NT080M-AE-S6 - Datasheet
MBA
Category Information
Nuts - AerotightAerotight Nuts. Aerotight is a Registered Trademark and can only be applied to goods manufactured by the Premier Screw and Repetition Company Limited.
- All-metal, self-locking nut designed to stay in place even under severe vibration. Works by using a locking collar that is deflected to grip the bolt's threads, creating a "prevailing torque" that prevents loosening.
- All-metal construction allows them to be used at higher temperatures and makes them resistant to oil.
- Also known as an Aerotight lock nut or Stiff Nut.
- Any company infringing the registered trade mark may be liable to legal proceedings.
- Aerotight nuts should not be used on damaged or interrupted threads.
- When assembled on the screw at least two threads should protrude through the Aerotight nut.
- Advantages: Will not work loose. No other locking device needed.
Product Data
- Thread Size : M8 (8x1.25mm)
- Pitch in mm / Threads Per Inch 1.250 mm / 20.32 TPI
- Overall Height (H)
10.00
mm
(Equiv. 0.394 in.) - Nut Height (F) 6.12 mm
- Across Flats (A/F) 13.00 mm
- Material Stainless Steel 316 (Similar to A4, 18-10)
Product Compliance and Data
Additional Resources
Cross References
- AIRM8S
- AIR-M8S
