SS080M-0080-C-MAG-SL - Datasheet

MBA

Product Data

• Thread Size : M8 (8x1.25mm)
• Thread Length (L) 8.00 mm
  (Equiv. 0.315 in.)
• Type Magnetic Tipped
• Magnet Size (M) 5 x 5 mm
• Hex Key Size 1.50
• Magnet Material Neodymium Iron Boron
• Drive Type Slot
• Finish Nickel Plated
• Material Carbon Steel
