Miniature Bearings Australia
MR95A-2RG-ECO - Datasheet
ECO
Category Information
Bearings - Single Row Ball - Unflanged - Precision - Chrome SteelChrome Steel Precision Unflanged Single Row Ball Bearings. Chrome steel radial ball bearings.
- Single row radial ball bearings are arguably the most common, widely used type of bearing. They consist of an inner ring, an outer ring, a set of balls, and a cage that retains the balls in a circular path.
- Single row radial ball bearings are commonly used in a wide range of applications, including electric motors, fans, pumps, gearboxes, agricultural equipment, appliances, and automotive components.
- They are versatile, cost-effective bearings that provide reliable support for radial loads and some axial loads in one direction. An expanded range may be available on special order. Please enquire.
- Standard single row radial ball bearings.
Product Data
- ID (d)
:
5.000
mm
(Equiv. 0.197 in.) - OD (D)
9.000
mm
(Equiv. 0.354 in.) - Width (B)
3.000
mm
(Equiv. 0.118 in.) - Precision Grade Economy
- Closure Type 2GS
- Bearing Type Radial
- Material Chrome Steel SAE 52100
- Lubrication Type Grease
- Lubrication Name Standard Unspecified
- Basic Part MR95A
- Limiting Speed 42750
- Cage Type Standard
- Static Load Rating KGf 16.2
- Dynamic Load Rating KGf 41.8
- Radii 0.15 mm
- Inner Shoulder (UI) 6.00mm
- Outer Shoulder (UO) 8.20 mm
- Number of Balls 8
- Clearance ECO (5 to 23)
- Precision Grade ECO
- Closure Type 2RB
- Max Temperature 80 Deg. C
Product Compliance and Data
Additional Resources
- Catalogue: Ceramic Bearings Catalogue
- Catalogue: Plastic Bearings Catalogue
- Catalogue: Standard Bearings Catalogue
- General: Bearing Cleanliness
- General: Bearing Clearances
- General: Bearing Flanges & Snap Rings
- General: Bearing Retainers (Cages)
- General: General Loads Information
- General: Lubrication
- General: Prefix & Suffix Guide
- General: Static vs Dynamic Loads
- Materials: 316 Stainless
- Materials: CASSTOP Anti-Corrosion Bearing Material
- Materials: Ceramic vs Ceramic Hybrid
- Materials: Ceramic Bearings in Vibratory Applications
- Materials: Ceramic Hybrid Bearings in Vibratory Applications
- Materials: General Bearing Materials
- Materials: Magnetism & Bearings
- Precision: 316 Stainless & Plastic Bearing Tolerances
- Precision: ABEC Basic Information
- Precision: Precision Bearing Tolerances
- Problem Solving: Bearing Failure
- Problem Solving: Fatigue (L10 Life)
- Problem Solving: Noise
Applications & Uses
- RC Car Parts
- Associated - Nitro TC3 - Bearing 5-9-3mm
- Associated - Nitro TC3 RTR - Bearing 5-9-3mm
- Corally - Assassin Mid Motor and Stock Option - Bearing 5-9-3mm
- Corally - Assassin Modified - Spur Pulley - Bearing 5-9-3mm
- Corally - C4 - Bearing 5-9-3mm
- Corally - C4.1 - Bearing 5-9-3mm
- Corally - Mini Assassin - Bearing 5-9-3mm
- Corally - RDX - Bearing 5-9-3mm
- Corally - RDX - US Carpet Spec Edition - Bearing 5-9-3mm
- Corally - SP10 - Bearing 5-9-3mm
- Corally - SP12 - Bearing 5-9-3mm
- Corally - SR12M and RTR - Bearing 5-9-3mm
- Duratrax - Evader Buggy - Bearing 5-9-3mm
- Duratrax - Evader BX - Bearing 5-9-3mm
- Duratrax - Evader BX Nitro - Bearing 5-9-3mm
- Duratrax - Evader BX Pro RTR Electric - Bearing 5-9-3mm
- Duratrax - Evader ST - Bearing 5-9-3mm
- Duratrax - Evader ST Nitro - Bearing 5-9-3mm
- Duratrax - Evader ST Pro RTR - Bearing 5-9-3mm
- Losi - Mini LST - Bearing 5-9-3mm
- Losi - Mini T - Bearing 5-9-3mm
- Losi - Mini T Pro - Bearing 5-9-3mm
- Losi - Mini ZT - Bearing 5-9-3mm
- Schumaker - Cat 1998 - 2000 - Bearing 5-9-3mm
- Schumaker - Cat 2000 - Bearing 5-9-3mm
- Schumaker - Cat 2000 SE - Bearing 5-9-3mm
- Schumaker - Cat 3000 - Bearing 5-9-3mm
- Schumaker - Cat 3000 With Steering - Bearing 5-9-3mm
- Schumaker - Cougar 2000 - Bearing 5-9-3mm
- Schumaker - Cougar 2000 1995 Team Car - Bearing 5-9-3mm
- Schumaker - Fire Blade 2000 - Bearing 5-9-3mm
- Schumaker - FireBlade Evo - Bearing 5-9-3mm
- Schumaker - Fusion - Bearing 5-9-3mm
- Schumaker - Fusion 21 - Bearing 5-9-3mm
- Schumaker - Fusion R12 - Bearing 5-9-3mm
- Schumaker - Menace 21 - Bearing 5-9-3mm
- Schumaker - MI2 - Bearing 5-9-3mm
- Schumaker - MI2 EC - Bearing 5-9-3mm
- Schumaker - Nitro Fusion 21 and RTR - Bearing 5-9-3mm
- Schumaker - SST 2000 98 - Bearing 5-9-3mm
- Schumaker - SST 2000 Pro - Bearing 5-9-3mm
- Schumaker - Storm Truck 2000 - Bearing 5-9-3mm
- Serpent - Freedom T1 - Bearing 5-9-3mm
- Tamiya - 415MSX - Bearing 5-9-3mm
- Tamiya - DJ TRF 414 Pro Module Suspension - Bearing 5-9-3mm
- Tamiya - T-05 Upgrade - Bearing 5-9-3mm
- Tamiya - TB Evolution IV 4Evo 4 - Bearing 5-9-3mm
- Tamiya - TFF 415MS X - Bearing 5-9-3mm
- Tamiya - TRF 414-DJ Pro Module Suspension - Bearing 5-9-3mm
- Tamiya - TRF 415MS - Bearing 5-9-3mm
- Tamiya - TRF 415MS Complete - Bearing 5-9-3mm
- Trinity - Itsy Bitsy Spyder - Bearing 5-9-3mm
- Xray - FK5 Electric - Bearing 5-9-3mm
- Xray - T1 - Bearing 5-9-3mm
- Xray - T1 Evo 2 - Bearing 5-9-3mm
- Xray - T1 Factory Kit - Bearing 5-9-3mm
- Xray - T1 FK 05 Complete - Bearing 5-9-3mm
- Xray - T1 Racer - Bearing 5-9-3mm
- Xray - T1M Mini - Bearing 5-9-3mm
- Xray - X Ray - Bearing 5-9-3mm
Cross References
- BOCA MR95-2GS
- MR95A
- MR952GS
- MR95A Basic Size Ref
