LCSQ-0381-057-4 - Datasheet
MBA
Category Information
Linear - Square HousingsSquare Housings Linear. Used to maintain radial integrity and eliminate the need for parallel shafting.
- Bearings are made from 6061-T6 Aluminum with Anodized finished.
- Equipped with bearing plugs that run on a single shaft.
- Threaded adjustable plugs are made from 316 Stainless with self-lubricating FrelonJ wear pads.
Product Data
- Suitable Shaft Diameter
:
38.10
mm
(Equiv. 1.5 in.) - Outside Diameter
44.45
mm
(Equiv. 1.75 in.) - No. Of Adjustable Sides. Four Sided
- Length 57.15 mm
- Load Capacity 417.30 kg
Product Compliance and Data
Additional Resources
Cross References
- PBC-410
- PBC410
