Collection: Pins - Dowel - Standard - Chamfered Ends - Plastic

Pins -> Dowel -> Standard -> Chamfered Ends -> Plastic

There are 16 products in the sub-categories of Pins - Dowel - Standard - Chamfered Ends - Plastic. Browse the Pins - Dowel - Standard - Chamfered Ends - Plastic products table.

Category Details

A selection of Plastic Chamfered Ends Standard Dowel Pins. Plastic Dowel Pins - Based on DIN6325 or ISO2338

Also known as parallel pins
Dowel pins are not used as bearing shafts under normal circumstances, due to their oversized tolerances
An expanded range may be available on special order. Please enquire.
Note! Type 2 pins may be supplied in lieu of type 1 pins.

Miniature Bearings Australia - MBA Minibearings

Additional resources:

A more concise listing may be found in the Pins - Dowel - Standard - Chamfered Ends - Plastic category on the Small Parts & Bearings online store.

Diameter (D)	Length (L)	Approx. Overall Length	Type
Diameter (D) 3.000 mm _{+ 0.03 / - 0.00} (Equiv. 0.118 in.)	Length (L) 10.00 mm (Equiv. 0.394 in.)	Approx. Overall Length 10.00 mm (Equiv. 0.394 in.)	Type 1 (Chamfer One End)
Material: Polycarbonate Static Yeild Load: 0.40 kN Standard: DIN 6325
Part Number: DP030-010-PC-1 Dowel Pins - 3x10 Standard - Polycarbonate Pin Out of Stock \| Backorder Now \| Orders can be expected around Sun, Oct 05, 2025 Regular price $36.86 AUD Regular price Sale price $36.86 AUD Unit price per Each Quantity Required Backorder: Out of Stock.
Diameter (D)	Length (L)	Approx. Overall Length	Indicative Image
Diameter (D) 3.000 mm _{+ 0.03 / - 0.00} (Equiv. 0.118 in.)	Length (L) 10.00 mm (Equiv. 0.394 in.)	Approx. Overall Length 10.00 mm (Equiv. 0.394 in.)
Material: Polycarbonate Type: 1 (Chamfer One End) Static Yeild Load: 0.40 kN Standard: DIN 6325
Part Number: DP030-010-PC-1 Dowel Pins - 3x10 Standard - Polycarbonate Pin Out of Stock \| Backorder Now \| Orders can be expected around Sun, Oct 05, 2025 Regular price $36.86 AUD Regular price Sale price $36.86 AUD Unit price per Each Quantity Required Backorder: Out of Stock.
DP030-010-PC-1 --- Dowel Pins - 3x10 Standard - Polycarbonate Pin DP030-010-PC-1 --- Dowel Pins - 3x10 Standard - Polycarbonate Pin Regular price $36.86 AUD Regular price Sale price $36.86 AUD Unit price per Out of stock! Backorder Now
Diameter (D) 3.000 mm _{+ 0.03 / - 0.00} (Equiv. 0.118 in.)	Length (L) 15.00 mm (Equiv. 0.591 in.)	Approx. Overall Length 15.00 mm (Equiv. 0.591 in.)	Type 1 (Chamfer One End)
Material: Polycarbonate Static Yeild Load: 0.40 kN Standard: DIN 6325
Part Number: DP030-015-PC-1 Dowel Pins - 3x15 Standard - Polycarbonate Pin Out of Stock \| Backorder Now \| Orders can be expected around Sun, Oct 05, 2025 Regular price $25.41 AUD Regular price ~~$30.49 AUD~~ Sale price $25.41 AUD Unit price per Each Quantity Required Backorder: Out of Stock.
Diameter (D) 3.000 mm _{+ 0.03 / - 0.00} (Equiv. 0.118 in.)	Length (L) 15.00 mm (Equiv. 0.591 in.)	Approx. Overall Length 15.00 mm (Equiv. 0.591 in.)
Material: Polycarbonate Type: 1 (Chamfer One End) Static Yeild Load: 0.40 kN Standard: DIN 6325
Part Number: DP030-015-PC-1 Dowel Pins - 3x15 Standard - Polycarbonate Pin Out of Stock \| Backorder Now \| Orders can be expected around Sun, Oct 05, 2025 Regular price $25.41 AUD Regular price ~~$30.49 AUD~~ Sale price $25.41 AUD Unit price per Each Quantity Required Backorder: Out of Stock.
DP030-015-PC-1 --- Dowel Pins - 3x15 Standard - Polycarbonate Pin Sale DP030-015-PC-1 --- Dowel Pins - 3x15 Standard - Polycarbonate Pin Regular price $25.41 AUD Regular price ~~$30.49 AUD~~ Sale price $25.41 AUD Unit price per Out of stock! Backorder Now Sale
Diameter (D) 3.000 mm _{+ 0.03 / - 0.00} (Equiv. 0.118 in.)	Length (L) 20.00 mm (Equiv. 0.787 in.)	Approx. Overall Length 20.00 mm (Equiv. 0.787 in.)	Type 1 (Chamfer One End)
Material: Polycarbonate Static Yeild Load: 0.40 kN Standard: DIN 6325
Part Number: DP030-020-PC-1 Dowel Pins - 3x20 Standard - Polycarbonate Pin Out of Stock \| Backorder Now \| Orders can be expected around Sun, Oct 05, 2025 Regular price $26.68 AUD Regular price ~~$32.02 AUD~~ Sale price $26.68 AUD Unit price per Each Quantity Required Backorder: Out of Stock.
Diameter (D) 3.000 mm _{+ 0.03 / - 0.00} (Equiv. 0.118 in.)	Length (L) 20.00 mm (Equiv. 0.787 in.)	Approx. Overall Length 20.00 mm (Equiv. 0.787 in.)
Material: Polycarbonate Type: 1 (Chamfer One End) Static Yeild Load: 0.40 kN Standard: DIN 6325
Part Number: DP030-020-PC-1 Dowel Pins - 3x20 Standard - Polycarbonate Pin Out of Stock \| Backorder Now \| Orders can be expected around Sun, Oct 05, 2025 Regular price $26.68 AUD Regular price ~~$32.02 AUD~~ Sale price $26.68 AUD Unit price per Each Quantity Required Backorder: Out of Stock.
DP030-020-PC-1 --- Dowel Pins - 3x20 Standard - Polycarbonate Pin Sale DP030-020-PC-1 --- Dowel Pins - 3x20 Standard - Polycarbonate Pin Regular price $26.68 AUD Regular price ~~$32.02 AUD~~ Sale price $26.68 AUD Unit price per Out of stock! Backorder Now Sale
Diameter (D) 4.000 mm _{+ 0.03 / - 0.00} (Equiv. 0.157 in.)	Length (L) 10.00 mm (Equiv. 0.394 in.)	Approx. Overall Length 10.00 mm (Equiv. 0.394 in.)	Type 1 (Chamfer One End)
Material: Polycarbonate Static Yeild Load: 0.60 kN Standard: DIN 6325
Part Number: DP040-010-PC-1 Dowel Pins - 4x10 Standard - Polycarbonate Pin Out of Stock \| Backorder Now \| Orders can be expected around Sun, Oct 05, 2025 Regular price $25.77 AUD Regular price ~~$30.93 AUD~~ Sale price $25.77 AUD Unit price per Each Quantity Required Backorder: Out of Stock.
Diameter (D) 4.000 mm _{+ 0.03 / - 0.00} (Equiv. 0.157 in.)	Length (L) 10.00 mm (Equiv. 0.394 in.)	Approx. Overall Length 10.00 mm (Equiv. 0.394 in.)
Material: Polycarbonate Type: 1 (Chamfer One End) Static Yeild Load: 0.60 kN Standard: DIN 6325
Part Number: DP040-010-PC-1 Dowel Pins - 4x10 Standard - Polycarbonate Pin Out of Stock \| Backorder Now \| Orders can be expected around Sun, Oct 05, 2025 Regular price $25.77 AUD Regular price ~~$30.93 AUD~~ Sale price $25.77 AUD Unit price per Each Quantity Required Backorder: Out of Stock.
DP040-010-PC-1 --- Dowel Pins - 4x10 Standard - Polycarbonate Pin Sale DP040-010-PC-1 --- Dowel Pins - 4x10 Standard - Polycarbonate Pin Regular price $25.77 AUD Regular price ~~$30.93 AUD~~ Sale price $25.77 AUD Unit price per Out of stock! Backorder Now Sale
Diameter (D) 4.000 mm _{+ 0.03 / - 0.00} (Equiv. 0.157 in.)	Length (L) 15.00 mm (Equiv. 0.591 in.)	Approx. Overall Length 15.00 mm (Equiv. 0.591 in.)	Type 1 (Chamfer One End)
Material: Polycarbonate Static Yeild Load: 0.60 kN Standard: DIN 6325
Part Number: DP040-015-PC-1 Dowel Pins - 4x15 Standard - Polycarbonate Pin Out of Stock \| Backorder Now \| Orders can be expected around Sun, Oct 05, 2025 Regular price $26.68 AUD Regular price ~~$32.02 AUD~~ Sale price $26.68 AUD Unit price per Each Quantity Required Backorder: Out of Stock.
Diameter (D) 4.000 mm _{+ 0.03 / - 0.00} (Equiv. 0.157 in.)	Length (L) 15.00 mm (Equiv. 0.591 in.)	Approx. Overall Length 15.00 mm (Equiv. 0.591 in.)
Material: Polycarbonate Type: 1 (Chamfer One End) Static Yeild Load: 0.60 kN Standard: DIN 6325
Part Number: DP040-015-PC-1 Dowel Pins - 4x15 Standard - Polycarbonate Pin Out of Stock \| Backorder Now \| Orders can be expected around Sun, Oct 05, 2025 Regular price $26.68 AUD Regular price ~~$32.02 AUD~~ Sale price $26.68 AUD Unit price per Each Quantity Required Backorder: Out of Stock.
DP040-015-PC-1 --- Dowel Pins - 4x15 Standard - Polycarbonate Pin Sale DP040-015-PC-1 --- Dowel Pins - 4x15 Standard - Polycarbonate Pin Regular price $26.68 AUD Regular price ~~$32.02 AUD~~ Sale price $26.68 AUD Unit price per Out of stock! Backorder Now Sale
Diameter (D) 4.000 mm _{+ 0.03 / - 0.00} (Equiv. 0.157 in.)	Length (L) 20.00 mm (Equiv. 0.787 in.)	Approx. Overall Length 20.00 mm (Equiv. 0.787 in.)	Type 1 (Chamfer One End)
Material: Polycarbonate Static Yeild Load: 0.60 kN Standard: DIN 6325
Part Number: DP040-020-PC-1 Dowel Pins - 4x20 Standard - Polycarbonate Pin Out of Stock \| Backorder Now \| Orders can be expected around Sun, Oct 05, 2025 Regular price $27.50 AUD Regular price ~~$33.00 AUD~~ Sale price $27.50 AUD Unit price per Each Quantity Required Backorder: Out of Stock.
Diameter (D) 4.000 mm _{+ 0.03 / - 0.00} (Equiv. 0.157 in.)	Length (L) 20.00 mm (Equiv. 0.787 in.)	Approx. Overall Length 20.00 mm (Equiv. 0.787 in.)
Material: Polycarbonate Type: 1 (Chamfer One End) Static Yeild Load: 0.60 kN Standard: DIN 6325
Part Number: DP040-020-PC-1 Dowel Pins - 4x20 Standard - Polycarbonate Pin Out of Stock \| Backorder Now \| Orders can be expected around Sun, Oct 05, 2025 Regular price $27.50 AUD Regular price ~~$33.00 AUD~~ Sale price $27.50 AUD Unit price per Each Quantity Required Backorder: Out of Stock.
DP040-020-PC-1 --- Dowel Pins - 4x20 Standard - Polycarbonate Pin Sale DP040-020-PC-1 --- Dowel Pins - 4x20 Standard - Polycarbonate Pin Regular price $27.50 AUD Regular price ~~$33.00 AUD~~ Sale price $27.50 AUD Unit price per Out of stock! Backorder Now Sale
Diameter (D) 5.000 mm _{+ 0.03 / - 0.00} (Equiv. 0.197 in.)	Length (L) 10.00 mm (Equiv. 0.394 in.)	Approx. Overall Length 10.00 mm (Equiv. 0.394 in.)	Type 1 (Chamfer One End)
Material: Polycarbonate Static Yeild Load: 1.10 kN Standard: DIN 6325
Part Number: DP050-010-PC-1 Dowel Pins - 5x10 Standard - Polycarbonate Pin Out of Stock \| Backorder Now \| Orders can be expected around Sun, Oct 05, 2025 Regular price $27.05 AUD Regular price ~~$32.45 AUD~~ Sale price $27.05 AUD Unit price per Each Quantity Required Backorder: Out of Stock.
Diameter (D) 5.000 mm _{+ 0.03 / - 0.00} (Equiv. 0.197 in.)	Length (L) 10.00 mm (Equiv. 0.394 in.)	Approx. Overall Length 10.00 mm (Equiv. 0.394 in.)
Material: Polycarbonate Type: 1 (Chamfer One End) Static Yeild Load: 1.10 kN Standard: DIN 6325
Part Number: DP050-010-PC-1 Dowel Pins - 5x10 Standard - Polycarbonate Pin Out of Stock \| Backorder Now \| Orders can be expected around Sun, Oct 05, 2025 Regular price $27.05 AUD Regular price ~~$32.45 AUD~~ Sale price $27.05 AUD Unit price per Each Quantity Required Backorder: Out of Stock.
DP050-010-PC-1 --- Dowel Pins - 5x10 Standard - Polycarbonate Pin Sale DP050-010-PC-1 --- Dowel Pins - 5x10 Standard - Polycarbonate Pin Regular price $27.05 AUD Regular price ~~$32.45 AUD~~ Sale price $27.05 AUD Unit price per Out of stock! Backorder Now Sale
Diameter (D) 5.000 mm _{+ 0.03 / - 0.00} (Equiv. 0.197 in.)	Length (L) 15.00 mm (Equiv. 0.591 in.)	Approx. Overall Length 15.00 mm (Equiv. 0.591 in.)	Type 1 (Chamfer One End)
Material: Polycarbonate Static Yeild Load: 1.10 kN Standard: DIN 6325
Part Number: DP050-015-PC-1 Dowel Pins - 5x15 Standard - Polycarbonate Pin Out of Stock \| Backorder Now \| Orders can be expected around Sun, Oct 05, 2025 Regular price $27.86 AUD Regular price ~~$33.44 AUD~~ Sale price $27.86 AUD Unit price per Each Quantity Required Backorder: Out of Stock.
Diameter (D) 5.000 mm _{+ 0.03 / - 0.00} (Equiv. 0.197 in.)	Length (L) 15.00 mm (Equiv. 0.591 in.)	Approx. Overall Length 15.00 mm (Equiv. 0.591 in.)
Material: Polycarbonate Type: 1 (Chamfer One End) Static Yeild Load: 1.10 kN Standard: DIN 6325
Part Number: DP050-015-PC-1 Dowel Pins - 5x15 Standard - Polycarbonate Pin Out of Stock \| Backorder Now \| Orders can be expected around Sun, Oct 05, 2025 Regular price $27.86 AUD Regular price ~~$33.44 AUD~~ Sale price $27.86 AUD Unit price per Each Quantity Required Backorder: Out of Stock.
DP050-015-PC-1 --- Dowel Pins - 5x15 Standard - Polycarbonate Pin Sale DP050-015-PC-1 --- Dowel Pins - 5x15 Standard - Polycarbonate Pin Regular price $27.86 AUD Regular price ~~$33.44 AUD~~ Sale price $27.86 AUD Unit price per Out of stock! Backorder Now Sale
Diameter (D) 5.000 mm _{+ 0.03 / - 0.00} (Equiv. 0.197 in.)	Length (L) 20.00 mm (Equiv. 0.787 in.)	Approx. Overall Length 20.00 mm (Equiv. 0.787 in.)	Type 1 (Chamfer One End)
Material: Polycarbonate Static Yeild Load: 1.10 kN Standard: DIN 6325
Part Number: DP050-020-PC-1 Dowel Pins - 5x20 Standard - Polycarbonate Pin Out of Stock \| Backorder Now \| Orders can be expected around Sun, Oct 05, 2025 Regular price $28.68 AUD Regular price ~~$34.42 AUD~~ Sale price $28.68 AUD Unit price per Each Quantity Required Backorder: Out of Stock.
Diameter (D) 5.000 mm _{+ 0.03 / - 0.00} (Equiv. 0.197 in.)	Length (L) 20.00 mm (Equiv. 0.787 in.)	Approx. Overall Length 20.00 mm (Equiv. 0.787 in.)
Material: Polycarbonate Type: 1 (Chamfer One End) Static Yeild Load: 1.10 kN Standard: DIN 6325
Part Number: DP050-020-PC-1 Dowel Pins - 5x20 Standard - Polycarbonate Pin Out of Stock \| Backorder Now \| Orders can be expected around Sun, Oct 05, 2025 Regular price $28.68 AUD Regular price ~~$34.42 AUD~~ Sale price $28.68 AUD Unit price per Each Quantity Required Backorder: Out of Stock.
DP050-020-PC-1 --- Dowel Pins - 5x20 Standard - Polycarbonate Pin Sale DP050-020-PC-1 --- Dowel Pins - 5x20 Standard - Polycarbonate Pin Regular price $28.68 AUD Regular price ~~$34.42 AUD~~ Sale price $28.68 AUD Unit price per Out of stock! Backorder Now Sale
Diameter (D) 6.000 mm _{+ 0.03 / - 0.00} (Equiv. 0.236 in.)	Length (L) 10.00 mm (Equiv. 0.394 in.)	Approx. Overall Length 10.00 mm (Equiv. 0.394 in.)	Type 1 (Chamfer One End)
Material: Polycarbonate Static Yeild Load: 1.40 kN Standard: DIN 6325
Part Number: DP060-010-PC-1 Dowel Pins - 6x10 Standard - Polycarbonate Pin Out of Stock \| Backorder Now \| Orders can be expected around Sun, Oct 05, 2025 Regular price $27.86 AUD Regular price ~~$33.44 AUD~~ Sale price $27.86 AUD Unit price per Each Quantity Required Backorder: Out of Stock.
Diameter (D) 6.000 mm _{+ 0.03 / - 0.00} (Equiv. 0.236 in.)	Length (L) 10.00 mm (Equiv. 0.394 in.)	Approx. Overall Length 10.00 mm (Equiv. 0.394 in.)
Material: Polycarbonate Type: 1 (Chamfer One End) Static Yeild Load: 1.40 kN Standard: DIN 6325
Part Number: DP060-010-PC-1 Dowel Pins - 6x10 Standard - Polycarbonate Pin Out of Stock \| Backorder Now \| Orders can be expected around Sun, Oct 05, 2025 Regular price $27.86 AUD Regular price ~~$33.44 AUD~~ Sale price $27.86 AUD Unit price per Each Quantity Required Backorder: Out of Stock.
DP060-010-PC-1 --- Dowel Pins - 6x10 Standard - Polycarbonate Pin Sale DP060-010-PC-1 --- Dowel Pins - 6x10 Standard - Polycarbonate Pin Regular price $27.86 AUD Regular price ~~$33.44 AUD~~ Sale price $27.86 AUD Unit price per Out of stock! Backorder Now Sale
Diameter (D) 6.000 mm _{+ 0.03 / - 0.00} (Equiv. 0.236 in.)	Length (L) 15.00 mm (Equiv. 0.591 in.)	Approx. Overall Length 15.00 mm (Equiv. 0.591 in.)	Type 1 (Chamfer One End)
Material: Polycarbonate Static Yeild Load: 1.40 kN Standard: DIN 6325
Part Number: DP060-015-PC-1 Dowel Pins - 6x15 Standard - Polycarbonate Pin Out of Stock \| Backorder Now \| Orders can be expected around Sun, Oct 05, 2025 Regular price $28.68 AUD Regular price ~~$34.42 AUD~~ Sale price $28.68 AUD Unit price per Each Quantity Required Backorder: Out of Stock.
Diameter (D) 6.000 mm _{+ 0.03 / - 0.00} (Equiv. 0.236 in.)	Length (L) 15.00 mm (Equiv. 0.591 in.)	Approx. Overall Length 15.00 mm (Equiv. 0.591 in.)
Material: Polycarbonate Type: 1 (Chamfer One End) Static Yeild Load: 1.40 kN Standard: DIN 6325
Part Number: DP060-015-PC-1 Dowel Pins - 6x15 Standard - Polycarbonate Pin Out of Stock \| Backorder Now \| Orders can be expected around Sun, Oct 05, 2025 Regular price $28.68 AUD Regular price ~~$34.42 AUD~~ Sale price $28.68 AUD Unit price per Each Quantity Required Backorder: Out of Stock.
DP060-015-PC-1 --- Dowel Pins - 6x15 Standard - Polycarbonate Pin Sale DP060-015-PC-1 --- Dowel Pins - 6x15 Standard - Polycarbonate Pin Regular price $28.68 AUD Regular price ~~$34.42 AUD~~ Sale price $28.68 AUD Unit price per Out of stock! Backorder Now Sale
Diameter (D) 6.000 mm _{+ 0.03 / - 0.00} (Equiv. 0.236 in.)	Length (L) 20.00 mm (Equiv. 0.787 in.)	Approx. Overall Length 20.00 mm (Equiv. 0.787 in.)	Type 1 (Chamfer One End)
Material: Polycarbonate Static Yeild Load: 1.40 kN Standard: DIN 6325
Part Number: DP060-020-PC-1 Dowel Pins - 6x20 Standard - Polycarbonate Pin Out of Stock \| Backorder Now \| Orders can be expected around Sun, Oct 05, 2025 Regular price $29.59 AUD Regular price ~~$35.51 AUD~~ Sale price $29.59 AUD Unit price per Each Quantity Required Backorder: Out of Stock.
Diameter (D) 6.000 mm _{+ 0.03 / - 0.00} (Equiv. 0.236 in.)	Length (L) 20.00 mm (Equiv. 0.787 in.)	Approx. Overall Length 20.00 mm (Equiv. 0.787 in.)
Material: Polycarbonate Type: 1 (Chamfer One End) Static Yeild Load: 1.40 kN Standard: DIN 6325
Part Number: DP060-020-PC-1 Dowel Pins - 6x20 Standard - Polycarbonate Pin Out of Stock \| Backorder Now \| Orders can be expected around Sun, Oct 05, 2025 Regular price $29.59 AUD Regular price ~~$35.51 AUD~~ Sale price $29.59 AUD Unit price per Each Quantity Required Backorder: Out of Stock.
DP060-020-PC-1 --- Dowel Pins - 6x20 Standard - Polycarbonate Pin Sale DP060-020-PC-1 --- Dowel Pins - 6x20 Standard - Polycarbonate Pin Regular price $29.59 AUD Regular price ~~$35.51 AUD~~ Sale price $29.59 AUD Unit price per Out of stock! Backorder Now Sale
Diameter (D) 6.000 mm _{+ 0.03 / - 0.00} (Equiv. 0.236 in.)	Length (L) 25.00 mm (Equiv. 0.984 in.)	Approx. Overall Length 25.00 mm (Equiv. 0.984 in.)	Type 1 (Chamfer One End)
Material: Polycarbonate Static Yeild Load: 1.40 kN Standard: DIN 6325
Part Number: DP060-025-PC-1 Dowel Pins - 6x25 Standard - Polycarbonate Pin Out of Stock \| Backorder Now \| Orders can be expected around Sun, Oct 05, 2025 Regular price $31.23 AUD Regular price ~~$37.47 AUD~~ Sale price $31.23 AUD Unit price per Each Quantity Required Backorder: Out of Stock.
Diameter (D) 6.000 mm _{+ 0.03 / - 0.00} (Equiv. 0.236 in.)	Length (L) 25.00 mm (Equiv. 0.984 in.)	Approx. Overall Length 25.00 mm (Equiv. 0.984 in.)
Material: Polycarbonate Type: 1 (Chamfer One End) Static Yeild Load: 1.40 kN Standard: DIN 6325
Part Number: DP060-025-PC-1 Dowel Pins - 6x25 Standard - Polycarbonate Pin Out of Stock \| Backorder Now \| Orders can be expected around Sun, Oct 05, 2025 Regular price $31.23 AUD Regular price ~~$37.47 AUD~~ Sale price $31.23 AUD Unit price per Each Quantity Required Backorder: Out of Stock.
DP060-025-PC-1 --- Dowel Pins - 6x25 Standard - Polycarbonate Pin Sale DP060-025-PC-1 --- Dowel Pins - 6x25 Standard - Polycarbonate Pin Regular price $31.23 AUD Regular price ~~$37.47 AUD~~ Sale price $31.23 AUD Unit price per Out of stock! Backorder Now Sale
Diameter (D) 8.000 mm _{+ 0.03 / - 0.00} (Equiv. 0.315 in.)	Length (L) 15.00 mm (Equiv. 0.591 in.)	Approx. Overall Length 15.00 mm (Equiv. 0.591 in.)	Type 1 (Chamfer One End)
Material: Polycarbonate Static Yeild Load: 2.10 kN Standard: DIN 6325
Part Number: DP080-015-PC-1 Dowel Pins - 8x15 Standard - Polycarbonate Pin Out of Stock \| Backorder Now \| Orders can be expected around Sun, Oct 05, 2025 Regular price $29.59 AUD Regular price ~~$35.51 AUD~~ Sale price $29.59 AUD Unit price per Each Quantity Required Backorder: Out of Stock.
Diameter (D) 8.000 mm _{+ 0.03 / - 0.00} (Equiv. 0.315 in.)	Length (L) 15.00 mm (Equiv. 0.591 in.)	Approx. Overall Length 15.00 mm (Equiv. 0.591 in.)
Material: Polycarbonate Type: 1 (Chamfer One End) Static Yeild Load: 2.10 kN Standard: DIN 6325
Part Number: DP080-015-PC-1 Dowel Pins - 8x15 Standard - Polycarbonate Pin Out of Stock \| Backorder Now \| Orders can be expected around Sun, Oct 05, 2025 Regular price $29.59 AUD Regular price ~~$35.51 AUD~~ Sale price $29.59 AUD Unit price per Each Quantity Required Backorder: Out of Stock.
DP080-015-PC-1 --- Dowel Pins - 8x15 Standard - Polycarbonate Pin Sale DP080-015-PC-1 --- Dowel Pins - 8x15 Standard - Polycarbonate Pin Regular price $29.59 AUD Regular price ~~$35.51 AUD~~ Sale price $29.59 AUD Unit price per Out of stock! Backorder Now Sale
Diameter (D) 8.000 mm _{+ 0.03 / - 0.00} (Equiv. 0.315 in.)	Length (L) 20.00 mm (Equiv. 0.787 in.)	Approx. Overall Length 20.00 mm (Equiv. 0.787 in.)	Type 1 (Chamfer One End)
Material: Polycarbonate Static Yeild Load: 2.10 kN Standard: DIN 6325
Part Number: DP080-020-PC-1 Dowel Pins - 8x20 Standard - Polycarbonate Pin Out of Stock \| Backorder Now \| Orders can be expected around Sun, Oct 05, 2025 Regular price $30.41 AUD Regular price ~~$36.49 AUD~~ Sale price $30.41 AUD Unit price per Each Quantity Required Backorder: Out of Stock.
Diameter (D) 8.000 mm _{+ 0.03 / - 0.00} (Equiv. 0.315 in.)	Length (L) 20.00 mm (Equiv. 0.787 in.)	Approx. Overall Length 20.00 mm (Equiv. 0.787 in.)
Material: Polycarbonate Type: 1 (Chamfer One End) Static Yeild Load: 2.10 kN Standard: DIN 6325
Part Number: DP080-020-PC-1 Dowel Pins - 8x20 Standard - Polycarbonate Pin Out of Stock \| Backorder Now \| Orders can be expected around Sun, Oct 05, 2025 Regular price $30.41 AUD Regular price ~~$36.49 AUD~~ Sale price $30.41 AUD Unit price per Each Quantity Required Backorder: Out of Stock.
DP080-020-PC-1 --- Dowel Pins - 8x20 Standard - Polycarbonate Pin Sale DP080-020-PC-1 --- Dowel Pins - 8x20 Standard - Polycarbonate Pin Regular price $30.41 AUD Regular price ~~$36.49 AUD~~ Sale price $30.41 AUD Unit price per Out of stock! Backorder Now Sale
Diameter (D) 8.000 mm _{+ 0.03 / - 0.00} (Equiv. 0.315 in.)	Length (L) 25.00 mm (Equiv. 0.984 in.)	Approx. Overall Length 25.00 mm (Equiv. 0.984 in.)	Type 1 (Chamfer One End)
Material: Polycarbonate Static Yeild Load: 2.10 kN Standard: DIN 6325
Part Number: DP080-025-PC-1 Dowel Pins - 8x25 Standard - Polycarbonate Pin Out of Stock \| Backorder Now \| Orders can be expected around Sun, Oct 05, 2025 Regular price $32.41 AUD Regular price ~~$38.89 AUD~~ Sale price $32.41 AUD Unit price per Each Quantity Required Backorder: Out of Stock.
Diameter (D) 8.000 mm _{+ 0.03 / - 0.00} (Equiv. 0.315 in.)	Length (L) 25.00 mm (Equiv. 0.984 in.)	Approx. Overall Length 25.00 mm (Equiv. 0.984 in.)
Material: Polycarbonate Type: 1 (Chamfer One End) Static Yeild Load: 2.10 kN Standard: DIN 6325
Part Number: DP080-025-PC-1 Dowel Pins - 8x25 Standard - Polycarbonate Pin Out of Stock \| Backorder Now \| Orders can be expected around Sun, Oct 05, 2025 Regular price $32.41 AUD Regular price ~~$38.89 AUD~~ Sale price $32.41 AUD Unit price per Each Quantity Required Backorder: Out of Stock.
DP080-025-PC-1 --- Dowel Pins - 8x25 Standard - Polycarbonate Pin Sale DP080-025-PC-1 --- Dowel Pins - 8x25 Standard - Polycarbonate Pin Regular price $32.41 AUD Regular price ~~$38.89 AUD~~ Sale price $32.41 AUD Unit price per Out of stock! Backorder Now Sale
