OR-00142-152-S70-003-C - Datasheet
MBA
Category Information
O-Rings - Silicone RubberSilicone Rubber O-Rings. High thermal resistance and cold flexibility. Some dental applications are included in the listings. Commonly used in food appliactions.
- Temperature Range: -70oC to +200oC.
- Good dialectric properties and resistance to ozone and oxygen attack.
- Retains flexibility at high and low temperatures.
- Poor strength and tear resistance.
- Poor resistance to oils, fuels, concentrated acids and alkalis, water and steam.
Product Data
- Inside Diameter (ID)
:
1.42
mm
(Equiv. 0.056 in.) - Section (t)
1.52
mm
(Equiv. 0.06 in.) - Colour Clear
- Hardness Duro 70
- Material Silicone Rubber
Product Compliance and Data
Additional Resources
Cross References
- ALTPART 1283N424
- Small Parts ORS-003
- ORS003
- BS003SIL70CLEAR
- BS003-SIL70-CLEAR
