Category Information
O-Rings - General Purpose - Nitrile RubberNitrile Rubber General Purpose O-Rings. General purpose. Includes o-rings for dental handpiece applications.
- Temperature Range: -30 Deg C to +90 Deg C.
- Nitrile: Excellent resistance to mineral oil based fluids, hydrocarbon fuels, greases and water.
- Not suitable for aromatic hydrocarbons, chlorinated hydrocarbons, brake fluid and some fire resistant hydraulic fluids.
Product Data
- Inside Diameter (ID)
:
28.17
mm
(Equiv. 1.109 in.) - Section (t)
3.53
mm
(Equiv. 0.139 in.) - Colour Black
- Hardness Duro 70
- Material Nitrile (NBR, BUNA-N)
Product Compliance and Data
Additional Resources
Cross References
- 9452K36
- Small Parts ORB-216
- ORB216
- BS216-NBR70
- BS216NBR70
