Miniature Bearings Australia
NT035C-BL-S4 - Datasheet
MBA
Category Information
Nuts - Blind - StandardStandard Blind Nuts. Blind nuts - Tee nuts.
- Put steel threads in soft materials like wood without counterboring.
Product Data
- Thread Size : 6-32 UNC (3.5mm)
- Flange Diameter
12.7
mm
(Equiv. 0.5 in.) - Barrel Height
4.8
mm
(Equiv. 0.189 in.) - Type Tee Nut
- Pitch 0.794 mm
- Threads Per Inch 32 TPI
- Material Stainless Steel 304
Product Compliance and Data
