THS040M-008-K-Z - Datasheet

MBA

Category Information

Screws - Thumb - Knurled - Steel

Steel Knurled Thumb Screws. Steel knurled head thumb screws

  • An expanded range may be available on special order. Please enquire.

Product Data

  • Thread Size (C) : M4 (4x0.7mm)
  • Thread Length (Tl) 8.00 mm +/- 0.20
    (Equiv. 0.315 in.)
  • Overall Length (L) 13.00 mm + / - 0.40
    (Equiv. 0.512 in.)
  • Head Diameter (D) 15.50 mm +/- 0.50
  • Head Height (H) 5.00 mm +/- 0.20
  • Finish Zinc Plated
  • Material Steel Zinc Plated
Country of Origin: TW

Product Compliance and Data

Additional Resources

View full details
THS040M-008-K-ZDiagramTHS040M-008-K-ZImage
