Collection: Motors - Vibrating
Motors -> VibratingThere are 5 products in the sub-categories of Motors - Vibrating. Browse the Motors - Vibrating products table.
Category Details
A selection of Vibrating Motors. This is the main category in this series
- This category will be discontinued when the remaining items are sold.
- All items are priced to quit.
- Backorders or orders for previously listed items in the category will only be available for very large orders.
Miniature Bearings Australia - MBA Minibearings
Additional resources:
A more concise listing may be found in the Motors - Vibrating category on the Small Parts & Bearings online store.
| Description | Information | Information | Information | Information | Information |
Indicative Image |
|---|---|---|---|---|---|---|
|
Description
8mm Dia x 3.4mm Thick
|
Information
Start Voltage 2.3V
|
Information
Operating Voltage Range 2.3-3.5V
|
Information
Nominal Voltage 3.0V
|
Information
Speed 12000RPM
|
Information
Current 80mA
|
|
|
Part Number: AD0834AD (10 Pcs)
Vibrating Motors - 8mm Dia x 3.4mm Thick Start Voltage 2.3V - Operating Voltage Range 2.3-3.5V 4 units (40 pcs) Available Now | Item Discontinued - Up to 4 may be ordered online. No backorders. Please contact us if you need a larger quantity Regular price
$15.00 AUD
Regular price
Unit price
per
Excludes GST and overseas Taxes & Duties Per 10
|
||||||
| Description | Information | Information | Information |
Indicative Image |
||
|
Description
8mm Dia x 3.4mm Thick
|
Information
Start Voltage 2.3V
|
Information
Operating Voltage Range 2.3-3.5V
|
Information
Nominal Voltage 3.0V
|
|
||
| Information: Speed 12000RPM Information: Current 80mA | ||||||
|
Part Number: AD0834AD (10 Pcs)
Vibrating Motors - 8mm Dia x 3.4mm Thick Start Voltage 2.3V - Operating Voltage Range 2.3-3.5V 4 units (40 pcs) Available Now | Item Discontinued - Up to 4 may be ordered online. No backorders. Please contact us if you need a larger quantity Regular price
$15.00 AUD
Regular price
Unit price
per
Excludes GST and overseas Taxes & Duties Per 10
|
||||||
|
||||||
|
Description
10mm Dia x 2mm Thick
|
Information
Operating Voltage Range 2.3-3.5V
|
Information
Start Voltage 2.3V
|
Information
Nominal 3.0V
|
Information
Speed 12000RPM
|
Information
Current 80mA
|
|
|
Part Number: AD1012AD (10 Pcs)
Vibrating Motors - 10mm Dia x 2mm Thick Operating Voltage Range 2.3-3.5V - Start Voltage 2.3V 28 units (280 pcs) Available Now | Item Discontinued - Up to 28 may be ordered online. No backorders. Please contact us if you need a larger quantity Regular price
$20.00 AUD
Regular price
Unit price
per
Excludes GST and overseas Taxes & Duties Per 10
|
||||||
|
Description
10mm Dia x 2mm Thick
|
Information
Operating Voltage Range 2.3-3.5V
|
Information
Start Voltage 2.3V
|
Information
Nominal 3.0V
|
|
||
| Information: Speed 12000RPM Information: Current 80mA | ||||||
|
Part Number: AD1012AD (10 Pcs)
Vibrating Motors - 10mm Dia x 2mm Thick Operating Voltage Range 2.3-3.5V - Start Voltage 2.3V 28 units (280 pcs) Available Now | Item Discontinued - Up to 28 may be ordered online. No backorders. Please contact us if you need a larger quantity Regular price
$20.00 AUD
Regular price
Unit price
per
Excludes GST and overseas Taxes & Duties Per 10
|
||||||
|
||||||
|
Description
12.0mm Diameter x 30.0mm Long
|
Information
Operating Voltage 3.0-6.0V Nominal 6V
|
Information
No Load 12800RPM /Max Efficiency 9000RPM
|
Information
Max efficiency Torque 6.0g-cm/22g-cm stall torque
|
Information
No Load 0.07A Max Efficiency 0.26A
|
|
|
|
Part Number: AD1230CAVAD (10 Pcs)
Vibrating Motors - 12.0mm Diameter x 30.0mm Long Operating Voltage 3.0-6.0V Nominal 6V - No Load 12800RPM /Max Efficiency 9000RPM 5 units (50 pcs) Available Now | Item Discontinued - Up to 5 may be ordered online. No backorders. Please contact us if you need a larger quantity Regular price
$8.00 AUD
Regular price
Unit price
per
Excludes GST and overseas Taxes & Duties Per 10
|
||||||
|
Description
12.0mm Diameter x 30.0mm Long
|
Information
Operating Voltage 3.0-6.0V Nominal 6V
|
Information
No Load 12800RPM /Max Efficiency 9000RPM
|
Information
Max efficiency Torque 6.0g-cm/22g-cm stall torque
|
|
||
| Information: No Load 0.07A Max Efficiency 0.26A | ||||||
|
Part Number: AD1230CAVAD (10 Pcs)
Vibrating Motors - 12.0mm Diameter x 30.0mm Long Operating Voltage 3.0-6.0V Nominal 6V - No Load 12800RPM /Max Efficiency 9000RPM 5 units (50 pcs) Available Now | Item Discontinued - Up to 5 may be ordered online. No backorders. Please contact us if you need a larger quantity Regular price
$8.00 AUD
Regular price
Unit price
per
Excludes GST and overseas Taxes & Duties Per 10
|
||||||
|
||||||
|
Description
Vibrating Motor
|
Information
23.7mm Diameter x 27.0mm Long
|
Information
Operating Voltage 3.0-12V Nominal 12V
|
Information
5600RPM
|
Information
100g.cm stall torque
|
Information
Max Efficiency Currrent 0.1A
|
|
|
Part Number: AD260RAAD (10 Pcs)
Vibrating Motors - Vibrating Motor 23.7mm Diameter x 27.0mm Long - Operating Voltage 3.0-12V Nominal 12V 8 units (80 pcs) Available Now | Item Discontinued - Up to 8 may be ordered online. No backorders. Please contact us if you need a larger quantity Regular price
$20.00 AUD
Regular price
Unit price
per
Excludes GST and overseas Taxes & Duties Per 10
|
||||||
|
Description
Vibrating Motor
|
Information
23.7mm Diameter x 27.0mm Long
|
Information
Operating Voltage 3.0-12V Nominal 12V
|
Information
5600RPM
|
|
||
| Information: 100g.cm stall torque Information: Max Efficiency Currrent 0.1A | ||||||
|
Part Number: AD260RAAD (10 Pcs)
Vibrating Motors - Vibrating Motor 23.7mm Diameter x 27.0mm Long - Operating Voltage 3.0-12V Nominal 12V 8 units (80 pcs) Available Now | Item Discontinued - Up to 8 may be ordered online. No backorders. Please contact us if you need a larger quantity Regular price
$20.00 AUD
Regular price
Unit price
per
Excludes GST and overseas Taxes & Duties Per 10
|
||||||
|
||||||
|
Description
Vibrating Motor
|
Information
24.0mm Diameter x 30.5mm Long
|
Information
Operating Voltage 3.0-12V Nominal 6V
|
Information
Double weights for extra vibration
|
Information
No Load 3550RPM/0.035A
|
Information
Max Efficiency 3400RPM/0.06A/5.0G-CM
|
|
| Information: 0.5W | ||||||
|
Part Number: ADDCM280AD
Vibrating Motors - Vibrating Motor 24.0mm Diameter x 30.5mm Long - Operating Voltage 3.0-12V Nominal 6V 10 Available Now | Item Discontinued - Up to 10 may be ordered online. No backorders. Please contact us if you need a larger quantity Regular price
$8.00 AUD
Regular price
Unit price
per
Excludes GST and overseas Taxes & Duties Each
|
||||||
|
Description
Vibrating Motor
|
Information
24.0mm Diameter x 30.5mm Long
|
Information
Operating Voltage 3.0-12V Nominal 6V
|
Information
Double weights for extra vibration
|
|
||
| Information: No Load 3550RPM/0.035A Information: Max Efficiency 3400RPM/0.06A/5.0G-CM Information: 0.5W | ||||||
|
Part Number: ADDCM280AD
Vibrating Motors - Vibrating Motor 24.0mm Diameter x 30.5mm Long - Operating Voltage 3.0-12V Nominal 6V 10 Available Now | Item Discontinued - Up to 10 may be ordered online. No backorders. Please contact us if you need a larger quantity Regular price
$8.00 AUD
Regular price
Unit price
per
Excludes GST and overseas Taxes & Duties Each
|
||||||
|
||||||
