BF0318-0381-0445-BS4895HH - Datasheet
MBA
Category Information
Bushes - Flanged - Bronze - SinteredSintered Bronze Flanged Bushes. Oil impregnated flanged sintered bronze bushes.
- An expanded range may be available on special order. Please enquire.
- Precision items show an allowable Load Speed Rating in Newtons times RPM.
Product Data
- Nominal Inside Diameter (d)
:
31.750
mm
+ 0.36 / + 0.46
(Equiv. 1.25 in.) - Nominal Outside Diameter (D)
41.275
mm
+ 0.076 / + 0.102
(Equiv. 1.625 in.) - Length (s)
44.450
mm
+/- 0.127
(Equiv. 1.75 in.) - Flange OD (D1) 47.63 mm
- Flange Thickness (S1) 9.525 mm
- Comments Special OEM Item
- Material Sintered Bronze SAE 841
Product Compliance and Data
Additional Resources
- DU Bush Material Information
- General Bushes Catalogue
- Sintered Bronze Products Catalogue
- Solid Bronze Bushes catalogue
Cross References
- Westinghouse AM426
- Westinghouse AM426-112
- Westinghouse AM426-117
- Westinghouse AM426-26
