MR2819-2RB-FC-ECO - Datasheet
ECO
Category Information
Bearings - Single Row Ball - Unflanged - Precision - Chrome SteelChrome Steel Precision Unflanged Single Row Ball Bearings. Chrome steel radial ball bearings.
- Single row radial ball bearings are arguably the most common, widely used type of bearing. They consist of an inner ring, an outer ring, a set of balls, and a cage that retains the balls in a circular path.
- Single row radial ball bearings are commonly used in a wide range of applications, including electric motors, fans, pumps, gearboxes, agricultural equipment, appliances, and automotive components.
- They are versatile, cost-effective bearings that provide reliable support for radial loads and some axial loads in one direction. An expanded range may be available on special order. Please enquire.
- Standard single row radial ball bearings.
Product Data
- ID (d)
:
19.000
mm
(Equiv. 0.748 in.) - OD (D)
28.000
mm
(Equiv. 1.102 in.) - Width (B)
5.000
mm
(Equiv. 0.197 in.) - Precision Grade Economy
- Closure Type 2RB
- Bearing Type Radial Full Complement
- Material Chrome Steel SAE 52100
- Lubrication Type Grease
- Lubrication Name Standard Unspecified
- Basic Part MR2819
- Limiting Speed Undefined
- Cage Type Full Complement
- Static Load Rating KGf 82.7
- Dynamic Load Rating KGf 124.7
- Radii Undefined mm
- Inner Shoulder (UI) Undefinedmm
- Outer Shoulder (UO) Undefined mm
- Number of Balls Undefined
- Clearance ECO (5 to 36)
- Precision Grade ECO
- Closure Type 2RB
- Max Temperature 80 Deg. C
