THS048F-016-K-BZ - Datasheet
MBA
Category Information
Screws - Thumb - Knurled - BrassBrass Knurled Thumb Screws. Brass knurled head thumb screws with zinc or black oxide protective coating.
- An expanded range may be available on special order. Please enquire.
Product Data
- Thread Size (C) : 10-32 UNF (4.76mm)
- Thread Length (Tl)
15.88
mm
(Equiv. 0.625 in.) - Overall Length (L)
20.64
mm
(Equiv. 0.813 in.) - Head Diameter (D) 11.11 mm
- Head Height (H) 4.76 mm
- Finish Zinc Chromate Plated
- Material Brass
Product Compliance and Data
Additional Resources
- Screws & Nuts Catalogue
- Shoulder Screws Catalogue
- Socket Set (Grub) Screws Catalogue
- Thumb Screws & Thumb Nuts Catalogue
- Thread Size Chart - Combined Imperial & Metric
Cross References
- 95488A272
- AJ483
- AJ-483
