Miniature Bearings Australia
RP064-0222-C - Datasheet
MBA
Category Information
Pins - Roll - Carbon SteelCarbon Steel Roll Pins. Plain carbon spring steel DIN1481/ISO8752.
- An expanded range may be available on special order. Please enquire.
- Also known as sel-lok and bissell pins
Product Data
- Nominal Diameter (D) : 6.35 mm
- Length (L) 22.23 mm
- Free Diameter 6.98 mm
- Thickness (S) 1.22 mm
- Chamfer Length (cL) 0.31-1.65 mm
- Chamfer Diameter (cD) 6.2 mm
- Standard DIN1481 / ISO8752
- Type Standard
- Material Carbon Spring Steel Self Finish
Product Compliance and Data
Additional Resources
Cross References
- 98296A925
- Huyett® SPP-250-0875
- NoCor® SPP-250-0875
- SPP2500875
