S6910-2RS - Datasheet
MBA
Category Information
Bearings - Single Row Ball - Unflanged - Precision - 440C Stainless440C Stainless Precision Unflanged Single Row Ball Bearings. Stainless steel radial ball bearings
- Single row radial ball bearings are arguably the most common, widely used type of bearing. They consist of an inner ring, an outer ring, a set of balls, and a cage that retains the balls in a circular path.
- Single row radial ball bearings are commonly used in a wide range of applications, including electric motors, fans, pumps, gearboxes, agricultural equipment, appliances, and automotive components.
- They are versatile, cost-effective bearings that provide reliable support for radial loads and some axial loads in one direction. An expanded range may be available on special order. Please enquire.
- Standard single row radial ball bearings.
Product Data
- ID (d)
:
50.00
mm
+ 0.000 / - 0.012
(Equiv. 1.969 in.) - OD (D)
72.00
mm
+ 0.000 / - 0.013
(Equiv. 2.835 in.) - Width (B)
12.000
mm
+ 0.000 / - 0.120
(Equiv. 0.472 in.) - Precision Grade Abec 1
- Closure Type 2RS
- Bearing Type Radial
- Material Stainless Steel AISI 440C
- Lubrication Type Grease
- Lubrication Name Standard Unspecified
- Basic Part 6910
- Limiting Speed 6120
- Cage Type Rivetted
- Static Load Rating KGf 1195
- Dynamic Load Rating KGf 1484
- Radii 0.60 mm
- Inner Shoulder (UI) 56.90mm
- Outer Shoulder (UO) 67.65 mm
- Number of Balls 16
- Clearance CN (6 to 23)
- Precision Grade Abec 1
- Closure Type 2RS
- Max Temperature 80 Deg. C
