Miniature Bearings Australia
BP0100-0130-0100-BSLT - Datasheet
MBA
Category Information
Bushes - Unflanged - Bronze - SinteredSintered Bronze Unflanged Bushes. Oil impregnated sintered bronze bushes.
- An expanded range may be available on special order. Please enquire.
- Precision items show an allowable Load Speed Rating in Newtons times RPM.
Product Data
- Nominal Inside Diameter (d)
:
10.000
mm
+ 0.005 / + 0.030
(Equiv. 0.394 in.) - Nominal Outside Diameter (D)
13.000
mm
+ 0.025 / + 0.051
(Equiv. 0.512 in.) - Length (s)
10.000
mm
+/- 0.120
(Equiv. 0.394 in.) - Comments ISO2795
Product Compliance and Data
Additional Resources
- DU Bush Material Information
- General Bushes Catalogue
- Sintered Bronze Products Catalogue
- Solid Bronze Bushes catalogue
Cross References
- Oilite AM-1013-10
- Oilube AM-1013-10
- BP010001300100BS
- AM101310
