Miniature Bearings Australia

607-2RS-MC3 - Datasheet

MBA

Category Information

Bearings - Single Row Ball - Unflanged - Precision - Chrome Steel

Chrome Steel Precision Unflanged Single Row Ball Bearings. Chrome steel radial ball bearings.

Single row radial ball bearings are arguably the most common, widely used type of bearing. They consist of an inner ring, an outer ring, a set of balls, and a cage that retains the balls in a circular path.
Single row radial ball bearings are commonly used in a wide range of applications, including electric motors, fans, pumps, gearboxes, agricultural equipment, appliances, and automotive components.
They are versatile, cost-effective bearings that provide reliable support for radial loads and some axial loads in one direction. An expanded range may be available on special order. Please enquire.
Standard single row radial ball bearings.

Product Data

ID (d) : 7.000 mm _{+ 0.000 / - 0.0075}
(Equiv. 0.276 in.)
OD (D) 19.000 mm _{+ 0.000 / - 0.010}
(Equiv. 0.748 in.)
Width (B) 6.000 mm _{+ 0.000 / - 0.125}
(Equiv. 0.236 in.)
Precision Grade Abec 1
Closure Type 2RS
Bearing Type Radial
Material Chrome Steel SAE 52100

Lubrication Type Grease
Lubrication Name Standard Unspecified
Basic Part 607
Limiting Speed 24480
Cage Type Ribbon
Static Load Rating KGf 91
Dynamic Load Rating KGf 238
Radii 0.30 mm
Inner Shoulder (UI) 9.00mm
Outer Shoulder (UO) 16.50 mm
Number of Balls 6
Clearance MC3 (5 to 10)
Precision Grade Abec 1
Closure Type 2RS
Max Temperature 80 Deg. C

Country of Origin: JP

Product Compliance and Data

Additional Resources

Applications & Uses

RC Car Parts
RC Nitro Engine Parts
Corally - C4 - Bearing 7-19-6mm
Crono - 4WD 3 Diff 1-8 - Bearing 7-19-6mm
Mugen - Sport 1/8 Gas - Bearing 7-19-6mm
Ofna - GT LX - Bearing 7-19-6mm
Ofna - Hoar 4-WD Buggy - Bearing 7-19-6mm
Ofna - Pirate 1/8 Gas - Bearing 7-19-6mm
Ofna - Ultra GT - Bearing 7-19-6mm
Ofna - Ultra LX COMP RTR - Bearing 7-19-6mm
Ofna - Ultra LX Pro RTR - Bearing 7-19-6mm
Ofna - Ultra World 2 - Bearing 7-19-6mm
Ofna - World GT - Bearing 7-19-6mm
Ricambi - SVM Crono 1/8 Gas - Bearing 7-19-6mm
Serpent - 5x5 Mega Engine - Engine Front Bearing 7-19mm
ASP - 40 All Models - Bearing 7-19-6mm
ASP - 46 All Models - Bearing 7-19-6mm
Associate Electrics - AE.21 - 0.21 - Bearing 7-19-6mm
Bluebird - 28 All Models - Bearing 7-19-6mm
CMB - 15 - Bearing 7-19-6mm
CMB - 21 All Models - Bearing 7-19-6mm
CMB - EVO Marine - 45 - Bearing 7-19-6mm
CMB - LS Green Head Marine - 45 - Bearing 7-19-6mm
CMB - Old - 21 - Bearing 7-19-6mm
CMB - RS - 35 - Bearing 7-19-6mm
CMB - TT Marine - 21 - Bearing 7-19-6mm
Como - 21 All Models - Bearing 7-19-6mm
Como - 40 All Models - Bearing 7-19-6mm
Duratrax - Torque 21 - 40 - Bearing 7-19-6mm
Dynamite - Mach 26 - 29 - Bearing 7-19-6mm
Dynamite - Mach 427 - 21 - Bearing 7-19-6mm
Enya - 4C - Old - 90 - Bearing 7-19-6mm
Enya - X - 45 - Bearing 7-19-6mm
Fantom - FR27 - 40 - Bearing 7-19-6mm
Force - 61 All Models - Bearing 7-19-6mm
Force - All Other Rear Exhaust - 61 - Bearing 7-19-6mm
Force - E- 1501 Rear Exhaust EFRA - 21 - Bearing 7-19-6mm
Force - E-1503 Rear Exhaust Not EFRA - 0.21 - Bearing 7-19-6mm
Force - E-2101 Rear Exhaust - 0.15 - Bearing 7-19-6mm
Force - E-2106 Rear Exhaust - 0.15 - Bearing 7-19-6mm
GS General Silicone - 15R - 47 - Bearing 7-19-6mm
GS General Silicone - R21B01P - 76 - Bearing 7-19-6mm
GS General Silicone - R25MT - 0.15 - Bearing 7-19-6mm
HP - 46 All Models - Bearing 7-19-6mm
HP - Old/1975 - 40 - Bearing 7-19-6mm
HP - VT 4C - 61 - Bearing 7-19-6mm
HPI - 21 - Bearing 7-19-6mm
HPI - 49 - Bearing 7-19-6mm
Irvine - New Turbo - 72 - Bearing 7-19-6mm
LRP Nitro - Truggy 28 - 15 - Bearing 7-19-6mm
LRP Nitro - Z.12R Team Spec 2 - 12 - Bearing 7-19-6mm
LRP Nitro - Z.28R Spec 2 Pullstart - 12 - Bearing 7-19-6mm
Mac - Outboard - 21 - Bearing 7-19-6mm
Magnum Power - XL - 36 - Bearing 7-19-6mm
Magnum Power - XL - 40 - Bearing 7-19-6mm
Magnum Power - XL - 52 - Bearing 7-19-6mm
MDS - 40 All Models - Bearing 7-19-6mm
Moki - All - 61 - Bearing 7-19-6mm
Moki - Marine - 120 - Bearing 7-19-6mm
MVVS - 1.6 All Models - Bearing 7-19-6mm
MVVS - GFR - 77 - Bearing 7-19-6mm
MVVS - GFS - 40 - Bearing 7-19-6mm
MVVS - Glow Engine - 1.5 - Bearing 7-19-6mm
MVVS - GRRT - 40 - Bearing 7-19-6mm
Nova Rossi - Nova - 28 4.66CC - Bearing 7-19-6mm
Ofna - 21 - 15 2.5CC - Bearing 7-19-6mm
Ofna - Hyper.12 - 21 - Bearing 7-19-6mm
OPS - 12 - Bearing 7-19-6mm
OPS - 15 All Models - Bearing 7-19-6mm
OPS - 35 All Models - Bearing 7-19-6mm
OPS - 90 All Models - Bearing 7-19-6mm
OPS - Old - 80 - Bearing 7-19-6mm
OPS - Pro - 30 - Bearing 7-19-6mm
OPS - Rotor BRGS - 60 - Bearing 7-19-6mm
OS - 21 RX-B RX-M - Front Bearing 7-19-6mm
OS - 40 H - 2 Stroke - Front Bearing 7-19-6mm
OS - Max-H 40 - Front Bearing 7-19-6mm
OS - Outboard Marine - 120 - Bearing 7-19-6mm
OS - RG - 61 - Bearing 7-19-6mm
OS - RG P - 61 - Bearing 7-19-6mm
OS - RG-M Marine - 21 - Bearing 7-19-6mm
OS - RG-MX - 21 - Bearing 7-19-6mm
OS - RGX P - 21 - Bearing 7-19-6mm
OS - RX - 21 - Bearing 7-19-6mm
OS - RX With 10C - 140 - Bearing 7-19-6mm
OS - RX-B - 15 - Bearing 7-19-6mm
OS - RX-M Marine - 61 - Bearing 7-19-6mm
OS - VG P - 46 - Bearing 7-19-6mm
OS - XM Marine Outboard - 21 - Bearing 7-19-6mm
Picco - 15 - 2 Stroke - Front Bearing 7-19-6mm
Picco - 21 EXR - 2 Stroke - Front Bearing 7-19-6mm
Picco - 40 - 2 Stroke - Front Bearing 7-19-6mm
Picco - 40 Pylon - 2 Stroke - Front Bearing 7-19-6mm
Picco - 45 - 2 Stroke - Front Bearing 7-19-6mm
Picco - 45 All Models - Bearing 7-19-6mm
Picco - 45 EXR - 2 Stroke - Front Bearing 7-19-6mm
Picco - 45 Pylon - 2 Stroke - Front Bearing 7-19-6mm
Picco - 49 - Bearing 7-19-6mm
Picco - 61 All Models - Bearing 7-19-6mm
Picco - 80 All Models - Bearing 7-19-6mm
Picco - 90 All Models - Bearing 7-19-6mm
Picco - P5 - 21 - Bearing 7-19-6mm
Picco - P5 EXR - 27 - Bearing 7-19-6mm
Picco - P6 - 21 - Bearing 7-19-6mm
PIP Marine - A90HP 4 BGS - 28 - Bearing 7-19-6mm
Power Racing - 21 - 45 - Bearing 7-19-6mm
Power Racing - 26 - 90 - Bearing 7-19-6mm
RB - 15 All Models - Bearing 7-19-6mm
RB - X - 21 - Bearing 7-19-6mm
Rossi - Blackhead - 91 - Bearing 7-19-6mm
Rossi - Revo Marine - 60 - Bearing 7-19-6mm
SH - SH-28 - 12 - Bearing 7-19-6mm
SH - SH-28 Pro - 21 - Bearing 7-19-6mm
Stalker - Pro - 27 - Bearing 7-19-6mm
Super Tigre - Bull Ring - 46 - Bearing 7-19-6mm
Super Tigre - G - 29 - Bearing 7-19-6mm
Super Tigre - G - 46 - Bearing 7-19-6mm
Super Tigre - G Sport W-Muffler - 60 - Bearing 7-19-6mm
Super Tigre - G34 - 20 - Bearing 7-19-6mm
Super Tigre - G51 Ring - 34 - Bearing 7-19-6mm
Super Tigre - GS40 Ring - 34 - Bearing 7-19-6mm
Super Tigre - GS45 ABC - 40 - Bearing 7-19-6mm
Super Tigre - Marine - 45 - Bearing 7-19-6mm
Super Tigre - S - 40 - Bearing 7-19-6mm
Super Tigre - S - 71 - Bearing 7-19-6mm
Super Tigre - SK - 18 - Bearing 7-19-6mm
Super Tigre - ST - 18 - Bearing 7-19-6mm
Super Tigre - ST - 45 - Bearing 7-19-6mm
Super Tigre - ST K - 56 - Bearing 7-19-6mm
Super Tigre - ST Old - 51 - Bearing 7-19-6mm
Super Tigre - X - 21 - Bearing 7-19-6mm
Super Tigre - X - 60 - Bearing 7-19-6mm
Thunder Tiger - 21 O-B - 2 Stroke - Bearing for Adaptor Plate for Crankshaft 7-19mm
Thunder Tiger - 21 O-B - 2 Stroke - Front Bearing 7-19-6mm
Thunder Tiger - Evo - 15 - Bearing 7-19-6mm
Thunder Tiger - Marine - 12 - Bearing 7-19-6mm
Thunder Tiger - Pro - 120 - Bearing 7-19-6mm
Thunder Tiger - Pro 21B - RC ABS-RC - Front Bearing 7-19-6mm
Webra - Heli - 2.2 - Bearing 7-19-6mm
Webra - Speed Heli MOD 1023H - 61 - Bearing 7-19-6mm
Webra - T46 All Models - Bearing 7-19-6mm
XTM Racing - 18 - 35 - Bearing 7-19-6mm
XTM Racing - 24.7 Pro - 21 - Bearing 7-19-6mm
XTM Racing - 24.7 Pull Start - 18 - Bearing 7-19-6mm

Cross References

5972K225
Nachi 607-2NK
ISO 6072RS
ISO 607-2RS
WIB 607-2RSR
NTN 607LLU
ISO 607RS
ISO 607-RS
WIB 607-RSR
607DDU
607RSR
6072RSR
607-RSMC3
607-2RSMC3
6072RSMC3
607RSMC3
6072NK
607 Basic Size Ref
