Miniature Bearings Australia
DR-0030-B-N - Datasheet
MBA
Category Information
Dampers - Rotary - 2.0 to 3.0 Ncm2.0 to 3.0 Ncm Rotary Dampers. Rotary dampers enable products to function with a smooth mechanical motion. Prevent lid and access panel closure damage.
- An expanded range may be available on special order. Please enquire.
- Body: Polycarbonate / Gear: Polyacetal.
- Fluid: Silicone.
- Temp range 0 to 50 oC.
Product Data
- Damping Torque : 3.0 (+/- 0.8) Ncm
- Direction Bi-directional
- Max Speed 50 RPM
- Gear No Gear
Product Compliance and Data
Additional Resources
Cross References
- ACERD301
- ACE-RD301
