded Ends - 316 Stainless
Part Number: DP080-040-316-3 (500 Pcs) Dowel Pins - 8x40x42.4 mm - Stainless Steel 316 Similar to A4, 18-10 Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Diameter (D) 8.000 mm + 0.006 / + 0.015 _{(0.315 in.)}	Length (L) 40.00 mm +/- 0.500 _{(1.575 in.)}	Approx. Overall Length 42.40 mm +/ - 0.500 _{(1.669 in.)}
Material: Stainless Steel 316 (Similar to A4, 18-10) Type: 3 (Rounded Ends) Category: Pins - Dowel - Standard - Rounded Ends - 316 Stainless
Part Number: DP080-040-316-3 (500 Pcs) Dowel Pins - 8x40x42.4 mm - Stainless Steel 316 Similar to A4, 18-10 Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Diameter (D) 8.000 mm + 0.006 / + 0.015 _{(0.315 in.)}	Length (L) 50.00 mm +/- 0.600 _{(1.969 in.)}	Approx. Overall Length 52.40 mm +/ - 0.600 _{(2.063 in.)}	Type 3 (Rounded Ends)
Material: Stainless Steel 316 (Similar to A4, 18-10) Category: Pins - Dowel - Standard - Rounded Ends - 316 Stainless
Part Number: DP080-050-316-3 Dowel Pins - 8x50x52.4 mm - Stainless Steel 316 Similar to A4, 18-10 Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Diameter (D) 8.000 mm + 0.006 / + 0.015 _{(0.315 in.)}	Length (L) 50.00 mm +/- 0.600 _{(1.969 in.)}	Approx. Overall Length 52.40 mm +/ - 0.600 _{(2.063 in.)}
Material: Stainless Steel 316 (Similar to A4, 18-10) Type: 3 (Rounded Ends) Category: Pins - Dowel - Standard - Rounded Ends - 316 Stainless
Part Number: DP080-050-316-3 Dowel Pins - 8x50x52.4 mm - Stainless Steel 316 Similar to A4, 18-10 Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Diameter (D) 8.000 mm + 0.006 / + 0.015 _{(0.315 in.)}	Length (L) 80.00 mm +/- 0.700 _{(3.15 in.)}	Approx. Overall Length 82.40 mm +/ - 0.700 _{(3.244 in.)}	Type 3 (Rounded Ends)
Material: Stainless Steel 303/304 (Similar to A2, 18-8) HRB80 Category: Pins - Dowel - Standard - Rounded Ends - 303-304 Stainless
Part Number: DP080-080-303-3 Dowel Pins - 8x80x82.4 mm - Stainless Steel 303/304 Similar to A2, 18-8 HRB80 Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Diameter (D) 8.000 mm + 0.006 / + 0.015 _{(0.315 in.)}	Length (L) 80.00 mm +/- 0.700 _{(3.15 in.)}	Approx. Overall Length 82.40 mm +/ - 0.700 _{(3.244 in.)}
Material: Stainless Steel 303/304 (Similar to A2, 18-8) HRB80 Type: 3 (Rounded Ends) Category: Pins - Dowel - Standard - Rounded Ends - 303-304 Stainless
Part Number: DP080-080-303-3 Dowel Pins - 8x80x82.4 mm - Stainless Steel 303/304 Similar to A2, 18-8 HRB80 Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Diameter (D) 10.000 mm + 0.007 / + 0.018 _{(0.394 in.)}	Length (L) 16.00 mm +/- 0.350 _{(0.63 in.)}	Approx. Overall Length 19.00 mm +/ - 0.350 _{(0.748 in.)}	Type 2 (Chamfer Both Ends)
Material: Stainless Steel 303/304 (Similar to A2, 18-8) HRB80 Category: Pins - Dowel - Standard - Rounded Ends - 303-304 Stainless
Part Number: DP100-016-303-3 Dowel Pins - 10x16x19 mm - Stainless Steel 303/304 Similar to A2, 18-8 HRB80 Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Diameter (D) 10.000 mm + 0.007 / + 0.018 _{(0.394 in.)}	Length (L) 16.00 mm +/- 0.350 _{(0.63 in.)}	Approx. Overall Length 19.00 mm +/ - 0.350 _{(0.748 in.)}
Material: Stainless Steel 303/304 (Similar to A2, 18-8) HRB80 Type: 2 (Chamfer Both Ends) Category: Pins - Dowel - Standard - Rounded Ends - 303-304 Stainless
Part Number: DP100-016-303-3 Dowel Pins - 10x16x19 mm - Stainless Steel 303/304 Similar to A2, 18-8 HRB80 Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Diameter (D) 10.000 mm + 0.007 / + 0.018 _{(0.394 in.)}	Length (L) 20.00 mm +/- 0.420 _{(0.787 in.)}	Approx. Overall Length 23.00 mm +/ - 0.420 _{(0.906 in.)}	Type 2 (Chamfer Both Ends)
Material: Stainless Steel 303/304 (Similar to A2, 18-8) HRB80 Category: Pins - Dowel - Standard - Rounded Ends - 303-304 Stainless
Part Number: DP100-020-303-3 Dowel Pins - 10x20x23 mm - Stainless Steel 303/304 Similar to A2, 18-8 HRB80 Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Diameter (D) 10.000 mm + 0.007 / + 0.018 _{(0.394 in.)}	Length (L) 20.00 mm +/- 0.420 _{(0.787 in.)}	Approx. Overall Length 23.00 mm +/ - 0.420 _{(0.906 in.)}
Material: Stainless Steel 303/304 (Similar to A2, 18-8) HRB80 Type: 2 (Chamfer Both Ends) Category: Pins - Dowel - Standard - Rounded Ends - 303-304 Stainless
Part Number: DP100-020-303-3 Dowel Pins - 10x20x23 mm - Stainless Steel 303/304 Similar to A2, 18-8 HRB80 Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Diameter (D) 10.000 mm + 0.007 / + 0.018 _{(0.394 in.)}	Length (L) 24.00 mm +/- 0.420 _{(0.945 in.)}	Approx. Overall Length 27.00 mm +/ - 0.420 _{(1.063 in.)}	Type 3 (Rounded Ends)
Material: Carbon Steel Unhardened Category: Pins - Dowel - Standard - Rounded Ends - Unhardened Steel
Part Number: DP100-024-C-3 (7 Pcs) Dowel Pins - 10x24x27 mm - Carbon Steel Unhardened Out of Stock \| Backorder Now \| Orders can be expected around Sun, Jun 08, 2025 Regular price $20.77 AUD Regular price Sale price $20.77 AUD Unit price per Per 7
Diameter (D) 10.000 mm + 0.007 / + 0.018 _{(0.394 in.)}	Length (L) 24.00 mm +/- 0.420 _{(0.945 in.)}	Approx. Overall Length 27.00 mm +/ - 0.420 _{(1.063 in.)}
Material: Carbon Steel Unhardened Type: 3 (Rounded Ends) Category: Pins - Dowel - Standard - Rounded Ends - Unhardened Steel
Part Number: DP100-024-C-3 (7 Pcs) Dowel Pins - 10x24x27 mm - Carbon Steel Unhardened Out of Stock \| Backorder Now \| Orders can be expected around Sun, Jun 08, 2025 Regular price $20.77 AUD Regular price Sale price $20.77 AUD Unit price per Per 7 View the product page first if you are unsure.
DP100-024-C-3 (7 Pcs) --- Dowel Pins - 10x24x27 mm - Carbon Steel Unhardened DP100-024-C-3 (7 Pcs) --- Dowel Pins - 10x24x27 mm - Carbon Steel Unhardened Regular price $20.77 AUD Regular price Sale price $20.77 AUD Unit price per Out of stock! Backorder Now
Diameter (D) 10.000 mm + 0.007 / + 0.018 _{(0.394 in.)}	Length (L) 30.00 mm +/- 0.500 _{(1.181 in.)}	Approx. Overall Length 33.00 mm +/ - 0.500 _{(1.299 in.)}	Type 2 (Chamfer Both Ends)
Material: Stainless Steel 303/304 (Similar to A2, 18-8) HRB80 Category: Pins - Dowel - Standard - Rounded Ends - 303-304 Stainless
Part Number: DP100-030-303-3 Dowel Pins - 10x30x33 mm - Stainless Steel 303/304 Similar to A2, 18-8 HRB80 Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Diameter (D) 10.000 mm + 0.007 / + 0.018 _{(0.394 in.)}	Length (L) 30.00 mm +/- 0.500 _{(1.181 in.)}	Approx. Overall Length 33.00 mm +/ - 0.500 _{(1.299 in.)}
Material: Stainless Steel 303/304 (Similar to A2, 18-8) HRB80 Type: 2 (Chamfer Both Ends) Category: Pins - Dowel - Standard - Rounded Ends - 303-304 Stainless
Part Number: DP100-030-303-3 Dowel Pins - 10x30x33 mm - Stainless Steel 303/304 Similar to A2, 18-8 HRB80 Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Diameter (D) 12.000 mm + 0.007 / + 0.018 _{(0.472 in.)}	Length (L) 12.00 mm +/- 0.350 _{(0.472 in.)}	Approx. Overall Length 15.60 mm +/ - 0.350 _{(0.614 in.)}	Type 3 (Rounded Ends)
Material: Stainless Steel 316 (Similar to A4, 18-10) Category: Pins - Dowel - Standard - Rounded Ends - 316 Stainless
Part Number: DP120-012-316-3 (1000 Pcs) Dowel Pins - 12x12x15.6 mm - Stainless Steel 316 Similar to A4, 18-10 Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Diameter (D) 12.000 mm + 0.007 / + 0.018 _{(0.472 in.)}	Length (L) 12.00 mm +/- 0.350 _{(0.472 in.)}	Approx. Overall Length 15.60 mm +/ - 0.350 _{(0.614 in.)}
Material: Stainless Steel 316 (Similar to A4, 18-10) Type: 3 (Rounded Ends) Category: Pins - Dowel - Standard - Rounded Ends - 316 Stainless
Part Number: DP120-012-316-3 (1000 Pcs) Dowel Pins - 12x12x15.6 mm - Stainless Steel 316 Similar to A4, 18-10 Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Diameter (D) 16.000 mm + 0.007 / + 0.018 _{(0.63 in.)}	Length (L) 50.00 mm +/- 0.600 _{(1.969 in.)}	Approx. Overall Length 55.00 mm +/ - 0.600 _{(2.165 in.)}	Type 3 (Rounded Ends)
Material: Carbon Steel Unhardened Category: Pins - Dowel - Standard - Rounded Ends - Unhardened Steel
Part Number: DP160-050-C-3 (2 Pcs) Dowel Pins - 16x50x55 mm - Carbon Steel Unhardened Out of Stock \| Backorder Now \| Orders can be expected around Sun, Jun 08, 2025 Regular price $11.68 AUD Regular price Sale price $11.68 AUD Unit price per Per 2
Diameter (D) 16.000 mm + 0.007 / + 0.018 _{(0.63 in.)}	Length (L) 50.00 mm +/- 0.600 _{(1.969 in.)}	Approx. Overall Length 55.00 mm +/ - 0.600 _{(2.165 in.)}
Material: Carbon Steel Unhardened Type: 3 (Rounded Ends) Category: Pins - Dowel - Standard - Rounded Ends - Unhardened Steel
Part Number: DP160-050-C-3 (2 Pcs) Dowel Pins - 16x50x55 mm - Carbon Steel Unhardened Out of Stock \| Backorder Now \| Orders can be expected around Sun, Jun 08, 2025 Regular price $11.68 AUD Regular price Sale price $11.68 AUD Unit price per Per 2 View the product page first if you are unsure.
DP160-050-C-3 (2 Pcs) --- Dowel Pins - 16x50x55 mm - Carbon Steel Unhardened DP160-050-C-3 (2 Pcs) --- Dowel Pins - 16x50x55 mm - Carbon Steel Unhardened Regular price $11.68 AUD Regular price Sale price $11.68 AUD Unit price per Out of stock! Backorder Now
