Collection: Bearings - Single Row Ball - Flanged - High Precision - Standard

Bearings (With Images)

Single Row Ball

Flanged

High Precision

Extended Inner
Standard

174 Products in this selection

Stainless Steel Bearings with Flanges - Abec 5 and Abec 7.
Single row radial ball bearings with flanges.
High precision bearings are not recommended for skates or fishing reels.
High precision bearings are used in accurately balanced application such as spindles, gyros and medical equipment.
If your application is not of a precision nature, standard bearings may be more suitable (and less expensive).

Miniature Bearings Australia (Minibearings)

Additional resources:
Tolerances
High Precision Bearings Catalogue PDF
Shafting

A more concise listing may be found on the Smallparts store at Bearings - Single Row Ball - Flanged - High Precision - Standard. Smallparts promote the most popular MBA products.

ID (d)	OD (D)	Width (B)	Inner Ring Width (Bn)	Flange Diameter (DF)	Flange Width (BF)	Indicative Image
ID (d) 9.525 mm + 0.000 / - 0.005 _{(0.375 in.)}	OD (D) 22.225 mm + 0.000 / - 0.005 _{(0.875 in.)}	Width (B) 7.142 mm + 0.000 / - 0.040 _{(0.281 in.)}		Flange Diameter (DF) 24.613 mm	Flange Width (BF) 1.575 mm
Material: Stainless Steel AISI 440C Precision Grade: Abec 5 Closure Type: ZZS Bearing Type: Radial Flanged Lubricant: Turmogrease Li 802 EP plus
Part Number: SFR6A-ZZS-MC34-GR5-R-G48 (20 Pcs) Single Row Ball Bearings - 9.525x22.225x7.142 mm - Stainless Steel AISI 440C Out of Stock \| Backorder Now \| Orders can be expected around Thu, Aug 14, 2025 Regular price $2,442.95 AUD Regular price Sale price $2,442.95 AUD Unit price per Per 20
ID (d)	OD (D)	Width (B)	Inner Ring Width (Bn)	Indicative Image
ID (d) 9.525 mm + 0.000 / - 0.005 _{(0.375 in.)}	OD (D) 22.225 mm + 0.000 / - 0.005 _{(0.875 in.)}	Width (B) 7.142 mm + 0.000 / - 0.040 _{(0.281 in.)}
Material: Stainless Steel AISI 440C Flange Diameter (DF): 24.613 mm Flange Width (BF): 1.575 mm Precision Grade: Abec 5 Closure Type: ZZS Bearing Type: Radial Flanged Lubricant: Turmogrease Li 802 EP plus
Part Number: SFR6A-ZZS-MC34-GR5-R-G48 (20 Pcs) Single Row Ball Bearings - 9.525x22.225x7.142 mm - Stainless Steel AISI 440C Out of Stock \| Backorder Now \| Orders can be expected around Thu, Aug 14, 2025 Regular price $2,442.95 AUD Regular price Sale price $2,442.95 AUD Unit price per Per 20 View the product page first if you are unsure.
SFR6A-ZZS-MC34-GR5-R-G48 (20 Pcs) --- Single Row Ball Bearings - 9.525x22.225x7.142 mm - Stainless Steel AISI 440C SFR6A-ZZS-MC34-GR5-R-G48 (20 Pcs) --- Single Row Ball Bearings - 9.525x22.225x7.142 mm - Stainless Steel AISI 440C Regular price $2,442.95 AUD Regular price Sale price $2,442.95 AUD Unit price per Out of stock! Backorder Now
ID (d) 9.525 mm + 0.000 / - 0.004 _{(0.375 in.)}	OD (D) 22.225 mm + 0.000 / - 0.005 _{(0.875 in.)}	Width (B) 7.142 mm + 0.000 / - 0.040 _{(0.281 in.)}		Flange Diameter (DF) 24.613 mm	Flange Width (BF) 1.575 mm
Material: Stainless Steel AISI 440C Precision Grade: Abec 7 Closure Type: ZZS Bearing Type: Radial Flanged Lubricant: Turmogrease Li 802 EP plus
Part Number: SFR6A-ZZS-MC34-GR7-R-G48 (20 Pcs) Single Row Ball Bearings - 9.525x22.225x7.142 mm - Stainless Steel AISI 440C Out of Stock \| Backorder Now \| Orders can be expected around Thu, Aug 14, 2025 Regular price $3,174.59 AUD Regular price Sale price $3,174.59 AUD Unit price per Per 20
ID (d) 9.525 mm + 0.000 / - 0.004 _{(0.375 in.)}	OD (D) 22.225 mm + 0.000 / - 0.005 _{(0.875 in.)}	Width (B) 7.142 mm + 0.000 / - 0.040 _{(0.281 in.)}
Material: Stainless Steel AISI 440C Flange Diameter (DF): 24.613 mm Flange Width (BF): 1.575 mm Precision Grade: Abec 7 Closure Type: ZZS Bearing Type: Radial Flanged Lubricant: Turmogrease Li 802 EP plus
Part Number: SFR6A-ZZS-MC34-GR7-R-G48 (20 Pcs) Single Row Ball Bearings - 9.525x22.225x7.142 mm - Stainless Steel AISI 440C Out of Stock \| Backorder Now \| Orders can be expected around Thu, Aug 14, 2025 Regular price $3,174.59 AUD Regular price Sale price $3,174.59 AUD Unit price per Per 20 View the product page first if you are unsure.
SFR6A-ZZS-MC34-GR7-R-G48 (20 Pcs) --- Single Row Ball Bearings - 9.525x22.225x7.142 mm - Stainless Steel AISI 440C SFR6A-ZZS-MC34-GR7-R-G48 (20 Pcs) --- Single Row Ball Bearings - 9.525x22.225x7.142 mm - Stainless Steel AISI 440C Regular price $3,174.59 AUD Regular price Sale price $3,174.59 AUD Unit price per Out of stock! Backorder Now
ID (d) 10.000 mm + 0.000 / - 0.005 _{(0.394 in.)}	OD (D) 19.000 mm + 0.000 / - 0.005 _{(0.748 in.)}	Width (B) 5.000 mm + 0.000 / - 0.040 _{(0.197 in.)}		Flange Diameter (DF) 21.000 mm	Flange Width (BF) 1.000 mm
Material: Stainless Steel AISI 440C Precision Grade: Abec 5 Closure Type: Open Bearing Type: Radial Flanged Lubricant: Windsorlube L245X - L23 Oil
Part Number: SF6800-MC34-GR5-R-L23 (20 Pcs) Single Row Ball Bearings - 10x19x5 mm - Stainless Steel AISI 440C Out of Stock \| Backorder Now \| Orders can be expected around Thu, Aug 14, 2025 Regular price $1,642.23 AUD Regular price Sale price $1,642.23 AUD Unit price per Per 20
ID (d) 10.000 mm + 0.000 / - 0.005 _{(0.394 in.)}	OD (D) 19.000 mm + 0.000 / - 0.005 _{(0.748 in.)}	Width (B) 5.000 mm + 0.000 / - 0.040 _{(0.197 in.)}
Material: Stainless Steel AISI 440C Flange Diameter (DF): 21.000 mm Flange Width (BF): 1.000 mm Precision Grade: Abec 5 Closure Type: Open Bearing Type: Radial Flanged Lubricant: Windsorlube L245X - L23 Oil
Part Number: SF6800-MC34-GR5-R-L23 (20 Pcs) Single Row Ball Bearings - 10x19x5 mm - Stainless Steel AISI 440C Out of Stock \| Backorder Now \| Orders can be expected around Thu, Aug 14, 2025 Regular price $1,642.23 AUD Regular price Sale price $1,642.23 AUD Unit price per Per 20 View the product page first if you are unsure.
SF6800-MC34-GR5-R-L23 (20 Pcs) --- Single Row Ball Bearings - 10x19x5 mm - Stainless Steel AISI 440C SF6800-MC34-GR5-R-L23 (20 Pcs) --- Single Row Ball Bearings - 10x19x5 mm - Stainless Steel AISI 440C Regular price $1,642.23 AUD Regular price Sale price $1,642.23 AUD Unit price per Out of stock! Backorder Now
ID (d) 10.000 mm + 0.000 / - 0.004 _{(0.394 in.)}	OD (D) 19.000 mm + 0.000 / - 0.005 _{(0.748 in.)}	Width (B) 5.000 mm + 0.000 / - 0.040 _{(0.197 in.)}		Flange Diameter (DF) 21.000 mm	Flange Width (BF) 1.000 mm
Material: Stainless Steel AISI 440C Precision Grade: Abec 7 Closure Type: Open Bearing Type: Radial Flanged Lubricant: Windsorlube L245X - L23 Oil
Part Number: SF6800-MC34-GR7-R-L23 (40 Pcs) Single Row Ball Bearings - 10x19x5 mm - Stainless Steel AISI 440C Out of Stock \| Backorder Now \| Orders can be expected around Thu, Aug 14, 2025 Regular price $3,719.59 AUD Regular price Sale price $3,719.59 AUD Unit price per Per 40
ID (d) 10.000 mm + 0.000 / - 0.004 _{(0.394 in.)}	OD (D) 19.000 mm + 0.000 / - 0.005 _{(0.748 in.)}	Width (B) 5.000 mm + 0.000 / - 0.040 _{(0.197 in.)}
Material: Stainless Steel AISI 440C Flange Diameter (DF): 21.000 mm Flange Width (BF): 1.000 mm Precision Grade: Abec 7 Closure Type: Open Bearing Type: Radial Flanged Lubricant: Windsorlube L245X - L23 Oil
Part Number: SF6800-MC34-GR7-R-L23 (40 Pcs) Single Row Ball Bearings - 10x19x5 mm - Stainless Steel AISI 440C Out of Stock \| Backorder Now \| Orders can be expected around Thu, Aug 14, 2025 Regular price $3,719.59 AUD Regular price Sale price $3,719.59 AUD Unit price per Per 40 View the product page first if you are unsure.
SF6800-MC34-GR7-R-L23 (40 Pcs) --- Single Row Ball Bearings - 10x19x5 mm - Stainless Steel AISI 440C SF6800-MC34-GR7-R-L23 (40 Pcs) --- Single Row Ball Bearings - 10x19x5 mm - Stainless Steel AISI 440C Regular price $3,719.59 AUD Regular price Sale price $3,719.59 AUD Unit price per Out of stock! Backorder Now
ID (d) 10.000 mm + 0.000 / - 0.005 _{(0.394 in.)}	OD (D) 19.000 mm + 0.000 / - 0.005 _{(0.748 in.)}	Width (B) 7.000 mm + 0.000 / - 0.040 _{(0.276 in.)}		Flange Diameter (DF) 21.000 mm	Flange Width (BF) 1.500 mm
Material: Stainless Steel AISI 440C Precision Grade: Abec 5 Closure Type: ZZS Bearing Type: Radial Flanged Lubricant: Turmogrease Li 802 EP plus
Part Number: SF6800B-ZZS-MC34-GR5-R-G48 (20 Pcs) Single Row Ball Bearings - 10x19x7 mm - Stainless Steel AISI 440C Out of Stock \| Backorder Now \| Orders can be expected around Thu, Aug 14, 2025 Regular price $1,723.50 AUD Regular price Sale price $1,723.50 AUD Unit price per Per 20
ID (d) 10.000 mm + 0.000 / - 0.005 _{(0.394 in.)}	OD (D) 19.000 mm + 0.000 / - 0.005 _{(0.748 in.)}	Width (B) 7.000 mm + 0.000 / - 0.040 _{(0.276 in.)}
Material: Stainless Steel AISI 440C Flange Diameter (DF): 21.000 mm Flange Width (BF): 1.500 mm Precision Grade: Abec 5 Closure Type: ZZS Bearing Type: Radial Flanged Lubricant: Turmogrease Li 802 EP plus
Part Number: SF6800B-ZZS-MC34-GR5-R-G48 (20 Pcs) Single Row Ball Bearings - 10x19x7 mm - Stainless Steel AISI 440C Out of Stock \| Backorder Now \| Orders can be expected around Thu, Aug 14, 2025 Regular price $1,723.50 AUD Regular price Sale price $1,723.50 AUD Unit price per Per 20 View the product page first if you are unsure.
SF6800B-ZZS-MC34-GR5-R-G48 (20 Pcs) --- Single Row Ball Bearings - 10x19x7 mm - Stainless Steel AISI 440C SF6800B-ZZS-MC34-GR5-R-G48 (20 Pcs) --- Single Row Ball Bearings - 10x19x7 mm - Stainless Steel AISI 440C Regular price $1,723.50 AUD Regular price Sale price $1,723.50 AUD Unit price per Out of stock! Backorder Now
ID (d) 10.000 mm + 0.000 / - 0.004 _{(0.394 in.)}	OD (D) 19.000 mm + 0.000 / - 0.005 _{(0.748 in.)}	Width (B) 7.000 mm + 0.000 / - 0.040 _{(0.276 in.)}		Flange Diameter (DF) 21.000 mm	Flange Width (BF) 1.500 mm
Material: Stainless Steel AISI 440C Precision Grade: Abec 7 Closure Type: ZZS Bearing Type: Radial Flanged Lubricant: Turmogrease Li 802 EP plus
Part Number: SF6800B-ZZS-MC34-GR7-R-G48 (26 Pcs) Single Row Ball Bearings - 10x19x7 mm - Stainless Steel AISI 440C Out of Stock \| Backorder Now \| Orders can be expected around Thu, Aug 14, 2025 Regular price $2,910.05 AUD Regular price Sale price $2,910.05 AUD Unit price per Per 26
ID (d) 10.000 mm + 0.000 / - 0.004 _{(0.394 in.)}	OD (D) 19.000 mm + 0.000 / - 0.005 _{(0.748 in.)}	Width (B) 7.000 mm + 0.000 / - 0.040 _{(0.276 in.)}
Material: Stainless Steel AISI 440C Flange Diameter (DF): 21.000 mm Flange Width (BF): 1.500 mm Precision Grade: Abec 7 Closure Type: ZZS Bearing Type: Radial Flanged Lubricant: Turmogrease Li 802 EP plus
Part Number: SF6800B-ZZS-MC34-GR7-R-G48 (26 Pcs) Single Row Ball Bearings - 10x19x7 mm - Stainless Steel AISI 440C Out of Stock \| Backorder Now \| Orders can be expected around Thu, Aug 14, 2025 Regular price $2,910.05 AUD Regular price Sale price $2,910.05 AUD Unit price per Per 26 View the product page first if you are unsure.
SF6800B-ZZS-MC34-GR7-R-G48 (26 Pcs) --- Single Row Ball Bearings - 10x19x7 mm - Stainless Steel AISI 440C SF6800B-ZZS-MC34-GR7-R-G48 (26 Pcs) --- Single Row Ball Bearings - 10x19x7 mm - Stainless Steel AISI 440C Regular price $2,910.05 AUD Regular price Sale price $2,910.05 AUD Unit price per Out of stock! Backorder Now
